Thin film chalcogenide photovoltaic materials

The Thin Film Chalcogenide Photovoltaic Materials symposium 2016 will closely follow the research in the field of chalcogenide materials for photovoltaic applications. The field is in fast progress, especially considering the emerging field of new materials, such as Cu2ZnSn(S,Se)4 in addition to the more mature materials CdTe and Cu(In,Ga)(S,Se)2. The symposium has a long tradition of attracting the most successful researchers in the world within this field and has grown to become one of the largest symposia at E-MRS Spring Meetings.

Scope:

Chalcogenides are highly interesting for use as light absorber layers in solar cells, due to their uniquely high absorbance. These materials include CdTe and the system CuInSe2 – CuGaSe2 – CuInS2 – AgInSe2 -CuAlSe2 and their alloys. The most commonly used alloy in the latter is Cu(In,Ga)(S,Se)2. An emerging material with a growing research interest is Cu2ZnSn(S,Se)4. Examples of chalcogenide materials used as components in this type of solar cells are CdS and Zn(O,S), which are used as buffer layers.

In the recent past industrial activities have expanded, especially in the field of CdTe and Cu(In,Ga)Se2 and a production capacity of above 2 GW per annum has been built up for CdTe and above 1 GW per annum for CIGS. All of the a fore mentioned materials are complex and further fundamental research is needed to investigate the electrical and material properties in order to improve the quality of solar cells and modules. The findings will lead to improved efficiencies of the solar cells and thereby improved cost structures of the solar cell systems. Presently record efficiencies of 21.7% for Cu(In,Ga)Se2, 21 % for CdTe and 12.6 % for Cu2ZnSn(S,Se)4 are obtained, which outperfrom to for example multicrystalline silicon, which has 20.4 % efficiency, whereas monocrystalline silicon is at challenging 25.6 %.

New concepts for further increasing the performance and reducing the costs by, for example, improved solar cell architectures and processing will be discussed, together with new and improved characterization methods involving the latest development in microscopy and electrical measurement equipment.

In previous E-MRS conferences the research communities in these highly productive research fields have met to discuss and learn from each other. In addition to oral presentations and poster sessions also discussion sessions with thematic topics have been and will be included at the end of each day. A young scientist tutorial has been a very popular event among the PhD students in the field. We strongly believe that this successful series will attract the leading researchers in the field also in the next E-MRS conference 2016.

Hot topics to be covered by the symposium:

  • Processes for film synthesis
  • Thin film growth, theory and experimental aspects
  • Material combinations and heterostructures
  • Chalcogenide PV materials, theory and modeling
  • Novel / alloyed chalcogenide materials
  • Material characterization methods
  • Electrical characterization methods, device analysis
  • New understanding of defects in chalcogenide-based PV materials
  • Research related to upscaling and manufacturing
  • Diagnostic tools
  • Chalcogenide based solar cells in tandem devices
  • The role of alkaline in chalcogenide based solar cells
  • Passivation of interfaces and surfaces
  • Novel device concepts

List of invited speakers:

  • Theresa Magorian Friedlmeier, ZSW: High efficiency CIGS solar cells
  • Ana Kanevce, NREL: Photoluminescence microscopy and numerical simulations
  • Negar Naghavi, IRDEP: Ultrathin CIGS solar cells
  • Roberto Menozzi, Parma University: 2D/3D device modeling
  • Bart Vermang, IMEC: Surface and interface passivation in thin-film solar cells
  • Janez Krk, University of Ljubljana: Optical confinement in chalcogenide based solar cells
  • Tokio Nakada, Tokyo University of Sciences: Buffers and windows of chalcogenide based solar cells
  • Gang Xiong, First Solar: High efficiency CdTe solar cells and modules
  • Shogo Ishizuka, AIST: Highefficiency CuGaSe2 solar cells

Tentative list of scientific committee members:

  • D. Lincot (IRDEP, France)
  • C. Ferekides (University of South Florida, USA)
  • T. Wada, (Ryokoku Univ., Japan)
  • A.N. Tiwari (Empa, Switzerland)
  • J.F. Guillemoles (IRDEP, France)
  • H.W. Schock (Helmholtz Zentrum Berlin, Germany)
  • D. Cahen (Weizmann Institute of Science, Israel)
  • U. Rau (Research Center Jülich, Germany)
  • R. Scheer (University of Halle, Germany)
  • A. Romeo (University of Verona, Italy)
Start atSubject View AllNum.Add

High efficiency CGIS and CdTe solar cells : S. Schorr, H. Hiroi
13:30
Authors : Theresa Magorian Friedlmeier, Philip Jackson, Andreas Bauer, Dimitrios Hariskos, Oliver Kiowski, Richard Menner, Wolfram Witte, Roland Wuerz, Michael Powalla
Affiliations : Zentrum für Sonnenenergie- und Wasserstoff-Forschung Baden-Württemberg, Industriestrasse 6, D-70565 Stuttgart, Germany

Resume : Record small-cell efficiencies for CIGS-based thin-film solar cells have recently surpassed the 22% mark [1]. 21.7% could be demonstrated by the ZSW laboratories in the fall of 2014 [2] and since then well above 200 cells with efficiencies exceeding 21% have been produced. Efficiency increases are attributed to the post-deposition treatment which is applied to adjust the concentrations of alkali elements in the CIGS layer. As a result, the optoelectronic properties of the CIGS film are modified and the surface is conditioned for improved subsequent buffer layer deposition. In this contribution we will provide an overview of the history and status of high-efficiency CIGS solar cells with a focus on latest developments in the ZSW laboratory and upscaling issues. [1] Solar Frontier press release Dec 8, 2015; http://www.solar-frontier.com/eng/news/2015/C051171.html [2] P. Jackson, D. Hariskos, R. Wuerz, O. Kiowski, A. Bauer, T. M. Friedlmeier, M. Powalla, “Properties of Cu(In,Ga)Se2 solar cells with new record efficiencies up to 21.7%,” Physica Status Solidi (RRL) 9 (2015) 28-31.

V.I.1
14:00
Authors : Erik Wallin, Viktoria Gusak, Sven Södergren, Si Chen, Tobias Jarmar, Nikolai Kaihovirta, Ulf Malm, Juhan Lundberg, Johan Mathiasson, Olle Lundberg, Lars Stolt
Affiliations : Solibro Research AB, Vallvägen 5, SE-75651 Uppsala, Sweden

Resume : Post-deposition treatment (PDT) of the absorber material with KF has gained significant interest in the CIGS community lately, owing to the remarkable increase in conversion efficiency observed by several research groups. In this contribution, we discuss results from the implementation of a KF PDT process into Solibro’s full-size co-evaporation pilot line. In line with available literature on single cells, a significant increase in conversion efficiency was observed also for full-size modules, driven by increased open-circuit voltage (Voc). However, in contrast to several previously published studies on KF PDT, fill factor (FF) was in many cases decreased due to a tendency of blocking behaviour in the cell current-voltage curve. This blocking could be remedied, at least partly, by light soaking, and the nature of this effect will be discussed further. Moreover, PDT treated CIGS allowed for the use of thinner CdS layers (without loss in Voc and FF) leading to increased short-circuit current. Compositional depth profiling using glow-discharge optical emission spectroscopy revealed incorporation of K accompanied by a simultaneous loss of Na, and reduced Cu and Ga contents in the absorber surface region. Using a fully scalable implementation of a KF PDT process, full-size module (119×63 cm2) aperture area efficiencies exceeding 17.5 % (certified measurement pending) were achieved.

V.I.2
14:15
Authors : Gang Xiong
Affiliations : California Technology Center First Solar Inc. 1035 Walsh Ave Santa Clara, CA 95050 USA

Resume : In 2015, First Solar has set two new CdTe efficiency records: 21.5% on cell and 18.6% on module aperture efficiency. Presently, Jsc is approaching the theoretical limit of CdTe. Increased Voc has been mostly driven by a nearly two-decade improvement of minority carrier lifetime (from ~1 ns to 100 ns). While 916 mV Voc has been achieved on poly-crystalline CdTe devices with Cu doping and no back surface passivation, further Voc improvement will require some breakthrough on absorber doping and/or reduction of back surface recombination. Recently, research on group-V doping of CdTe has demonstrated greater than 1016 cm-3 hole concentration in poly-crystalline devices. Materials such as Cd1-xMgxTe also showed promise on reduction of CdTe surface recombination velocity. However, in both cases, significant process and device integration challenges need to be overcome in order to demonstrate devices with higher Voc and efficiency. The 18.6% module is a proof on how quickly lab technology breakthroughs can be scale up to mass production. In addition, continuous advancement has been made to further enhance the technology advantage of CdTe modules, for example energy yield. Our commercially available 16.3% efficiency CdTe modules showed 11% power density advantage compared to multi-crystalline Si due to superior temperature coefficient, spectra and shading response. Adoption of new back contact technology also significantly reduced the longer term efficiency degradation. In summary, the progress in recent CdTe cell and module technology development are further evidences of sustainable future of CdTe PV, as measured by levelized cost of electricity which is already competitive to fossil fuel.

V.I.3
14:45
Authors : Guillaume Stechmann (1), Stefan Zaefferer, (1), Peter Konijnenberg (1), Torsten Schwarz (1), Dierk Raabe (1), Christina Gretener (2), Lukas Kranz (2), Julian Perrenoud (2), Stephan Buecheler (2) and Ayodhya Tiwari (2)
Affiliations : (1) Max-Planck-Institut für Eisenforschung GmbH, Duesseldorf, Germany; (2) Laboratory for Thin Films and Photovoltaics, Empa - Swiss Federal Laboratories for Materials Science and Technology, Duebendorf, Switzerland

Resume : Studies of functional materials often require a correlation between their structure and a set of relevant physical properties. In the case of semiconductors and particularly for thin film solar cells, establishing this connection has long been, and is still, a critical issue due to the different characterization scales required to probe both microstructural and electronic features. In the present work, we propose a correlative approach, using recent scanning electron microscopy (SEM) analytical techniques, aiming at characterizing cadmium-telluride (CdTe) thin films solar cells. Focused ion beam / electron backscatter diffraction tomography (3D-EBSD) is used to probe the evolution of a set of relevant parameters (grain size, texture, grain boundary character distribution...), through the whole thickness (around 4 microns) of this strongly microstructurally-anisotropic absorber layer. Moreover, the three-dimensional grain boundary network can also be reconstructed, providing a complete 5-parameters description of these interfaces. Electron channeling contrast imaging under controlled diffraction conditions (c-ECCI) is then employed to image and characterize dislocations and nano-twins on bulk samples with a lateral resolution down to a few nanometers only. In addition, these microstructural features are correlated with their electronic properties using panchromatic and spectrally-resolved cathodoluminescence, establishing the bridge between microstructure and functional properties. Finally molecular dynamics (MD) simulation is also employed to probe the atomistic structure of grain boundaries.

V.I.4
15:00
Authors : James R Sites
Affiliations : Department of Physics, Colorado State University, Fort Collins CO 80523 USA

Resume : Despite remarkable efficiency improvements, CdTe solar cells have not achieved highly-competitive voltages, only about 75% of the ideal for CdTe compared to 83% for Si and 85% for CIGS [1]. The voltage limitation is primarily due to the low carrier densities and recombination lifetimes. One approach to increase voltage is higher doping; the alternative presented here is a conduction-band barrier for back-contact electron reflection of both photogenerated and forward-current electrons [2]. This has been accomplished with the addition of a CdMgTe (CMT) layer deposited by close-space-sublimation similar to that used for CdTe, CdS, and CdCl2 [3]. Voltage increases have been observed for CdTe-absorber thicknesses from 2 μm down to 0.3 μm with increases up to 90 mV for the thinner absorbers. Additional evidence for the effectiveness of electron-reflection has been seen in increased EBIC signal from the rear part of the absorber, increased collection from longer-wavelength photons, and increased TRPL lifetime. One issue with oxidation of Mg in the CMT layer was addressed with a capping layer of CdTe. Work continues on optimal passivation of cells with CMT, the most appropriate CMT band gap, and the best back contact to use with CMT. [1] R.M. Geisthardt, M. Topič, and J.R. Sites, IEEE J. Photovoltaics 5, 1217-1221 (2015). [2] K.J. Hsaio and J.R. Sites, Prog. in Photovoltaics 20, 486-489 (2012). [3] P.S. Kobyakov et al, J. Vac. Sci. Technol. A32, 021511 (2014).

V.I.5
15:15
Authors : Martina Lingg, Annina Spescha, Julian Perrenoud, Stephan Buecheler, Ayodhya N. Tiwari
Affiliations : Laboratory for Thin Films and Photovoltaics, Empa - Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstrasse 129, 8600 Duebendorf Switzerland.

Resume : As one of the most promising absorber materials for high-efficiency and low-cost solar cells, CdTe holds the highest market share among thin film photovoltaics technologies. The performance improvement of conventional CdTe solar cells is mainly limited by minority carrier life time and achievable doping concentration. Introducing a compositional grading by alloying CdTe is a possible approach to overcome both limitations by introducing electric fields to increase carrier drift and by increasing acceptor type defect concentrations. In this work we co-evaporated CdTe and CdSe with varying rates to realize a graded alloying of the ab-sorber. Depending on the composition of the resulting CdTe1-xSex, the band gap can be shifted to higher and lower values with a minimum band gap of 1.38 eV for x=0.3. A decrease of the bandgap from 1.45 eV to ~1.38 eV leads to a gain in photocurrent. Further it is expected that CdSe alloying will increase the solubility of the p-dopant Cu and thereby increase the VOC. By simultaneous evaporation of CdTe and CdSe with varying rates, we introduce a concentration gra-dient in the solar cell absorber layer. The resulting band gap behaviour is analysed, as well as the sta-bility of the gradient during subsequent processing of the solar cell. An already observed decrease of the band gap by addition of CdSe was shown to improve the photo-current of CdTe solar cells, but with losses in VOC and fill factor. Further results will include the influence of alloying on the dopant concentration and therefore charge carrier concentration.

V.I.6
15:30 Coffee break
16:00
Authors : K. Abderrafi(1,2), R. R-Andrade(1,3), N. Nicoara(1,2), H. Limborço(1,3), J.C. Gonzalez(3), P.M.P. Salomé(1), F. Briones(2), J.M. Garcia(2), and S. Sadewasser(1)
Affiliations : 1 International Iberian Nanotechnology Laboratory, Av. Mestre José Veiga s/n, 4715-330 Braga, Portugal 2Instituto de Microelectrónica de Madrid, CSIC, Spain 3 Universidade Federal de Minas Gerais, Belo Horizonte, Brazil

Resume : While CuInSe2 chalcopyrite materials are mainly used in their polycrystalline form to prepare thin film solar cells, epitaxial layers have been used for the characterization of defects. Typically, epitaxial layers are grown by metal-organic vapor phase epitaxy and molecular beam epitaxy (MBE). Here we present epitaxial layers grown by migration enhanced epitaxy (MEE), which was previously introduced for III-V compounds [1], and compare the materials quality to standard MBE grown layers. CuInSe2 layers were grown on GaAs(001) substrates by co-evaporation of Cu, In, and Se using substrate temperatures of 450ºC, 530ºC, and 620ºC. In contrast to MBE deposition, where all elements are evaporated simultaneously, in MEE deposition cycles of alternating (Cu+In) and (Se) deposition of 2 seconds each are repeated, maintaining all other conditions equal. High-resolution x-ray diffraction and high-resolution transmission electron microscopy show a better crystalline quality of the MEE grown layers, and Raman spectroscopy confirms single phase CuInSe2. Atomic force microscopy shows the typically observed faceting of the (001) surface into {112} facets with trenches formed along the [1-10] direction. For MEE samples, the surface exhibits less roughness compared to the MBE growth, a similar trend is observed with increasing growth temperature. Additionally, we analyze interdiffusion of In and Ga at the CuInSe2/GaAs interface. [1] Y. Horikoshi et al., J. Chryst. Growth 105, 326 (1990).

V.P1.1
16:00
Authors : Hocine Abib (1.2), Khadidja Rahmoun (1), Jean-Pierre Vilcot (2), Alex Montagne (3), Alain Iost (4).
Affiliations : Unité de Recherche Matériaux et Energies Renouvelables URMER, Université Abou Bakr Belkaid, BP 119, Tlemcen 13000, Algérie; Institut d'Electronique de Microelectronique et de Nanotechnologie IEMN, Cité Scientifique - Avenue Poincaré - CS 60069 59652 Villeneuve d'Ascq cedex, France; Université Lille Nord de France, USTL, LML, CNRS, UMR 8107, F-59650 Villeneuve d'Ascq, France; Arts et Métiers ParisTech — Centre de Lille, 8, Boulevard Louis XIV, 59000 Lille Cedex, France.

Resume : The nano indentation is a well-known method for materials characterization and it has a considerable interest in the field of thin films. Its principle lies in bringing a very small tip, also called indenter of known geometry and mechanical properties, to the surface of the material to be characterized producing an imprint, in order to deduce its mechanical properties. The aim of this work is to assess the mechanical properties of the different layers composing a CIGS based solar cell, obtained by magnetron sputtering deposition technique. We performed indentation tests on the surface of the solar cell and deduced by à hardness composite model the mechanical properties of each individual layers (bottom electrode, transparent conductive oxide, absorbing layer) deposited on glass substrates, by varying the applied force. Keywords: CIGS, Nano indentation, hardness, Young's modulus.

V.P1.2
16:00
Authors : P. Arnou1*, C.S. Cooper2, S. Ulicna1, A. Abbas1, A. Eeles1, L. Wright1, A.V. Malkov2, J.M. Walls1 and J.W. Bowers1
Affiliations : 1Centre for Renewable Energy Systems Technology (CREST), School of Mechanical and Manufacturing Engineering, Loughborough University, Loughborough, Leicestershire, LE11 3TU, UK 2Department of Chemistry, Loughborough University, Loughborough, Leicestershire, LE11 3TU, UK

Resume : The chalcopyrite semiconductor CuInSe2 along with its alloys, referred to as CIGS, is currently the highest performance PV material for thin film solar cells. There has been significant interest in developing solution processing for CIGS, as a low cost alternative to conventional vacuum-based deposition methods. The highest performing solution-based approach to date has been obtained by dissolving metal chalcogenides in hydrazine. High quality CuInSe2 and Cu(In,Ga)Se2 devices have been obtained with a 12.2% and 15.2% efficiency, respectively. Although hydrazine is an excellent solvent for dissolving these types of precursors, it is highly toxic. The safety requirements of this approach would introduce significant additional costs which prevent the manufacture of economically viable modules. A safer and less expensive method is required which combines the simplicity of this approach, but still results in high efficiency devices. In this paper we report on a new approach that has been developed for the preparation of high quality CIGS solar cells, which is safe, simple, easily controllable and cost effective. Metal sulphides are rapidly dissolved in ambient conditions in an alternative solvent mixture (dithiol/diamine). The post-deposition selenization of the sprayed films results in high quality CuIn(S, Se)2 films, exceeding 8% efficiency. The addition of elemental gallium to the starting solution has also resulted in CIGS thin films with excellent crystalline quality.

V.P1.3
16:00
Authors : L. Arzel ,T. Lepetit, S. Harel, and N. Barreau
Affiliations : Institut des Matériaux Jean Rouxel (IMN) - UMR6502, Université de Nantes, CNRS, 2 rue de la Houssinière, BP 32229, 44322 Nantes Cedex 3, France

Resume : KF-PDT of CIGSe surface introduced by the EMPA group allows to increase all the photovoltaic performances of solar cells. In this work, we studied the impact of chemical etching with HBr/Br2 onto CIGSe surface. The etching will modify at the same time the roughness and the surface chemistry. The aim of the study is to investigate the influence of surface chemistry and roughness on KF-PDT effects. The CIGSe layers were prepared by two step process (CUPRO) to avoid gradient of composition, after deposition the absorbers were etched, and finally KF-PDT was performed. IV and EQE were measured on standard cell structure. To evaluate the etching and KF-PDT effects on the roughness, we calculated haze factor from reflectance on bare absorbers and cells. The RMS roughness decreases from 60 to 35 nm. To study the chemistry of surface, we performed Raman scattering and XPS. We observe that Jsc and FF decrease strongly for etched cells compared to reference ones. The etched-treated cell recovers the FF reference value (73%) and shows higher Jsc and Voc than the reference ones. On etched surface, chemical species such as elemental Se and Cu2Se are identified, they hinder the junction formation and interface recombinations are the dominant mechanisms. The treatment cleans the etched surface, the CdS growth is more homogeneous even though the surface is rougher. So surface chemistry at heterojunction plays an important role in increasing Voc.

V.P1.4
16:00
Authors : T. Aviles, B. Ayachi, C. Sion, and J.P. Vilcot
Affiliations : Crosslux,Rousset, France; Institut d’Electronique, de Microélectronique et de Nanotechnologie de Lille UMR CNRS 8520, Villeneuve d’Ascq, France

Resume : A new method has been developed to form CIGS absorbers by magnetron pulsed DC sputtering at room temperature from a single quaternary target in an inert argon atmosphere without additional selenium supply followed by a rapid thermal annealing (RTP) in a N2 atmosphere that allows a good re-crystallization of the film. The target composition has been designed to get an adapted Cu-poor and Se-rich film composition. In this work, we investigate the CIGS material properties by a wide range of structural, chemical, physico-chemical techniques such as EDX, FIB, Raman, SIMS, strain measurements, XRD, KFM and Hall probes.

V.P1.5
16:00
Authors : B. AYACHI (1), T. Aviles (2). J.P.Vilcot (1), C. Sion (3)
Affiliations : (1) Institute of Electronics, Microelectronics and Nanotechnology, Lille 1 University, Avenue Poincaré, UMR 8520 - CS 60069, Villeneuve d’Ascq, 59652, France; (2) CROSSLUX, Avenue Georges Vacher, ZI Rousset Peynier, Immeuble CCE, Rousset, 13106, France ; (3) Ecole Centrale Lille, Cité Scientifique - CS20048, Villeneuve d’Ascq, 59651, France

Resume : Nowadays, the fabrication of the highest efficiency CIGS based solar cells needs the use of a co-evaporated absorber layer and a wet-chemically deposited buffer layer. Such a high efficiency is attributed to the absorber band gap engineering and the numerous advantages of the chemical bath deposition process. However, in the case of large surface deposition, the high cost and the complexity of the co-evaporation technique, on one hand and, on the other hand, the offline process, the toxicity, the waste recycling and the huge amount of needed chemical products, are still pointed out as real issues for industrialization. In this work, believing in the fact that sputtering might lead to low production cost and features better in-line-processing compatibility, we will present our first results on solar cells entirely deposited by sputtering: a DC-sputtered molybdenum back contact, a pulsed-DC sputtered CIGS absorber from a quaternary target, a zinc oxysulfide buffer layer deposited by an ALD-inspired sputtering technique and a pulsed-DC sputtered AZO front contact. A comparative study to reference cells with CBD buffer layers will also be presented

V.P1.6
16:00
Authors : Idris Bouchama1,2,*, Kamal Djessas3, Abdeslam Bouloufa2,4, Djeffal faycal5
Affiliations : 1 Département d’Electronique, Faculté de Technologie, Université de Msila, Alegria. 2 Laboratoire d’Electrochimie et Matériaux, Université Ferhat Abbas de Sétif, Algeria. 3Laboratoire Procédés Matériaux et Energie Solaire PROMES-CNRS, Rambla de la Thermodynamique, Technosud, 66100 Perpignan, France. 4Département d’Electronique, Faculté de Technologie, Université de Setif, Algeria. 5LEA, Département d’Electronique, Faculté de Technologie, Université de Batna, Batna 05000, Algeria

Resume : CuIn0.7Ga0.3Se2 (CIGS) thin films were deposited with different substrate temperatures by using radio-frequency (rf) magnetron sputtering on glass substrates and an annealing process for improving the crystallinity and the morphology of the prepared films was performed. The annealing step was performed in argon gas atmosphere at 300°C for 1h. The influence of the substrate temperatures on the crystalline quality as well as structural, optical and electrical properties of thin layers obtained has been studied. X-ray diffraction showed that the films were highly orientated in the (112) and/or (204)/(220) direction. In2Se3 secondary phase was observed on the samples grown at lower substrate temperatures. The surface morphology of CIGS layers studied by Atomic Force Microscopy (AFM) and Scanning Electronic Microscopy (SEM) has been also discussed. The most surprising and exciting outcome of this study was that the as grown films were of near stoichiometric composition after annealing. Resistivity measurements were carried out using the four point probe method. The optical absorption showed that energy gap values are between 1.13 and 1.18 eV and rather sharp absorption fronts. Thin films resistivities are between 10.7 and 60.9 Ω.cm depending on the experimental growth conditions. Keywords : Cu(In,Ga)Se2, thin films, rf-magnetron sputtering, secondary phase.

V.P1.7
16:00
Authors : Chia-Wen Chang, Wei-Sheng Lin, Chou-Cheng Li, Sheng-Wen Chan, Tung-Po Hsieh, Song-Yeu Tsai, Hsi-Chuan Chen
Affiliations : Industrial Technology Research Institute (ITRI)

Resume : Thin film absorbers Cu(In,Ga)S2 (CIGS) were prepared by means of co-evaporation Cu-In-Ga metallic precursors followed by reactive annealing in elemental sulfur vapor. We investigated the correlation between S incorporation and phase formation during sulfurization process with various temperatures. For the structural properties of the CIGS thin films and the crystallization process were investigated by X-ray diffraction (XRD), Raman spectroscopy, scanning electron microscope (SEM), energy-dispersive X-Ray spectroscopy (EDS). The solar cells were fabricated for I-V characteristics and quantum efficiency measurements. The microstructural characterization of sulfurized CIGS films was performed by combined in Raman scattering and XRD measurements as a function of the composition and temperature of sulfurization. The major peak of Raman spectrum for CIGS was characterized by a dominant A1-mode at approximately 290−292 cm-1. The Raman peak was also accompanied by a significant shoulder of an additional line at 303 cm-1 and broaden minor peaks at 240, 258, 322 cm-1.The presence of such phases was strongly related to the temperature of sulfurization, being obviously secondary phases formation when the crystallization temperature below to 550oC. The XRD of Cu(In1-xGax)S2 film shows three prominent peaks due to (112), (204)/(220), (116)/(312) planes while that of β-In2S3 shows from (206), (0012), (1015), (419) planes. The minor peaks may be due to the formation of β-In2S3 secondary phase in the CIGS. The CIGS absorber with poor structural quality shows the appearance of the additional line in the spectra gives remarkable support to its worse crystalline qualities origin and related to the decreasing of conversion efficiency.

V.P1.8
16:00
Authors : Ivan Fernández-Martínez 1, Victor Bellido-Gonzalez 2, Raquel Caballero 3, Dermot Monaghan 2, Joseph Brindley 2, Benoit Daniel 2, Robert Brown 2, Ambiorn Wennberg 1 and Maximo Leon 3
Affiliations : 1 Nano4Energy SL, Madrid, Spain 2 Gencoa Limited, Liverpool, UK 3 Universidad Autónoma de Madrid, Madrid, Spain

Resume : The 21st century has seen a rapid increase in the manufacturing of thin film photovoltaic (PV) panels. One of the most successful materials as a PV absorber has been CuInGa(Se,S). Although different deposition methodologies have been employed, one of the steps that remain critical in the manufacturing and performance of the solar cells is the selenisation of the CuInGa alloy. Effusion cells of different forms and shapes are in the market but effective methods to control the vapour are limited, hence most of the production platforms evaporate Se in an open loop configuration lacking any real feedback. Selenium is generally poured into the deposition system in excess. Such are the consequences in production that the largest material cost in CIGS production is the Se rather than the In as would many people believe. In CIGS production more than 90% of the Se gets wasted away. In addition to the material costs the level of waste gives an even bigger problem due to the waste management and cleaning operations needed for the contaminated elements of the deposition system. The authors of this presentation have developed and tested a new type of Se sensor for such application which is combined with a pulsed Se effusion cell and allows real feedback control regulation to maintain deposition conditions in a stable vapour pressure environment.

V.P1.9
16:00
Authors : P. Prepelita a, V. Craciun a, A. Vlad a, F. Garoi a, G. Sbarcea b
Affiliations : a National Institute for Laser, Plasma and Radiation Physics, 409 Atomistilor Street, PO Box MG-36, Magurele 077125, Ilfov, Romania b National Institute for R & D in Electrical Engineering ICPE-CA, Splaiul Unirii Street, Nr. 313, District 3, 030138, Bucharest Romania

Resume : This paper investigates the dependence of Cu(In,Ga)Se2 thin films on their thickness using multiple structural investigation techniques. The Cu(In,Ga)Se2 chalcogenide thin films, with thickness of 750 nm, 1000 nm and 1200 nm, respectively), were deposited onto molybdenum back contacts on glass substrate by rf magnetron sputtering technique from a single sintered sputtering target. The Cu(In,Ga)Se2 layer is then capped with a 60 nm CdS thin film deposited by vacuum thermal evaporation. Atomic Force Microscopy (AFM) and Scanning Electron Microscopy (SEM) investigations show that surface morphology changes with the deposition technique and it is influenced by the increase in thickness of the Cu(In,Ga)Se2 layer. We used XPS, XRD and SEM characterization technique to reveal the micro-structural and compositional changes in these Cu (In, Ga) Se2 layers, which are used in the realization of solar cells. The surface composition of the Cu(In,Ga)Se2 films, given by the XPS intensities, is in good agreement with the results of the EDAX analysis. Cu(In,Ga)Se2 chalcogenide thin films are polycrystalline and have a tetragonal lattice, with plane (112) parallel with the surface of the substrate. Moreover, we found that the intensity of the (112) peak is the highest for the 1200 nm thick sample, which suggests the usage of thicker Cu(In,Ga)Se2 films in order to improve the structural quality of chalcogenide materials. The optical reflectance as a function of wavelength was measured for the studied samples. As expected, the reflection coefficients of the deposited Cu(In,Ga)Se2 films were higher with increasing thickness. The increase of thickness of the Cu(In,Ga)Se2 film determined the decrease of the band gap value.

V.P1.10
16:00
Authors : Arnaud Gerthoffer, Frédéric Roux, Fabrice Emieux, Pascal Faucherand, Hélène Fournier, Louis Grenet, Simon Perraud
Affiliations : CEA, LITEN - 17 rue des Martyrs, 38054 Grenoble Cedex 9, France

Resume : The development of Cu(In,Ga)Se2 (CIGS) thin-film solar cells is highly desirable because of their great potential for reduction of both raw material consumption and manufacturing costs, in particular if flexible substrates compatible with roll-to-roll processing are used. Additionally, using flexible substrates allows the fabrication of high power-to-weight ratio panels and opens new integration possibilities. Today, comparable levels of power conversion efficiency (higher than 20%) have been demonstrated on both rigid (soda-lime glass) and flexible (polyimide) substrates. However, very little is known about the evolution of the photovoltaic performances of CIGS solar cells when they are bent. Here we report an original study on the effects of bending-induced mechanical stress on CIGS solar cells fabricated on 100 µm thick ultra-thin glass substrates. Compared with polyimide, ultra-thin glass benefits from high temperature resistance, low coefficient of thermal expansion, high transparency and high moisture barrier property. After 100 bending cycles with a radius of curvature of 54 mm, a relative decrease of 12.5% of the efficiency was observed. This could be explained by mechanical cracks observed by scanning electron microscopy in some cyclically bent solar cells. A study on the stress induced in the CIGS layer depending on the substrate properties and the radius of curvature is reported and approaches to lower the degradation of thin-film solar cells are discussed.

V.P1.11
16:00
Authors : S. Harel (1), T. Lepetit (1), P. Jonnard (2), L. Arzel (1), N. Barreau (1)
Affiliations : (1) Institut des Matériaux Jean Rouxel (IMN) - UMR6502, Université de Nantes, CNRS, 2 rue de la Houssinière, BP 32229, 44322 Nantes Cedex 3, France ; (2) Sorbonne Universités, UPMC Univ Paris 06, CNRS UMR7614, Laboratoire de Chimie Physique - Matière et Rayonnement, 11 rue Pierre et Marie Curie, F-75231 Paris cedex 05, France

Resume : Sulfurization of CIGSe surface allows to form Cu(In,Ga)(Se,S)2 with wider band gap than the pure selenide phase and yields improved solar cells performance. Recently Li et al. [1] showed that sulfurization leads to passivated CIGSe surface and grain boundaries (GBs) which lower photo-generated carrier recombination. Surface partial sulfurization of co-evaporated CIGSe absorbers is strongly dependent on absorber surface chemical characteristics [2]. Last record efficiency obtained by K-post-deposition treatment (K-PDT) after the co-evaporation of the absorber have shown to modify the CIGSe surface composition with marked Cu and Ga depletions and so could possibly change the CIGSe sulfurization yield. It therefore appears relevant to investigate whether the K-PDT could enhance the sulfurization of the CIGSe polycrystalline thin film surface and GBs during the chemical bath deposition of CdS buffer layer. In the present study we show through XPS measurements that the presence of potassium at the CIGSe surface indeed favors greatly its sulfurization. In order to investigate the CIGSe sulfurization during the chemical bath deposition of CdS buffer layer, buried K treated CIGSe/CdS interfaces have been investigated with the help of non-destructive, depth-resolved EXES (Electron-induced X-ray Emission Spectroscopy) measurements. [1] W. Li et al Sol. Energy Mater. Sol. Cells 120, 500 ( 2014) [2] J. Djordjevic et al J. Phys. Chem. Solids 64, 1843 (2003)

V.P1.12
16:00
Authors : (a) Elif Peksu, (a) Sare Akgöz, (a-b) Hamed Behzad and (a) Hakan Karaagac*
Affiliations : (a) Department of Physics Engineering, Istanbul Technical University, Maslak, 34469 Istanbul, Turkey *E-mail: karaagacha@itu.edu.tr (b) Department of physics, Faculty of Science, The University of Guilan, Namjoo Avenue, 413351914 Rasht, Iran

Resume : CuIn0.5Ga0.5Se2 (CIGS) thin films were successfully deposited on soda-lime glass substrates at room temperature via one stage electron-beam technique by using a stoichiometric single crystalline powder as evaporation source. The thickness of the deposited films was simultaniously monitored through thickness monitor during the deposition cycle and subsequently checked by surface profilometer, which was found to be around 1μm. A number of characterization techniques have been employed in order to reveal the structural, electrical and optical properties of the deposited films. Amorphous nature of the as-grown CIGS thin films was revealed by X-ray diffraction pattern (XRD). Following the post-annealing process at 250 o C it was revealed that there was a transition from the amorphous state to polycrystalline state as well as an improvement in crystallinity with increasing annealing temperature. Energy-dispersive X-ray energy dispersive (EDXA) analysis patterns exhibited that there was a deviation from stoichiometry of CuIn0.5Ga0.5Se2 thin films, which was attributed to the low vapor pressure of Cu and high vapor pressure of selenium (Se) during the evaporation process. Large agglomeration on the surface of the as-grown film was revealed by scanning electron microscopy (SEM) and atomic force microscopy (AFM) measurements. From these measurements, the size of features were determined and found to be increasing significantly with increasing annealing temperature. Temperature dependent photoconductivity measurements were performed for as-grown and CIGS thin films annealed at 350 oC and 450 oC under different light intensities. Results showed that there was a remarkable increase in conductivity following the increase in illumination intensity for all CIGS thin films. Room temperature conductivities of this films were calculated to be 6.76x107, 3.38x107 and 2.19x105 Ω.cm for as-grown, the film annealed at 350 oC and 450 oC, respectively. Based on transmitance and reflectance measurement results, it was observed that there was a fluctuation in both following the post-annealing at different temperatures. From the absorption and photon energy relation, energy band gaps were extracted, which exhibited a dramatic change following the post-annealing process, which was attributed to the modification observed in the structure of the films after heat treatment.

V.P1.13
16:00
Authors : Samira Khelifi(1), Johan Lauwaert(1), Maria Batuk(2), Armin E. Zaghi(3,4), M. Buffière(4,5), Joke Hadermann(2), Marc Meuris(6,7), Jef Poortmans(4,5), Jef Vleugels(3), Jeroen Beeckman(1), Kristiaan Neyts(1)
Affiliations : (1) Department of Electronic and Information Systems (ELIS), University of Gent, St-Pietersnieuwtraat 41, B-9000 Gent, Belgium (2) Electron Microscopy for Materials Science (EMAT), University of Antwerp, Groenenborgerlaan 171, 2020 Antwerp, Belgium (3) Department of Materials Engineering (MTM), KU Leuven, Kasteelpark Arenberg 44, 3001 Heverlee, Belgium (4) imec – partner in Solliance, Kapeldreef 75, 3001 Heverlee, Belgium (5)Department of Electrical Engineering (ESAT), KU Leuven, Kasteelpark Arenberg 10, 3001 Heverlee, Belgium (6) imec division IMOMEC – partner of Solliance, Wetenschapspark 1, 3590 Diepenbeek, Belgium (7) Institute for Material Research (IMO) Hasselt University, Wetenschapspark 1, 3590 Diepenbeek, Belgium

Resume : Chalcogenide absorber layers were prepared by doctor blading of mechanically alloyed and planetary ball milling Cu-In-Se nanopowder. The CuInSe2 thin film solar cells fabricated from the prepared absorbers showed an efficiency of 5.7 % on a device area of 0.25 cm2. It’s well known that for CdS/CuInSe2 solar cell devices, a post-treatment is required to achieve higher conversion efficiency. To investigate the effect of post-annealing temperature on the morphology and the electrical properties of the CuInSe2 based solar cells, samples were annealed under both nitrogen atmosphere and air environment, using a rapid thermal processing furnace (RTP). The performance, composition and morphology of the solar cells have been investigated using advanced electrical characterization techniques. It was found that annealing temperatures above 200-225 °C rapidly degrade the solar cells. Device efficiencies decrease by 50-90% over a temperature range 200  T  400 °C. The capacitance-voltage measurements show a decrease in the doping profile near the surface of the CuInSe2 absorber which could be assigned to the formation of an interfacial transition layer due to the diffusion of constituent elements and segregation of located structures. Segregation of different secondary phases on the CuInSe2 surface and grain boundaries was confirmed by TEM and EDX measurements. A noticeable growth of CuInSe2 grains is observed in samples annealed under nitrogen atmosphere.

V.P1.14
16:00
Authors : A. KOTBI (1, 3), S. FADILI (1), B. HARTITI (1), K. ABDERRAFI (2), A. RIDAH (3), P. THEVENIN (4)
Affiliations : (1) MAC&PM Laboratory, ANEPMAER Group, FSTM, Hassan II Casablanca University, B.P 146, Mohammedia, Morocco; (2) INL- International Iberian Nanotechnology Laboratory , Avenida Mestre José Veiga s/n, 4715-330 Braga, Portugal; (3) LIMAT Laboratory, Departement of Physics, FSB, Hassan II Casablanca University, B.P 7955, Casablanca, Morocco; (4) LMOPS Laboratory, Department of Physics, University of Lorraine, Metz, France

Resume : In this study, CuIn1-xGaxS2 (CuInGaS2) multi-component semiconductors thin films were elaborated by chemical spray pyrolysis on glass substrates using different concentrations of gallium in the spray solutions (y=([Ga3 ]/[In3 ]) varying from 5 to 25 at% by a step of 10 at%). The fabricated films were characterized by using Raman spectroscopy measurements, UV-VIS spectroscopy and 4-point probe technique. Raman spectra revealed that all of the spray pyrolyzed CuInGaS2 thin films have chalcopyrite structures. Optical studies reveals that the band gap of the films increases by increasing the Ga content and it is in the range 1.50-1.56 eV, indicating that CuIn1-xGaxS2 compound has an absorbing property favorable for applications in solar cell devices. Finally electrical parameters such as sheet resistivity of the samples revealed that sample prepared at 5 at% was less resistive than the other samples. Keywords-CuIn1-xGaxS2; thin films; spray pyrolysis; solar cell.

V.P1.15
16:00
Authors : Jackson LONTCHI, Mohamed ABAAB
Affiliations : National School of Ingeneers of Tunis, Tunis, Tunisia

Resume : We have deposited undoped and Na doped CuInS2 by thermal evaporation on glass substrates followed by annealing in air atmosphere in the temperature range of 250-450°C. Structural and optical properties have been explored. For electrical properties, we have performed impedance spectroscopy studies on the sample in the frequency range of 1Hz to 13MHz at different temperature from 300 till 480°C. The structural studies showed an amorphous structure as deposited and crystallized after annealing in air atmosphere with the 112 chalcopyrite major peaks. The crystal parameters confirm the tetragonal structure with the crystals parameters near the optimal values. Crystallites sizes and peak intensities have been found to decrease with the annealing temperature this has been attributed to the appearance of secondary phases. The optical spectra?s showed good homogeneity till 350°C annealing with oscillations but we found a critical temperature around 400°C with a decrease of oscillations and a change of band gap value before 1.5 eV as the other where above 1.5 eV. The absorption coefficient has been found in the range of 105 cm-1. To correlate these structural and optical observations we have investigate the dependence with the temperature of the AC and DC electrical properties where we found the influence of that 400°C critical point where we start to have semi-circle in the impedance spectra. We then study the electrical comportment of the film between 420 and 480°C.

V.P1.16
16:00
Authors : Anaïs Loubat, Dimitri Mercier, Muriel Bouttemy, Sofia Gaiaschi, Damien Aureau, Jackie Vigneron, Patrick Chapon, Arnaud Etcheberry
Affiliations : Institut Lavoisier de Versailles (ILV), UMR CNRS-UVSQ 8180, 45 avenue des Etats Unis, 78035 Versailles, France; Institut Lavoisier de Versailles (ILV), UMR CNRS-UVSQ 8180, 45 avenue des Etats Unis, 78035 Versailles, France; Institut Lavoisier de Versailles (ILV), UMR CNRS-UVSQ 8180, 45 avenue des Etats Unis, 78035 Versailles, France; HORIBA Jobin Yvon, 16 Rue du Canal, 91160 Longjumeau, France; Institut Lavoisier de Versailles (ILV), UMR CNRS-UVSQ 8180, 45 avenue des Etats Unis, 78035 Versailles, France; Institut Lavoisier de Versailles (ILV), UMR CNRS-UVSQ 8180, 45 avenue des Etats Unis, 78035 Versailles, France; HORIBA Jobin Yvon, 16 Rue du Canal, 91160 Longjumeau, France; Institut Lavoisier de Versailles (ILV), UMR CNRS-UVSQ 8180, 45 avenue des Etats Unis, 78035 Versailles, France

Resume : The CIGS (Cu(In,Ga)Se2) absorbers are among the most efficient in photo-conversion. As part of the manufacturing cycle in which they are involved, the preliminary steps of each surface are crucial for both the success of processes and the outcome of characterizations actions (eg. GDOES/XPS coupling). This contribution fits with performances improvement by asking the question of efficient deoxidation of surfaces. Chemical composition of surface and extreme surface is investigated thanks to XPS and nanoAuger characterizations. We particularly focused the study on the control of the surface chemistry (composition, contamination, doping) of CIGS absorber associated with KCN and HCl treatments. By crossing the high resolution XPS, X-AES and nanoAuger data, we are able to affirm that we reach a level of remarkable elimination of oxide. It allows a treatment of Ga3dIn4d region with an original and very reliable GGI measurement. This work, obtained on coevaporated CIGS with a GGI 0.3 and thickness 2.5 µm, reveals information about the CIGS "air aged" surface that highlights a phenomenon of oxidation involving In, Ga and Se elements while the Cu signal seems unaffected, indicating typical Cu poor surface. XPS study shows that it is possible to overcome the oxidation phenomenon with a slight HCl treatment. A subsequent small Se enrichment is observed but can be eliminated by additional classical KCN treatment, giving access to the spectroscopic signature of an absolute CIGS reference.

V.P1.17
16:00
Authors : Enrico Jarzembowski, Frank Syrowatka, Kai Kaufmann, Wolfgang Fränzel, Torsten Hölscher, Matthias Maiberg, and Roland Scheer
Affiliations : Institute of Physics, Martin-Luther-University Halle-Wittenberg, 06120 Halle, Germany, matthias.maiberg@physik.uni-halle.de

Resume : The recombination velocities at Cu(In,Ga)Se2/MoSe2/molybdenum interfaces are still not well determined and published values spread by orders of magnitude. How- ever, this back surface recombination may become detrimental for the solar cell per- formance, thus, making further investigations necessary. In our talk, we demonstrate that the interface recombination velocity at the rear contact can be determined by means of combined front and back surface time-resolved photoluminescence (TRPL).[1] The latter means a detachment of the Cu(In,Ga)Se2 layer and the measurement of the photoluminescence through the back side of the absorber. For absorbers, that have been processed without incorporation of alkali metals, a strong increase of the luminescence decay time is observed after removing the back contact. This indicates a high recombination at the Cu(In,Ga)Se2 /MoSe2 interface with a recombination ve- locity above 10^5 cm s^−1. Then, we show that a systematic incorporation of sodium by means of a post deposition process increases the front surface time-resolved pho- toluminescence, while the back surface TRPL is almost uninfluenced. Therefore, sodium does not seem to change the bulk recombination, but it may passivate the rear contact and reduces the recombination velocity below 10^2 cm s^−1 . This is also in accordance with an accumulation of Na found at the back side of the absorber layer by time-of-flight secondary-ion-mass-spectroscopy. [1] E. Jarzembowski, F. Syrowatka, K. Kaufmann, W. Fränzel, T. Hölscher, and R. Scheer, Applied Physics Letters 107, 051601 (2015).

V.P1.18
16:00
Authors : Thi Thu Trang Nguyen*, Hankyoul Moon*, Gee Yeong Kim*, William Jo*, JungYup Yang**, Junggyu Nam**, Dong Ho Lee**, Dongseop Kim**, Minsu Kwon***, Chan-Wook Jeon***, and Seokhyun Yoon*
Affiliations : *Department of Physics, Ewha Womans University, Seoul 120-750, Korea; **Photovoltaic Technology Team, Samsung SDI, Cheonan 331-300, Korea; ***Department of Chemical Engineering, Yeungnam University, Geyongsan 712-749, Korea

Resume : CuInGa(S,Se)2 (CIGSSe) has advantages as an absorber layer in solar cell thin film fabrication because of its low cost and high efficiency. In this presentation, we used Raman scattering spectroscopy to study CIGSSe thin films under various selenization/sulfurization annealing temperatures from 570 °C to 590 °C [1,2]. We observed the phonon modes of CIGSSe (188 cm-1), CIGS (287 cm-1) from the sample surfaces and a frequency shift of the CIGSSe peak due to the variation of Ga content with increased annealing temperature. We also studied spatial variation of thin films near surface and near CIGSSe/Mo interface regions that were cut by a dimpling method. We observed that the CIGSSe peak red shifted which is due to decreased Ga content near the absorber region. However, near CIGSSe/Mo interface, there was no frequency shift of the CIGSSe peak observed and the CIGS peak disappeared. Moreover, by observing the amount of secondary phase of Cu¬¬2-xSe, we suggest that the best material with intrinsic properties of the CIGSSe phase was the sample with annealing temperature of 580 °C. These results are completely consistent with local electrical measurements that show the best sulfurization temperature that resulted the highest efficiency of 15% is 580 °C [1]. [1] J. Y. Yang, D. Lee, K. S. Huh, S. J. Jung, J. W. Lee, H. C. Lee, D. H. Baek, B. J. Kim, D. Kim, J. Nam, G. Y. Kim, and W. Jo, RSC Advances 5, 40719 (2015). [2] J. Nam, Y. Kang, D. Lee, J. Yang, Y. –S. Kim, C. B. Mo, S. Park, D. Kim, Prog. Photovolt: Res. Appl. (2015) DOI: 10.1002/pip.2653.

V.P1.19
16:00
Authors : Shiro Nishiwaki, Thomas Feurer, Benjamin Bissig, Enrico Avancini, Romain Carron, Stephan Buecheler, Ayodhya N. Tiwari
Affiliations : Laboratory for Thin Films and Photovoltaics, Empa ‐ Swiss Federal Laboratories for Materials Science and Technology

Resume : To achieve high efficiency utilizing Cu(In,Ga)Se2 (CIGS) absorber layers prepared by thermal co-evaporation of elements in vacuum, careful control of Se supply during the process is mandatory. In our previous work, this was realized by the combination of in-situ monitoring of optical absorption of UV light by Se vapor and a valved Se source. Using this Se-flux controlling system further optimization for solar cell application has been attempted in this work. CIGS layers are prepared by a multi stage co-evaporation process with post deposition of NaF at low substrate temperature below 450 °C on soda-lime glass and polyimide. The devises with the structure substrate/Mo/CIGS/CdS/ZnO were fabricated and the solar cell properties were evaluated. It was revealed that the profile of the Ga/(In+Ga) composition ratio from the back contact to the front surface changed with the rate of Se-flux. This attributes to the dependence of Ga diffusion toward the growing front surface on the rate of Se flux. Despite the clear change in the grading of Ga/(In+Ga), the efficiency did not critically change. For the moment improved short circuit current density was observed. Microstructural and electrical characterization will be presented.

V.P1.20
16:00
Authors : V. Parvan1, A. Mizrak1, B. Ümsür1, W. Calvet1, A. Steigert1, I. Lauermann1, T. Dittrich1, D. Greiner1, C.A. Kaufmann1, and M. Lux-Steiner1,2
Affiliations : 1 Helmholtz-Zentrum Berlin, Hahn-Meitner-Platz 1, D-14109 Berlin, Germany; 2 Freie Universität Berlin, Department of Physics, Arnimallee 14, D-14195 Berlin, Germany

Resume : Cu(In,Ga)Se2 (CIGS) based thin film solar cells have recently exceeded an efficiency of 21 % which is due to a dedicated KF post deposition treatment (KF-PDT). However, an explanation for this behaviour on the atomistic scale is still missing. Therefore, we have investigated the interaction of various alkaline metals with the CIGS absorber in an in-situ approach combining physical vapour deposition (PVD) with surface photovoltage (SPV) and x-ray/ultraviolet photoemission spectroscopy (XPS/UPS). In this work we have deposited stepwise thin NaF, Na, and KF, K layers in the thickness regime up to a few Å on top of bare standard CIGS absorbers using effusion cells for NaF and KF and dispensers for Na and K. Between each deposition step we have analysed the samples with SPV and XPS/UPS yielding information on surface composition, energetics (work function and valence band maximum) and surface photo voltage as a function of film thickness. It turns out that pure Na has the strongest impact on the surface photovoltage, but only for very thin layers. Increasing the Na thickness leads to a more and more unstable photovoltage signal. For NaF and KF, the surface photovoltage is also increased, but on a lower level compared to the experiment with pure Na and the stability of the photovoltage signal is also improved. In all cases we have found a strong variation of the electronic properties with the film thickness indicating a distinct reactivity of the deposited material with the adjacent CIGS absorber.

V.P1.21
16:00
Authors : Cheul Ho Ha, Mingyang Zhu, Ho Young Jun, Si Ok Ryu*
Affiliations : School of Chemical Engineering, Yeungnam University, 280 Daehak-ro, Gyeongsan 712-749, South Korea

Resume : Processes for the fabrication of high-efficiency CuIn1-xGaxSe2 (CIGS) solar cell devices always include the selenization process with either excess H2Se gas or Se vapor to form a uniform CIGS thin films. Since those gases are very toxic and harmful to environment, CuIn1-xGaxSe2 (x=0~0.5) thin films were synthesized by using a modified spray process with Se powder, instead, and then CIGS solar cell was fabricated with CdS buffer layer deposited by both CBD and continuous flow reactor processes. Precursors were prepared with CuCl2, InCl3, GaCl3, selenourea. In order to improve the crystallization of films and to avoid their oxidation, the as-deposited CIGS thin films were selenized during the rapid thermal process with varying temperatures in the range of 250~580℃ under a nitrogen atmosphere. The fabricated devices were systematically characterized by various analytical instruments. XRD analysis was employed to identify the phase for obtained thin films and particles. TEM and SEM were used to provide the detail information for particle size, structural information and surface morphology respectively. XPS was used to evaluate the chemical composition and bonding of the thin films. Energy band gap was estimated by UV-vis spectroscopy. Morphologies, crystal structures, energy bandgaps of the films prepared in this study showed good enough physicochemical properties to be used in CIGS solar cell devices on the basis of analytical results.

V.P1.22
16:00
Authors : Erik Haubold (1), Philipp Schöppe (1), Stefanie Eckner (1), Sebastian Lehmann (2), Susan Schorr (3,4), Francesco di Benedetto (5), Ivan Colantoni (6), Francesco d’Acapito (7), Claudia S. Schnohr (1)
Affiliations : (1) Institut für Festkörperphysik, Friedrich-Schiller-Universität Jena, Max-Wien-Platz 1, 07743 Jena, Germany; (2) Solid State Physics and NanoLund, Lund University, P.O. Box 118, SE-221 00 Lund, Sweden; (3) Helmholtz-Zentrum Berlin für Materialien und Energie, Hahn-Meitner-Platz 1, 14109 Berlin, Germany; (4) Institut für Geologische Wissenschaften, Freie Universität Berlin, Malteserstr. 74-100, 12249 Berlin, Germany; (5) Dipartimento di Scienze della Terra, Università degli Studi di Firenze, Via La Pira 4, 50121 Firenze, Italy; (6) Department of Physics, University of Rome “Tor Vergata”, Via della Ricerca Scientifica 1, 00133 Roma, Italy; (7) CNR-IOM-OGG c/o ESRF LISA CRG, 71 Avenue des Martyrs, 38043 Grenoble, France

Resume : The Cu-poor phases Cu(In,Ga)3Se5 and Cu(In,Ga)5Se8 play an important role during the growth of high efficiency Cu(In,Ga)Se2 thin film solar cells. The local atomic arrangements of these materials may depend on both the In/Ga ratio and the Cu content and were shown to strongly influence the bandgap energy [1,2]. We have therefore studied the composition-dependent local atomic structure of Cu(In,Ga)Se2, Cu(In,Ga)3Se5 and Cu(In,Ga)5Se8 using X-ray absorption spectroscopy. Remarkably, the element-specific average Cu-Se, Ga-Se and In-Se bond lengths hardly change with decreasing Cu content despite clear differences in the crystallographic structure and a significant decrease of the unit cell volume. In contrast, the element-specific bond length variations strongly increase with decreasing Cu content due to the growing number of different local configurations present in the Cu-poor phases. Regarding the influence of the In/Ga ratio, all three phases show a strong change of the lattice constants and thus of the average group-III-Se distance. However, the element-specific Ga-Se and In-Se bond lengths are strikingly different from each other and remain nearly constant over the whole compositional range. The material is thus characterized by pronounced bond angle distortions and severe atomic displacements which affect important material properties including the bandgap energy. [1] Schnohr et al., Thin Solid Films 582, 356 (2015). [2] Eckner et al., Appl. Phys. Lett. 103, 081905 (2013).

V.P1.23
16:00
Authors : Ph. Schöppe(1), C. S. Schnohr(1), M. Oertel(1), S. Schönherr(1), E. Butz(1), A. Johannes(1), S. Eckner(1), M. Burghammer(2), G. Martínez-Criado(2), U. Reislöhner(1), C. Ronning(1)
Affiliations : (1 )Institut für Festkörperphysik, Friedrich-Schiller-Universität Jena, Max-Wien-Platz 1, D-07743 Jena, Germany; (2) European Synchrotron Radiation Facility, 6 rue Jules Horowitz, BP 220, F-38043 Grenoble Cedex, France

Resume : High-efficiency Cu(In,Ga)Se2 thin film solar cells are known to be inhomogeneous at various length scales. In order to unravel the impact of the inhomogeneity on the electrical properties there is a strong need for spatially resolved investigations. We introduce a new approach by measuring thin lamellas of Cu(In,Ga)Se2 cross sections via highly focused X-ray fluorescence analysis (XRF) [1]. This approach ensures high resolution compositional analysis combined with spatial resolution below 100 nm. As the typical grain size of the absorber is in the order of microns our approach easily allows the collection of information even from single grains and grain boundaries. We investigated several sequentially produced Cu(In,Ga)Se2 solar cells and observed that the temperature during the first selenization stage drastically influences the Ga depth profile. Furthermore, slight lateral variations of the Ga/(Ga In) ratio in the order of 0.01 could be detected. Additionally, we measured solar cells which were exposed to a post deposition treatment with potassium fluoride. For these samples the composition of some grain boundaries differs from the composition of the surrounding material. Most remarkable is a loss of Cu in those grain boundaries. Transmission electron microscopy was also performed on these lamellas in order to correlate the grain structure of the lamellas with the XRF data. [1] Ph. Schöppe et al., Appl. Phys. Lett. 106, 013909 (2015)

V.P1.24
16:00
Authors : M. Schuster, P. Sisterhenn, L. Graf, T.L. Nguyen, P.J. Wellmann
Affiliations : Materials Department 6 (i-MEET), Martensstr. 7, 91058 Erlangen, Germany, Friedrich-Alexander-Universität Erlangen-Nürnberg (FAU)

Resume : The objective of this work is the processing and characterization of a dense CuInSe2 solar-cell-absorber-layer based on nanoparticulate precursors. Bimetallic copper-indium- and elemental selenium-nanoparticles were synthesized by wet-chemical reduction and then dispersed in organic solvents as nano-inks. These inks were then printed to different layer-stacks on a molybdenum coated float-glass-substrate via doctor-blading. The temperature treatment to transform these layer-stacks into dense thin films was investigated, using face-to-face technique and mechanically applied pressure. The concentrations and solvents of the nano-inks are critical for closed and homogenous layer-stacks before the temperature treatment. Ink concentrations of 0.5 mol/l and toluene as solvent showed the best coverage of substrates. CuInS2 nanoparticles, synthesized by solvothermal reaction, were selenized to exchange S atoms with Se atoms and the resulting volume expansion helps the transfer of CuInS2 nanoparticle films to a dense CuInSe2 layer. All absorber layers were characterized with optical microscopy, SEM, EDX and XRD. Dense, coarse grained CuInSe2 layers with a thickness ≈ 7 µm were formed and the application of mechanical pressure shows potential to reduce thickness. The face-to-face-annealing ensured keeping a stoichiometric ratio of (Cu+In) / Se ≈ 1. For the S-Se-exchange a complete transformation from CuInS2 to CuInSe2 has been observed during selenization at 510°C for 10 minutes.

V.P1.25
16:00
Authors : K. Isowaki 1, T. Fukuyama 1, S. Kawamura 1, K. Kawasaki 1, T. Umehara 2, A. Yamada 2, N. Terada 1, 3
Affiliations : 1. Kagoshima University, Kagoshima, Kagoshima 890-0065, Japan; 2. Tokyo Institute of Technology, Meguro, Tokyo 152-2897, Japan; 3. Advanced Industrial Science and Technology, Tsukuba, Ibaraki 305-8568, Japan

Resume : Ag(In, Ga)Se2 [AIGS] is a promising wide band gap absorber for the top cell in the high-efficiency multi-junction cells. In this study, electronic structure of the Ga-rich AIGS and band alignment at the interface between the AIGS and CdS buffer by in-situ MBE have been studied by in-situ photoemission and inverse photoemission spectroscopy. AIGS films with an average Ga/(In Ga) of 0.88 were grown by 3-stage evaporation. The cells using CdS buffer and the identically grown AIGS exhibited a conversion efficiency about 7%. Se-capping layer was deposited on the AIGS for protecting the original nature. Prior to the analyses, the Se layer was removed by annealing in UHV, which yielded almost contamination-free nature. The decapped AIGS show Ag/(In Ga) of 0.26, Ga/(Ga In) of 0.83 and Se/(Ag In Ga) of 1.23, which is close to the Ag-deficient so-called OVC phase. The decapped surfaces show conduction band minimum CBM and valence band maximum VBM of 1.1 and -1.2 eV, respectively. The wide band gap energy is consistent with the Ag-deficiency. The formation of the interface results in a small downward band bending about 0.1 eV. CBM and VBM of the 40 nm thick CdS on the decapped AIGS are 0.4 and -2.2 eV respectively. From these values, we find a negative conduction band offset CBO of -0.6 eV. This serious cliff-type connection should be one of the main origins of the low performance of the CdS/AIGS-based cells. The impact of the post treatments on the band connection is to be discussed.

V.P1.26
16:00
Authors : K. Ueda, T. Maeda, T. Wada
Affiliations : Department of Materials Chemistry, Ryukoku University

Resume : Recently, we reported crystallographic and optical properties of CuInSe2, CuIn3Se5, and CuIn5Se8 phases in Cu-poor (1-x)Cu2Se-(x)In2Se3 pseudo-binary system with 0.5 ≤ x ≤ 1.0 [1]. The crystal structure of the sample changed from chalcopyrite-type CuInSe2 to hexagonal CuIn5Se8 through a stannite-type CuIn3Se5 with increasing x (decreasing Cu/In ratio). The band-gap energies of Cu-poor Cu-In-Se samples, i.e. CuIn3Se5 (1.17 eV) and CuIn5Se8 (1.22-1.24 eV), are larger than that of chalcopyrite-type CuInSe2 (0.99 eV). However, solid solution region of CuIn3(SxSe1-x)5 and CuGa3(SxSe1-x)5 systems and their electronic structures are not investigated in detail. In this study, we prepared CuIn3(S,Se)5 and CuGa3(S,Se)5 samples by a mechanochemical process and post-heating at 550 oC. We obtained the single-phase solid solutions with the stannite-type structure for CuIn3(SxSe1-x)5 (0.0 ≤ x ≤ 0.1) and for CuGa3(SxSe1-x)5 (0.0 ≤ x ≤ 1.0). The solid solution region of the CuGa3(SxSe1-x)5 system is much wider than that of the CuIn3(SxSe1-x)5 system. The band-gap energies of the CuGa3(SxSe1-x)5 samples linearly increase with increasing S content. Then, energy levels of the valence band maximum (VBM) were estimated from the ionization energies measured by photoemission yield spectroscopy (PYS). [1] T. Maeda, W. Gong and T. Wada, Jpn. J. Appl. Phys., submitted.

V.P1.27

Poster 1: CIGS solar cells : J. Sites, T. Margorian Friedlmeier
16:00
Authors : Mingqing Wang, Md. Anower Hossain, and Kwang-Leong Choy*
Affiliations : UCL Institute for Materials Discovery, University College London (UCL), Roberts Building, Malet Place, London WC1E 7JE, United Kingdom. Corresponding author’s email: k.choy@ucl.ac.uk

Resume : A novel and non-vacuum Electrostatic Spray Assisted Vapour Deposition (ESAVD) process has been developed as a complimentary method to deposit CIGS absorber layers for thin film solar cells in order to lower the cost of chalcogenide based solar cells [1-2]. During ESAVD process, the aerosol containing a mixture of chemical precursor is being charged and directed towards a heated substrate where it would undergo decomposition and chemical reaction to deposit a stable solid film onto the substrate [3]. ESAVD is a scalable process and it can be operated in open atmosphere. It is also very easy to be adapted for large area deposition with the deposition efficiency as high as 90% under optimised conditions. In our work, optimised CIGS absorber thin films by ESAVD method with high uniformity (≤ ±5%) have been achieved. The composition, purity and grain size of absorbers have significant influence on the device performance of the fabricated solar cells. The composition ratio and absorber thickness were optimized further based on the results of XRF, SEM, Raman, EDX, and photovoltaic properties of devices. The optimized solar cell with Cu/In+Ga= 0.78 and In/In+Ga=0.29 exhibited the best efficiency of 9.55% with Voc = 0.518V, jsc= 28.79 mA cm−2, and FF = 64.02%. The EQE bias ratio plot, the ratio of EQE measured at −1 and 0 V, [EQE(−1 V)/EQE(0V)], shows an increasing [EQE(−1 V)/EQE(0 V)] ratio with photon wavelength, especially at longer wavelength, suggesting a voltage-dependent collection efficiency which occurs in solar cells with shorter minority carrier diffusion length. Further improvement of films quality is crucial to obtain enhanced carrier collection efficiency in solar cells. Copper(Cu) deficient CIGS films were intentionally designed to avoid the dangerous KCN post-treatment step for the removal of the undesirable highly conducting minor phase of CuxSe. Subsequently, the as-deposited absorber was into aqueous NaCl solution prior to selenization in order to increase the grain size and p-type conductivity of the absorber. The SEM and XRD results confirmed the grain size increases and (112) orientation of the crystal in Na incorporated CIGS films. Photovoltaic results from J-V curve demonstrated that dipping in 0.2M NaCl for 20minutes resulted in an increased in Voc and jsc due to the enhanced grain size and p type conductivity, which showed the promising jsc, Voc, FF and η of the solar cell of 29.30mA/cm2, 0.564V,65.59% and 10.83%, respectively. References: [1] Mingqing Wang, Xianghui Hou, Junpeng Liu, KwangLeong Choy*, Paul Gibson, Elhamali Salem,Demosthenes Koutsogeorgis, and Wayne Cranton, Phys. Status Solidi A 212, No. 1, 72–75 (2015) [2] Md. Anower Hossain,‡ Mingqing Wang,‡ and Kwang-Leong Choy*, ACS Appl. Mater. Interfaces, 2015, 7 (40), pp 22497–22503 [3] K.L. Choy, Prog .Mater. Sci. 48 , 57-170(2003). Acknowledgements: This work has been funded by the European Union’s Seventh Framework Programme Scalenano, FP7/2007-2013 under grant agreement nº 284486.

V.P1.28
16:00
Authors : M. Wegner, F. Wilangowski, J. Bastek, R. Wuerz, N.A. Stolwijk
Affiliations : Institute of Materials Physics, WWU Münster, Wilhelm-Klemm-Straße 10, D-48149 Münster, Germany; Center for Solar Energy and Hydrogen Research, Baden Württemberg, Industriestraße 6, D-70565, Stuttgart, Germany

Resume : At present, very little is known about mechanisms and point defects governing diffusion on the Cu sub-lattice of Cu(In,Ga)Se2 thin films. Unfortunately, suitable copper radioisotopes (64Cu / 67Cu) exhibit very short half-life times and are not commercially available; thus, self-diffusion studies are almost impossible to conduct by standard radiotracer experiments. Chemically, Ag is closely related to Cu. Therefore, probing Ag solute diffusion may give rise to much desired information about relevant point defects on the Cu sub-lattice, which are assumed to control, e.g., Cd and Zn diffusion in Cu(In,Ga)Se2 thin films. Front-side diffusion studies were performed in a temperature range from 300 °C to 400 °C utilizing the 110mAg radioisotope (half-life ~ 250 d) and ion beam sputtering. The observed penetration profiles exhibit unexpected shapes with two distinct parts, a steep decay near the surface followed by a deep tail reaching into the CIGS-Mo interface. Apparently, the profiles are strongly affected by remnant surface activity prior to the sputtering process and the surface roughness of the sample (RRMS ~ 140 nm). Consequently, these parameters have to be carefully monitored and controlled in order to perform a meaningful analysis. Moreover, the anomalous shape of the profile tail may indicate trapping of mobile Ag atoms by crystal defects up to a fixed saturation level.

V.P1.29
16:00
Authors : P. Yang1, P. Reinhard2, B. Bissig2, E. Avancini2, T. Kunze1, E. Handick1, S. Buecheler2, R. G. Wilks1,3, A. N. Tiwari2, M. Bär1,3,4
Affiliations : 1 Renewable Energy, Helmholtz-Zentrum Berlin für Materialien und Energie GmbH, 14109 Berlin, Germany; 2 Laboratory for Thin Films and Photovoltaics, Empa-Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstr. 129, 8600 Duebendorf, Switzerland; 3 Energy Materials In-Situ Laboratory Berlin (EMIL), Helmholtz-Zentrum Berlin für Materialien und Energie GmbH, 12489 Berlin, Germany; 4 Institut für Physik und Chemie, Brandenburgische Technische Universität Cottbus-Senftenberg 03046 Cottbus, Germany;

Resume : Post-deposition treatments (PDT) of Cu(In,Ga)Se2 (“CIGSe”) absorber layers aiming at the controlled supply of alkalis as, e.g. sodium and potassium, have recently enabled fabrication of CIGSe devices with excellent performance,1-3 outperforming polycrystalline Si-wafer based solar cells. A NaF/KF PDT is observed to lead to significant modification of the CIGSe surface,1,2,4 giving raise to the assumption that the heterojunction formed with the CdS buffer layer is also affected. We have studied related buffer/absorber sample sets by x-ray photoelectron (XPS) and x-ray excited Auger (XAES) spectroscopy for which the type of PDT (NaF or NaF/KF) and CdS deposition time (i.e., the buffer thickness) was varied. While for the NaF PDT CIGSe we find the intensity of the absorber peaks to attenuate faster with CdS deposition time; for the NaF/KF PDT CIGSe the buffer-related photoemission line intensities increase faster indicating a different interface formation mechanism. This is confirmed by our finding that the chemical environment of selenium in the NaF/KF PDT CIGSe surface region is drastically changed upon CdS deposition with clear indications for the formation of Se-Cd bonds. In our contribution, we will discuss the pronounced impact of different PDTs on the chemical structure of the buffer/absorber interface and their consequence for the solar cell in detail. [1] P. Jackson et al.; Physica Status Solidi (RRL), 2015, 9, 28. [2] A. Chirila et al., Nature Materials, 2013, 12, 1107. [3] http://www.solar-frontier.com/eng/news/2015/C051171.html, last accessed Dec. 21, 2015. [4] E. Handick et al., ACS Appl. Mater. Interfaces, 2015, 7, 27414.

V.P1.30
16:00
Authors : Zheng Jie Ming,Tzu-Ying Lin, Chih-Huang Lai
Affiliations : Department of Materials Science and Engineering, National Tsing Hua University, Hsinchu 300, Taiwan

Resume : Cu(In,Ga)Se2 (CIGS) thin films are not only the highest potential for low-cost solar cell but also the most promising material for photovoltaics because of reaching similar efficiency to Si-based and direct band gap compare to the other kinds of solar cell The development of flexible photovoltaic devices is the future trend such as stainless steel because flexible substrates have several advantages such as lightweight ,flexibility and reduction the manufacturing cost of modules by roll-to-roll process Ga distribution in the CIGS absorber layer is important to improve CIGS solar cell efficiency However, for general process such as co-evaporation and selenization with metallic precursor processes , Ga will easily accumulate to the back site during CIGS deposition Inhomogeneous Ga distribution within CIGS absorbers would be the limitation of efficiency, and the Ga-grading control is complicated by co-evaporation and selenization with metallic precursor processes In this study we propose a promising way to fabricate Cu(In,Ga)Se2 (CIGS) on stainless steel substrate by using one-step sputtering from a quaternary target and co-sputtering by Ga2Se3 binary target to reduce the manufacturing cost of modules and precisely control the Ga profile in the absorber layer during the deposition We achieved that the one-step sputtering process from a CIGS quaternary target effectively mitigated the Ga segregation, and demonstrate an uniform distribution in lateral and planar direction. In addition, it is the first time that the Ga-grading of CIGS absorber by co-sputtering was proposed, and the preliminary results showed the 10.25% in conversion efficiency by the normal grading structure without post-selenization on the flexible stainless steel substrate

V.P1.31
16:00
Authors : Stephan J. Heise, J. F. López Salas
Affiliations : Laboratory for Chalcogenide Photovoltaics, Department of Energy and Semiconductor Research, University of Oldenburg, D-26111 Oldenburg, Germany

Resume : Time-resolved photoluminescence (TRPL) is a powerful tool for investigating the recombination dynamics in semiconductors. Many mechanisms may contribute to the PL decay characteristics, such as radiative band-to-band recombination, non-radiative Shockley-Read-Hall recombination, capture and re-emission of minority carriers via trap states, as well as separation of the generated electron-hole pairs by gradients in their electrochemical potentials or their conductivity. In CIGS thin film solar cells charge separation has been shown to dominate the TRPL signal at low injection levels in complete devices whereas the PL decay in CdS-covered absorbers seemed unaffected by charge separation and has been reported to equal that of the bare absorber layer. In this study we investigate the PL decay of complete cells, CdS-covered absorbers and bare absorbers as a function of injection level in two types of systems based on Cu(In,Ga)S2 and Cu(In,Ga)(S,Se)2, respectively. We show that for both systems the PL decay of not only the complete cell but also the CdS-covered absorber is dominated by charge separation at sufficiently low injection levels. In this injection regime the TRPL signal of the CdS-covered absorber significantly differs from that of the bare absorber whereas towards higher injection levels the influence of charge separation fades away.

V.P1.32
16:00
Authors : Chae-Woong Kim1,2, Hye Jin Kim1, Ki Lim Kim1, Jin Hyeok Kim2∗ and Chaehwan Jeong1,∗
Affiliations : 1 Applied Optics & Energy R&D Group, Korea Institute of Industrial Technology, 6 Cheomdan-gwagiro 208-gil, Buk-gu, Gwangju 500-480, Korea 2 Department of Material Science and Engineering, Chonnam National University,77 Yongbong-ro, Buk-gu, Gwangju 500-757, Korea

Resume : Thin film solar cells based on a Cu(In,Ga)Se2(CIGS) absorber layer have reached efficiencies of above 17.7% on flexible stainless steel(SLG) substrate. There is an increasing interest in the development of CIGS solar cells on the flexible substrates, for novel applications to space, buildings, and mobile due to their low cost, light weight, high specific power density, and excellent radiation hardness. From the manufacturing point of view, flexible substrates have an advantage in that roll- to-roll deposition can be used, which enables high throughput and cost reduction. Especially, the stainless steel foils with a potential as low-cost substrates were tested. The major issue with the use of stainless steel as a flexible substrate is the potential diffusion of detrimental impurities in the CIGS absorber. These impurities severely hamper the performance of CIGS thin film solar cells. Stainless steel is composed of Fe, Ni and Cr elements that can diffuse through Mo layers into CIGS absorbers as impurities. Previous reports mainly focused on the impact of Fe impurities in the CIGS layer. Fe atom is known to have a very detrimental effect on the absorber layer, which is dissolved in the bulk of CIGS grains. Ni atoms are the most detrimental impurities for the performance of CIGS solar cells, even at very small concentrations. It is noteworthy that these impurities induce defects deep within the band gap, which would lead to a reduction in the efficiencies of solar cells. In order to reduce absorber contamination by the diffusion of Fe, Ni and Cr impurities, barrier layers comprised of SiOx, Al2O3 or Cr have been deposited on metal substrates. These barrier layers are either expensive or need to be deposited with high thicknesses that effectively increase the cost of solar cells. In this study, ZnO layers were deposited on stainless steel substrate as diffusion barrier layer. The ZnO barrier layers were deposited by the same condition as i-ZnO layer, except for the thickness. The thickness of ZnO barrier layers were controlled at 50~200 nm. Even with a thin ZnO barrier diffusion layer (< 200nm), the diffusion of impurities from the substrate to the CIGS absorber is effectively reduced. The optimal ZnO diffusion barrier layer thickness (150 nm) resulted in an improvement in the efficiency from 5.9 to 10.7%. The 166 % increment in the efficiency of the CIGS solar cell is attributed to reduced diffusion of impurities into the CIGS layer, which is supported by GD-OES and DLTS analysis. The deposited films are basically characterized by scanning electron microscope (SEM), Raman spectroscopy, X-ray diffraction (XRD), X-ray Fluorescence (XRF), Glow Discharge-Optical Emission Spectrometer (GD-OES). And then, to complete the solar cells, a buffer layer of 50nm CdS was deposited by chemical bath deposition (CBD), followed by a double layer (high resistivity/low resistivity) of RF sputtered i-ZnO/Al-ZnO. The Al front contacts were deposited by thermal evaporator. No anti-reflection (AR) coating was applied. The photovoltaic properties of small area solar cells were characterized with I-V and quantum efficiency measurements.

V.P1.33
16:00
Authors : S. Levcenko1, H. Stange2, S.Brunken1, D. Greiner1, M. D. Heinemann1, C. A. Kaufmann1, S. S. Schmidt1, J. P. Bäcker1, R. Mainz1, and T. Unold1
Affiliations : 1Helmholtz-Zentrum Berlin für Materialien und Energie(HZB),Hahn-Meitner-Platz 1,D14109 Berlin, Germany 2Technische Universität Berlin, Institut für Werkstoffwissenschaften, 10587, Berlin, Germany

Resume : Efficiencies of Cu(In,Ga)Se2 thin film solar cells deposited by three-stage co-evaporation are improved by a recrystallization process coinciding with surface Cu-Se segregation at the stoichiometry point. To investigate the influence of the Cu composition on the electronic properties of CuInSe2 (CISe) in more detail, we produced samples with a lateral Cu-gradient including the recrystallization transition by interrupting co-evaporation during Cu-Se deposition. Combined photoluminescence (PL), time resolved photoluminescence (TRPL) and Raman nondestructive mapping of the thin films has been performed at room temperature on Cu graded areas of CISe films. Raman spectroscopy confirms presence of the Cu2-xSe films at the film surface in accordance with phase diagram. The characteristic A1 vibrational mode (at ~175cm-1) of the CISe shows no clear trends with Cu composition. PL measurements reveal the characteristic band edge emission at ~1.02eV and the defect band at ~ 0.9eV. PL mappings of the band edge emission properties (maximum PL, FWHM, PL yield) indicate a clear correlation with the Cu–gradient in the thin film.

V.P1.34
16:00
Authors : J. P. Teixeira (1), P. M. P. Salomé (2), R. A. Sousa (1), M. G. Sousa (1), A. F. da Cunha (1), P. A. Fernandes (1,3), S. Sadewasser (2) and J. P. Leitão (1)
Affiliations : (1) Departamento de Física and I3N, Universidade de Aveiro, Campus Universitário de Santiago, 3810-193 Aveiro, Portuga; (2) INL - International Iberian Nanotechnology Laboratory, Avenida Mestre José Veiga, 4715-330 Braga, Portugal; (3) Departamento de Física, Instituto Superior de Engenharia do Porto, Instituto Politécnico do Porto, Rua Dr. António Bernardino de Almeida 431, 4200-072 Porto, Portugal;

Resume : Due to recent efficiency improvements in thin-film photovoltaic (PV) technologies, Cu(In,Ga)Se2 (CIGS) and Cu2ZnSnS4 (CZTS) have received an increased attention as promising PV materials. Further improvement of the electrical performance of solar cells depends on the understanding of fundamental physical properties, namely, the electronic levels’ structure. Different models have been considered for the assignment of the radiative transitions in CIGS and CZTS, namely: donor acceptor pair recombination (DAP), quasi-DAP recombination (QDAP), and fluctuating potentials. In this work, we focus on CIGS and CZTS materials which have a high doping level and strong compensation. Thus, the radiative and non-radiative recombination channels are strongly influenced by electrostatic fluctuating potentials along the film. As a consequence, bound states for electrons do not occur for single donors but only for sufficiently large clusters of them. This behaviour is a quite different from that of acceptors: holes can bound to individual acceptor defects. Such discussion is sometimes discarded in the literature but of the utmost importance. Photoluminescence (PL) results for Cu-poor CIGS thin films are presented. The observed radiative transitions are discussed in the scope of the previous theoretical analysis. The DAP model is unable to explain the excitation power dependence of the PL. The influence of fluctuating potentials is shown and discussed.

V.P1.35
16:00
Authors : J. F. López Salas, Stephan J. Heise, Michael Richter, Viktor Gerliz, Maria S. Hammer, Jörg Ohland, Ingo Hammer-Riedel, Jürgen Parisi
Affiliations : All authors: Laboratory for Chalcogenide Photovoltaics, Energy and Semiconductor Research, Department of Physics, University of Oldenburg, 26129 Oldenburg, Germany

Resume : Cu(In,Ga)(S,Se)2 thin-film solar cells are known to show a metastable behavior of their open-circuit voltage when exposed to light. Time-resolved measurements of the photoluminescence decay after pulsed excitation (TRPL) reveal that also the PL decay changes with conditioning, yielding shorter effective lifetimes after annealing under illumination (light-soaking) than after annealing in the dark. However, the mechanisms behind this metastable behavior are not entirely understood yet. We developed simulations with Synopsys TCAD to reproduce the results of TRPL measurements. For this we used a model of capture and reemission of minority charge carriers via two characteristic trap states. It is proposed that the metastable conditions can be adequately described through the change in doping concentration as well as the activation energy and concentration of the trap states. These assumptions are backed up by measurements of admittance spectroscopy. The capture, reemission and recombination lifetimes of minority charge carriers are calculated and their contribution to the measured decay dynamics in TRPL is discussed.

V.P1.36
16:00
Authors : Aleksander Urbaniak, Małgorzata Igalson, Piotr Szaniawski, Marika Edoff
Affiliations : Faculty of Physics, Warsaw University of Technology, Koszykowa 75, PL 00 662 Warszawa, Poland; Faculty of Physics, Warsaw University of Technology, Koszykowa 75, PL 00 662 Warszawa, Poland; Ångström Solar Centre, Uppsala University, P.O. Box 534, SE-751 21, Uppsala, Sweden; Ångström Solar Centre, Uppsala University, P.O. Box 534, SE-751 21, Uppsala, Sweden

Resume : This work contributes to the discussion on defect levels in Cu(In,Ga)Se2 (CIGS) photovoltaic material. CuInSe2- and Cu(In,Ga)Se2- based Schottky junctions, solar cells and thin films with different Cu stoichiometry were investigated using complementary capacitance and current spectroscopic techniques. The diversity of existing interpretations concerning defects in CIGS material show that if a single, measurement technique is applied to CIGS solar cells, the results might be ambiguous. In the following study, we have extended the investigation to complementary spectroscopic techniques and to structures other than solar cells. As well as solar cells, Schottky junctions and CIGS thin films were investigated using admittance spectroscopy, deep level spectroscopy (DLTS) and photo-induced current transient spectroscopy (PICTS). Depending on the investigated structure and applied measurement technique, different signals can be revealed in Cu(In,Ga)Se2. In the present study, six different signals were separated, three of which were proposed to originate from bulk point defects- two electron traps and one deep, hole trap. The response from electron traps was common for all the investigated structures regardless of measurement technique used. We interpret it as a composite of two signals derived from bulk electron traps located in the vicinity of the Cu(In,Ga)Se2/CdS interface. The response from a hole trap was also common for the investigated structures but due to measurement limitation it was detected only by DLTS and in some cases PICTS. In case of the remaining, three signals we present arguments that their presence is rather the result of another mechanism than thermal emission from a point defect and discuss it in light of available literature models. Based on the DLTS spectra we have estimated the concentrations of discussed traps and concluded about existence of thin inversion layer in first few tens of nanometres of CIGS close to the CdS/CIGS interface. Correlation of the trap concentration with the Cu content in CIGS show the inverse dependence of the electron traps concentration on Cu/III ratio. On the other hand the concentration of the hole trap show no systematic depandance on the amount of Cu in the absorber.

V.P1.37
16:00
Authors : Marek Maciaszek, Pawel Zabierowski
Affiliations : Faculty of Physics, Warsaw University of Technology, Koszykowa 75, 00-662 Warszawa, Poland

Resume : Many characteristics of persistent photoconductivity effect in CIGS can be well explained by metastable properties of the (VSe-VCu) complex in the framework of Lany and Zunger model. However, explanation of large differences (even by factor >20) between magnitude of the PPC effect in different samples is problematic. Particularly large differences are observed between CIGS samples with and without sodium. In this contribution we analyze influence of deep defects which may influence on the magnitude of the PPC effect. A deep level of energy 0.2-0.3 eV was observed experimentally by AS and DLTS in Na free CIGS samples. By solving occupancy equations, we determine possible range of densities of (VSe-VCu) complexes and an additional defect that may explain experimental results. Basing on our calculations, only a deep defect situated close to the Fermi level can decrease magnitude of the PPC effect. Hence, observed defect can be a good candidate. Moreover, obtained results suggest that an additional defect is a donor. To verify this supposition, we analyze character of DLTS signal observed in CIGS sample without sodium.

V.P1.38
18:00 Innovation Highway: Breakthrough Milestones & Key Developments in Chalcopyrite PV until 20:00
Start atSubject View AllNum.Add

Light management : R. Menozzi, M. Maiberg
08:30
Authors : J. Krc, M. Sever, A. Campa, Z. Lokar, B. Lipovsek, and M. Topic
Affiliations : University of Ljubljana, Faculty of Electrical Engineering Trzaska 25, 1000 Ljubljana, Slovenia

Resume : Chalcogenide absorbers in thin-film solar cells render relatively high optical absorption of solar spectrum up to the photon energy determined by the absorber bandgap. By using sufficiently thick absorbers (> 1 um) the main concern related to light management is, in this case, decreasing optical losses in front layers (new electrode and window materials) and minimising reflectances at front interfaces (antireflecting nanostructures). When thinning down absorber layer thicknesses d < 0.5 um (ultra-thin devices), a highly reflective back reflector in combination with light scattering nano/micro structures have to be introduced. In this contribution we will make a short overview of main existing solutions of light confinement in different types of chalcogenide solar cells (CIGS, CdTe, CZTS). In the main part of the contribution we will present the results of advanced optical modelling, verified with selected realistic cases, which enables us to: - quantify optical loses in chalcogenide solar cells when thinning down absorber layers to ultra-thin devices - show the potential gains in photocurrent related to introduction of different light scattering and anti-reflective nanostructures (periodic and random) at different positions in solar cell and in combination with highly reflective back reflectors - show possibilities for tandem devices, such as combinations of chalcogenides with perovskite solar cell.

V.II.1
09:00
Authors : F. Mollica1, M. Jubault1, F. Donsanti1, A. Loubat2, M. Bouttemy2, J. Vigneron2, A. Etcheberry2, N. Naghavi1
Affiliations : 1 Institute of Research and Development on Photovoltaic Energy (IRDEP) EDF – UMR 7174 CNRS – Chimie ParisTech, IPVF, 6 quai Watier, 78400 Chatou, France; 2 Lavoisier Institute of Versailles (ILV), UMR 8180 CNRS – UVSQ, IPVF, 45 avenue des Etats Unis, 78035 Versailles, France;

Resume : CIGS-based solar cell including an ultra-thin absorber layer (below 500 nm) gives an opportunity to reduce the deposition time as well as material consumption. As already reported, we can observe a drop in cell efficiency when the CIGS layer thickness decreases, predominately due to a decrease of Jsc. As this is caused by an incomplete absorption of light and a sharpened impact of the interfaces, a rear interface developed to reflect the remaining light and to readily collect majority carriers can improve the cell efficiency. In this work we analyze the potential of replacing the molybdenum back contact with a Transparent Conducting Oxide (TCO) coupled with reflectors. We have simulated the CIGS absorption with a Ray Transfer Matrix calculation method. The current density of 300-nm-thick-CIGS cell is improved up to 4 mA/cm² on a TCO back contact coupled with a Lambertian reflector. The Jsc improvement is also presented with various structures. Based on these results, solar cells with a thin coevaporated CIGS layer on ZnO:Al and SnO2:F substrates were fabricated. The difficulty to adjust the amount of Na in CIGS, which has to be externally supplied, and the impact of growth temperature will be discussed. An analysis of the CIGS/TCO interface is made, based on the interface composition, contact resistance and recombination characterization. Finally, we report in this work higher efficiency of 450 nm CIGS cells on SnO2:F/mirror (10.6%) than on Mo (9.6%).

V.II.2
09:15
Authors : R. Carron 1, E. Avancini 1, B. Bissig 1, P. A. Losio 2, B. Ruhstaller 2, J. Steinhauser 1, S. Buecheler 1, A. Tiwari 1
Affiliations : 1 Laboratory for Thin films and Photovoltaics, Empa, Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstrasse 129, 8600 Dübendorf, Switzerland 2 Institute of Computational Physics, Zurich University of Applied Sciences (ZHAW), Technikumstr. 9, 8401 Winterthur, Switzerland

Resume : Decoupling of the effects of optical and collection losses in solar cells based on graded Cu(In,Ga)Se2 (CIGS) absorber can be achieved by numerical simulation methods. However, accurate measurements of the complex refractive indices of the different layers of the solar cell structure are essential to calculate the light propagation and charge carrier generation in the absorber. In this contribution, we report spectra for the complex refractive indices of Mo, MoSe, CIGS, CdS, intrinsic and aluminum-doped ZnO, and MgF layers. Data from several characterization techniques, such as ellipsometry, optical reflectance and transmittance, AFM, SEM, and profilometry measurements, are combined. To account for gradings and changes in absorber composition, CIGS layers with different [Cu]/([In]+[Ga]) (CGI) and [Ga]/([In]+[Ga]) (GGI) compositions were grown by co-evaporation on Mo coated glasses to ensure comparable growth conditions as for actual devices. Discrepancies between our results and literature data are discussed. Comparison of the computed light absorption spectra of CIGS absorber layers with the corresponding device quantum efficiency measurements allows to differentiate effects of optical and collection losses. Based on this analysis, we suggest possibilities to improve cell performance in the near-infrared range.

V.II.3
09:30
Authors : Shu-Yi Li, Carl Hägglund, Yi Ren, Jonathan J. S. Scragg, Jes Larsen, Christopher Frisk, Katharina Rudisch, Sven Englund and Charlotte Platzer-Björkman
Affiliations : Ångström Solar Center, Solid State Electronics, Uppsala University, Sweden

Resume : The optical properties (i.e., dielectric functions, absorption coefficients and bandgap) of 500 nm and 800 nm-thick Cu2ZnSnS4 absorbers grown by reactive sputtering on bare and Mo-coated soda-lime glass (SLG) were determined using spectroscopic ellipsometry (SE) and spectrophotometry. X-ray fluorescence, X-ray photoelectron spectroscopy depth profiling, X-ray diffraction, Raman spectroscopy, scanning-electron microscopy and atomic force microscopy measurements were performed to characterize the composition, crystal structure, phase purity and morphology. The ensuing sample characteristics were utilized in SE analysis for the establishment of a multilayer stack optical model and the dielectric functions and refractive indices were determined. The SE-derived absorption coefficients from CZTS/SLG samples were compared with those derived from complementary spectrophotometry measurements and found to be in good agreement. The bandgap determined from Tauc plots was Eg =1.57±0.02 eV. The absorption coefficients with moderate sub-band tailing were found to be a few 10^4 cm^{-1} just above the bandgap and exceeding 10^5 cm^{-1} at energies above ~2.5 eV. Separate device characterization performed on identical samples showed that the optical properties determined in this work can be linked to 2.8% and 5.3% to the 500 nm and 800 nm-thick samples featured in this study. The same studies on the Cu2ZnSn(S,Se)4 samples are in progress.

V.II.4
09:45
Authors : F.Pattini, E. Gilioli, F. Bissoli, M. Bronzoni, M. Calicchio, N. Cavallari, R. Fornari, E. Gombia, A. Kingma, M. Mazzer, S. Rampino
Affiliations : IMEM-CNR, Parma, ITALY; University of Parma, Dept. of Physics and Earth Sciences, Parma, ITALY; Delft University of Technology, Delft, The Netherlands

Resume : Although the photovoltaic (PV) market is still dominated by the Si-based solar cells, thin film technology is considered to be a viable solution, in particular for unconventional applications such as flexible, transparent or bifacial solar cells, which represent an great opportunity in the field of the integrated PV (BIPV). Cu(In,Ga)Se2 (CIGS) represents a good compromise between conversion efficiency, stability and possibility to be grown on different substrates therefore is considered to be the most promising material for thin-film PV. We report on the fabrication of CIGS-based bifacial thin film solar cells by means of the Pulsed Electron Deposition (PED) technique, using transparent substrates (glass) and back contacts (based on In2O3:Sn, ITO). In the last years, PED has been developed at IMEM-CNR [1-2] for high-quality CIGS deposition; recently, small solar cells with PV efficiency exceeding 17% have been obtained by controlling the absorber doping and by optimizing the cell architecture and the device processing [3]. Interestingly, high-quality CIGS absorber layers can be deposited at much lower temperature (250-270°C) compared to alternative techniques, enabling the use of a large number of substrates, including polymeric thermo-labile ones. This makes the PED a very effective method to grow “complex” materials and to explore unconventional devices, such as flexible or transparent solar cells. The studied cells have the typical bifacial configuration [4]: substrate (glass)/back contact (ITO, by sputtering)/absorber (CIGS, by PED)/buffer layer (CdS, by CBD)/front contact (ZnO-ZnO:Al, by sputtering). We will report on the performance of PV cells with a total exceeding 10% of efficiency and significantly higher than recently published results [5] under different types of illumination (direct, diffused, back reflected) for thick and thin CIGS layers. REFERENCES: [1] S Rampino et al., “15% efficient Cu (In, Ga) Se2 solar cells obtained by low-temperature pulsed electron deposition”, Applied Physics Letters, vol. 101, p. 132107, 2012 [2] S Rampino et al., “Low-temperature growth of single-crystal Cu(In,Ga)Se2 films by PED technique”, Solar Energy Materials and Solar Cells vol. 133, pp. 82-86, 2014 [3] M. Mazzer et al. submitted [4] T. Nakada et al., “Novel device structure for Cu(In,Ga)Se2 thin film solar cells using transparent conducting oxide back and front contacts”, Solar Energy, vol. 77, pp. 739–747, 2004 [5] S. H. Moon et al., “Printable, wide band-gap chalcopyrite thin films for power generating window applications”, Scientific Report, vol. 4, p. 4408, 2014

V.II.5
10:00 Coffee break

Device characterization and modeling : J. Krc, F. Pattini
10:30
Authors : Giovanna Sozzi, Simone Di Napoli, Roberto Menozzi
Affiliations : Department of Information Engineering, University of Parma Parco Area delle Scienze 181A 43124 Parma, Italy

Resume : Over the last few years, the development of ever more efficient thin-film chalcogenide solar cells has been steady, in spite of incomplete understanding of the physical mechanisms that determine and limit the cell’s performance. However, keeping the pace of efficiency improvement above the recently overcome 20% barrier toward 25% and beyond will likely require increased support from device-level physical modeling. 1D numerical modeling has been routinely used for many years and proven to be a valuable tool, especially for c-Si and III-V cells. Thin-film chalcogenide cells, however, have peculiarities that make 1D modeling inadequate in some respects: the effect of grain boundaries, for example, is a typical 3D effect, that can be treated with a 2D model but clearly eludes a 1D approach. In addition to that, the use of patterned front- or back-side passivation layers with point contact openings to reduce the negative effect of defective interfaces requires 2D/3D models for optimum choice of the contact layout. The aim of this paper is to give an overview of results of 2D/3D numerical simulation of thin-film chalcogenide cells including dark I-V curves, C-V curves, and illuminated characteristics; the role of defects, whether in the grain interior, at the grain boundaries, or at heterointerfaces, will be specifically addressed, together with the use of passivation and point contacts to mitigate the impact of defective surfaces.

V.III.1
11:00
Authors : Tetiana Lavrenko, Thomas Walter; Torsten Hoelscher, Roland Scheer
Affiliations : Ulm University of Applied Sciences, Albert-Einstein-Allee 55, 89081 Ulm, Germany; Martin-Luther-University Halle-Wittenberg, von-Danckelmann-Platz 3, 06120 Halle (Saale), Germany

Resume : A sulfur incorporation into the surface of sequentially grown Cu(In,Ga)(Se,S)2 absorbers is one of the approaches to optimize the efficiency of these devices. A sulfur gradient widens the bandgap in the space charge region without a significant impact on the bandgap in the bulk. As a result, a separation of the recombination and absorption processes takes place which leads to an improved open circuit voltage without a loss in the short circuit current. The question which is still open, and therefore will be addressed in this contribution, is an impact of the sulfur gradient on the minority carrier lifetimes in the absorber. In this work, solar cells with different sulfur gradients have been investigated. Photoluminescence decay measurements have been performed to study carrier dynamics and recombination mechanisms. Since the interpretation of these results is not straightforward, the temperature-dependent measurements of transient photoluminescence and current-voltage characteristics of these devices will be correlated in order to build a relevant recombination model to extract minority carrier lifetimes. Experimental results will be supported by simulations. Furthermore, the impact of a front grading on the temperature- and intensity-dependence of transient photoluminescence with respect to different sulfur contents will be discussed in terms of carrier trapping and re-emission.

V.III.2
11:15
Authors : Dario Cozza, Carmen M. Ruiz, D. Duché, J.J. Simon and L. Escoubas
Affiliations : Aix Marseille Université, CNRS, IM2NP UMR 7334, 13397, Marseille, France

Resume : Kesterite based photovoltaics is a promising thin film technology with the potential of future large scale production: Cu2ZnSnSe4 absorbers are made of cheap/earth-abundant elements and present optimal band gaps for solar cells (between 1 and 1.5 eV). Devices with efficiency higher than 11% have been demonstrated by different groups. Significant VOC deficit limits the performances of kesterite solar cells and the causes for this issue have not been clearly identified yet. Among the possible sources of VOC loss, some studies in literature suggested that the Grain Boundaries (GBs) inside the polycrystalline absorber can play a dominant role. We employ 2D modeling and the software Silvaco® to perform electrical simulations of Cu2ZnSnSe4 solar cells structures including GBs inside the absorber and a MoSe2 layer between the absorber and the Mo back contact. The GBs are modeled as thin vertical stripes presenting different properties and physical mechanisms than the surrounding Intra-Grain kesterite: lower bandgaps, higher recombination, presence of static charges (positive or negative) and n-conductivity: these conditions are considered both independently and combined. The analysis of the results gives an insight about the possible correlations between the electrical activity of GBs and their impact on the performances of the device. Experimental KPFM measurements and JV curves of real samples are showed to interpret and motivate our theoretical findings.

V.III.3
11:30
Authors : Matthias Maiberg, Torsten Hölscher, Setareh-Zahedi Azad, Stefan Hartnauer, Wolfgang Fränzel, and Roland Scheer
Affiliations : Institute of Physics, Martin-Luther-University Halle-Wittenberg, 06120 Halle, Germany, matthias.maiberg@physik.uni-halle.de

Resume : The decay of the room-temperature time-resolved photoluminescence (TRPL) on thin-film semiconductors such as Cu(In,Ga)Se2 and Cu2ZnSnSe4 often is bi- exponential. This is often traced back either to fluctuations of the electrostatic potential or to minority charge carrier trapping. We show by means of simulations that both effects can be discriminated by a measurement of the TRPL decay at different excitation intensities and temperatures.[1,2] A requisite is that the samples are stable under light exposure which is not always the case. Application of the standard semiconductor theory yields, that the bi-exponential photoluminescence decay in Cu(In,Ga)Se2 and Cu2ZnSnSe4 must result from a strong minority carrier trapping. By simulation of experimental TRPL decay curves we can determine the minority carrier lifetime, the trap energy, the trap density, and the doping density of these materials with values in the ranges of 1 − 10 ns, 200 meV, 10^15 − 10^16 cm^−3 , and 10^15 − 10^16 cm^−3 .[3,4] These yield reasonable solar cell parameters and they also explain the non-correlation of the open-circuit voltage and the luminescence decay time found by our and other groups. [1] M. Maiberg, T. Hölscher, S. Zahedi-Azad, and R. Scheer, Journal of Applied Physics 118, 105701 (2015). [2] M. Maiberg, F. Bertram, and R. Scheer, Journal of Applied Physics (2015), submitted. [3] M. Maiberg, T. Hölscher, S. Zahedi-Azad, W. Fränzel, and R. Scheer, Applied Physics Letters 107, 122104 (2015). [4] M. Maiberg, T. Hölscher, S. Hartnauer, W. Fränzel, and R. Scheer, Applied Physics Letters (2015), submitted.

V.III.4
11:45
Authors : Michael Richter, Maria Hammer, Jürgen Parisi
Affiliations : Laboratory for Chalcogenide Photovoltaics (LCP), Energy and Semiconductor Research Laboratory, University of Oldenburg, Carl-von-Ossietzky-Strasse 9-11, 26129 Oldenburg, Germany

Resume : Quantum efficiency measurements on Cu(In,Ga)Se2 (CIGS) solar cells are widely used as a non-destructive and easy to use method to extract the bandgap of the CIGS absorber layer. Information about the bandgap is of major relevance, e.g., for process control or parameter definition in device simulations. However, determining the bandgap from quantum efficiency measurements bear on the assumption that the quantum efficiency is solely given by the absorption of a homogeneous absorber layer. We therefore compared different bandgap extraction models on CIGS solar cells with different diffusion length, thus different bulk recombination properties, and with different bandgap grading profiles. The extracted minimum bandgap value is compared to that calculated from the composition measured with glow discharge optical emission spectroscopy. To study the effects of limited diffusion and grading in more detail, we created a one-dimensional optical simulation tool that calculates the optics by means of the generalized transfer matrix method. The tool includes models to account for roughness, thickness non-uniformity and graded layers. The quantum efficiency is given by the local generation rate multiplied with a local collection probability. The latter is a function of the diffusion length of the absorber material. We found that bandgap values that are extracted from layers with a bandgap gradient are overestimated by up to 200 meV depending on the slope of the grading. In contrast to this, the influence of the diffusion length on the extracted bandgap is negligible.

V.III.5
12:00 Lunch break

Novel materials and structural aspects in kesterites : R. Carron, M. Richter
13:30
Authors : Stephan Lany, Pawel Zawadzki, Adam Welch, Lauryn L. Baranowski, Andriy Zakutayev
Affiliations : National Renewable Energy Laboratory, Golden, CO 80401, USA

Resume : Increasing the chemical complexity of zinc-blende derived semiconductors through elemental substitution on the cation lattice has been a long-standing design principle for generating new candidate materials for photovoltaics. We have recently investigated the role of cation disorder in Cu2SnS3, Cu2ZnSnS4, and other zinc-blende derived materials using both theory and experiment. The underlying motif-based Hamiltonian goes beyond the conventional theoretical point defect model, and allows for performing Monte-Carlo simulations to create realistic models of disordered structures. The application of this model to stoichiometric phases has revealed an entropy-driven nano-clustering with impact on photovoltaics by the resulting potential fluctuations and band-gap variations [1], as supported by the experiments [2]. In case of off-stoichiometric materials, the disorder can dramatically impact the doping properties through the formation of extended anti-site defects with up to 1 eV lower formation energies compared to the conventional point defects [3], consistent with experimental observations [4]. The lessons learned from the disorder studies point towards those materials where disorder is suppressed by a high energy cost for formation of non-ground-state motifs, which, notably is the case in the chalcopyrites. However, a similar effect can be achieved in non-tetrahedral ternary compounds, where the disorder is suppressed by a different coordination environment of the cation. As an example of this class of materials, we considered CuSbS2 [5] and CuSbSe2 [6], and demonstrated the development of a solar cell with almost 5% efficiency within an unusually short time scale of less than 2 years. [1] P. Zawadzki et al Phys. Rev. Appl. 3, 034007 (2015). [2] L. L. Baranowski et al Phys. Rev. Appl. 4, 044017 (2015) [3] P. Zawadzki et al Phys. Rev. B 92, 201204(R) (2015). [4] L. L. Baranowski et al Chem. Mater., 26, 4951 (2014) [5] A.W. Welch et al Sol. En. Mat. So. Cel. 132, 499 (2015) [6] A.W. Welch et al Appl. Phys. Express 8, 082301 (2015).

V.IV.1
13:45
Authors : Rongzhen Chen, Clas Persson
Affiliations : Department of Materials Science and Engineering, Royal Institute of Technology, Stockholm, SE–100 44, Sweden; Department of Materials Science and Engineering, Royal Institute of Technology, Stockholm, SE–100 44, Sweden, Department of Physics, University of Oslo, P.Box 1048 Blindern, NO–0316 Oslo, Norway

Resume : The chalcopyrite Cu(In,Ga)Se2 alloy is today a rather well-established compound for thin film solar cells. Emerging Cu-based materials are explored to benefit from the energetically high-lying Cu d-state in combination with low effective mass of the minority carriers. In the present study, we explore the details in the optical properties of emerging Cu-based compounds, like for instance Cu2ZnSn(S,Se)4, Cu2SnS3, Cu(Sb,Bi)(S,Se)2, and Cu3(Sb,Bi)(S,Se)3, employing the Heyd-Scuseria-Ernzerhof (HSE06) hybrid functional. We calculate the electronic structure and we analyze the optical properties in terms of the dielectric functions and absorption coefficients. By modeling the quantum efficiency of the compounds, we further discuss the optical response. The results help to understand fundamental physics of then emerging Cu-based materials in order to design and optimize solar cell devices. Refs.: R. Chen and C. Persson, J. Appl. Phys. 112, 103708 (2012); ibid, Thin Solid Films 519, 7503 (2011); M. Kumar and C. Persson, Appl. Phys. Lett. 102, 062109 (2013); ibid Energy Procedia 44, 176 (2014); S.G. Choi, et al., Appl. Phys. Lett. 101, 261903 (2012).

V.IV.2
14:00
Authors : T. Maeda, C. Zhao, A. Kai, T. Wada
Affiliations : Department of Materials Chemistry, Ryukoku University

Resume : Recently, we reported the first-principles study on alkali-metal effect of Li, Na, and K in CuInSe2 (CISe) and CuGaSe2 (CGSe) [1]. The substitution energies of Li atom for Cu (LiCu) atom in these compounds are much lower than those of NaCu and KCu atoms in CISe and CGSe. Therefore, we predicted that a large amount of Li atoms can substitute for the Cu atom in CISe and CGSe. However, there is a few report on the lithium effect on the crystallographic and optical properties of CISe and CGSe. In 1992, German group reported the phase diagram of CuInSe2-LiInSe2 system [2]. The crystal structure changes from chalcopyrite-type CuInSe2 to NaFeO2-type LiInSe2. In this study, we prepared (Cu,Li)InS2 and (Cu,Li)GaS2 samples by a mechanochemical process and post-heating at 550 oC. We obtained the single-phase (Cu1-xLix)InS2 solid solutions with for (0.0 ≤ x ≤ 0.15) and (Cu1-xLix)GaS2 solid solutions for (0.0 ≤ x ≤ 0.30). The band-gap energies of the (Cu,Li)InS2 and (Cu,Li)GaS2 samples linearly increase with increasing Li content. The energy level of the valence band maximum (VBM) were estimated from the ionization energies measured by photoemission yield spectroscopy (PYS). [1] T. Maeda, A. Kawabata, and T. Wada, Jpn. J. Appl. Phys., 54, 08KC20 (2015). [2] U.-C. Boehnke and H. Neumann, and G. Kühn, J. Alloys Compounds 190, L17-L18 (1992).

V.IV.3
14:15
Authors : R. Kondrotas(1), S. Giraldo(1), M. Neuschitzer(1), M. Colina(1), F. Oliva(1), Y. Sánchez(1), X. Alcobé(2), P. Pistor(1), V. Izquierdo-Roca(1), A. Pérez-Rodriguez(1,3), E. Saucedo(1)
Affiliations : (1) Catalonian Institute for Energy Research (IREC), Jardin de les Dones de Negre 1, 08930, Sant Adrià de Besòs, Spain; (2) Centres Científics i Tecnològics de la Universitat de Barcelona (CCiTUB), LLuís Solé i Sabarís 1-3, 08028, Barcelona, Spain; (3) Departament de Electrònica (IN2UB), Universitat de Barcelona, Martí i Franquès 1, 08028, Barcelona, Spain Address line 2, postcode, Country

Resume : Zinc-blende CuZnIn(Se,S)3 compounds have been identified as promising materials for optoeletronic devices based on their excellent luminescent properties, and working solar cells have already been reported. In this work, we have synthesized CuZnInSe3 by a two-step process: sputtering of metallic precursors and subsequent selenization in Se atmosphere. The crystal structure of the resulting thin films was proven to be cubic and of the zinc-blende type. Solar cells using CuZnInSe3 as absorber were fabricated following standard procedures of back contact and front-end termination as commonly implemented in kesterite and CIGS thin film technologies. In order to investigate the influence of composition, mainly the Cu content, CuZnInSe3 samples were prepared from Cu-poor (Cu/Zn+In =0.3) to slightly Cu-rich (Cu/Zn+In=0.53) compositions. This variation resulted in a change of the band gap from 1.16 to 1.32 eV. A first optimization showed that the performance of CuZnInSe3 solar cells depends slightly on the temperature of the first of the two stages during selenization and - strongly - on composition. Solar cells with high Cu deficiency show very high VOC (up to 560 mV), whereas devices with only slightly Cu-poor composition exhibited higher fill factors and power conversion efficiencies (PCE). The characteristics of the best solar cell device were: VOC=520 mV, JSC=22.6 mA/cm2, FF=64%, and PCE=7.6 %, which, to our knowledge, is the highest efficiency reported for this material so far.

V.IV.4
14:30
Authors : Jarvist Moore Frost, Suzanne Wallace, Aron Walsh
Affiliations : University of Bath, United Kingdom

Resume : Copper Zinc Tin Sulphide (CZTS, Cu2ZnSnS4) is a promising earth-abundant thin film photovoltaic material. Current devices have disappointing open circuit voltages considering the band gap of the material. At open circuit all charges are recombining; the open circuit voltage is set by the degree of recombination. From studies of the photoluminescence, there appears to be significant band-gap tailing even in high quality bulk CZTS material. Independent of the source of disorder, the device physics are particularly affected due to the low dielectric constant of this material. In this work we combine electronic structure calculations with different representations of disorder. We write custom Monte Carlo codes to simulate both substitutional disorder; and sample positional disorder with both molecular dynamics and lattice dynamics (phonons). With these models of disorder we simulate the band tailing observed in bulk material, and estimate its effect on the device physics, and predict what experimental observables would agree with the different models.

V.IV.5
14:45
Authors : Erik Ahlswede (ZSW); Michael Wolfstädter (ZSW); Thomas Schnabel (ZSW); Michael Hetterich (KIT)
Affiliations : ZSW: Zentrum für Sonnenenergie- und Wasserstoff-Forschung Baden-Württemberg KIT: Intstitute of Applied Physics, Karlsruhe Institute of Technology (KIT)

Resume : Absorbers made from the kesterite material Cu2ZnSn(S,Se)4 have gained interest as low-cost alternative to Cu(In,Ga)Se2 for high-efficiency thin-film solar cells. One of the major ongoing research topics in kesterites is the investigation of possible disorder amongst the Cu+ and Zn2+ cations within the Cu/Zn crystal lattice planes and its influence on material properties. The degree of disorder can be influenced by thermal treatment at different temperatures and the rate of subsequent cooling. It is typically determined in an indirect way by changes in the optical band gap of the material. Following few publications on the impact of disorder on the absorber layer itself, we present experimental results on cyclic changes between the ordered and disordered state and its direct effect on complete solar cells. We compare samples that we firstly ordered or disordered, respectively, and then repeated two additional cycles of alternate ordering or disordering. The processes were done both on pure absorber layers on Mo substrates and complete cell stacks simultaneously. In addition, after each step parts of the pure absorber samples were finalized to complete cells as well. Hence, we could compare the influence of ordering effects in the absorber layer and thermally induced changes in the interface between absorber and CdS buffer layer. The results indicate locally different behavior but a general trend for Voc that follows directly Egap and is normally improved after an ordering step. Nevertheless all cell parameters are degrading with cyclical annealing steps. Further details on layer and cell properties will be discussed.

V.IV.6
15:00
Authors : Susan Schorr, Galina Gurieva, Laura Elisa Valle Rios, Kai Neldner
Affiliations : Helmholtz-Zentrum Berlin for Materials and Energy, Department Structure and Dynamics of Energy Materials Freie Universitaet Berlin, Department of Geosciences

Resume : Understanding of the interplay between structural, chemical and electronic properties of kesterite type compound semiconductors, applied as absorber in PV devices, can give crucial informations aiding continuous improvement of device efficiencies. These absorber layers exhibit in general an off-stoichiometric composition. The presence of secondary phases and deep defect levels caused by intrinsic point defects are efficiency limiting factors. The kesterite type structure can be described by a stacking sequence of cation layerd Cu/Sn-Cu/Zn - Sn/Cu-Cu/Zn-Cu/Sn perpendicular to the crystallographic c-axis. An off-stoichiometric composition originates from the prospensity of the structure to stabilize defects, charge balancees beeing commonly insured by appropriate cationic substitutions forming anti-sites, vacancies or interstitials. This study reports a detailed crystallographic investigation of cationic point defects in off-stoichiometric Cu2ZnSnS4 and Cu2ZnSnSe4, based on powder sample series synthesized by solid state reaction. Due to the isoelectronic character of Cu+ and Zn2+ it is necessary to apply neutron diffraction to investigate the distribution of the 3 cations on the 4 cationic sites of the kesterite structure. Rietveld refinements and the average neutron scattering length analysis method enables us to determine point defect type and concentrations. We will present the possibility to deduce occuring point defects from the chemical composition of the kesterite phase.

V.IV.7
15:15
Authors : L.T. Schelhas1, K.H. Stone1, S. Harvey2, G. Teeter2, I. Repins2, M.F. Toney1
Affiliations : 1. SSRL, Materials Science Division, SLAC National Accelerator Laboratory, Menlo Park, CA 2. Chemical and Material Science, National Renewable Energy Laboratory, Golden, CO

Resume : The interest in Cu2ZnSn(S,Se)4 (CZTS) for photovoltaic applications is motivated by the similarities to the promising material Cu(In,Ga)Se2 (CIGS) while being comprised of non-toxic and earth abundant elements. The structural similarity of a number of competing phases makes identification through standard x-ray diffraction (XRD) challenging. Further, CZTS is thought to contain potentially high levels of point defects, the exact effect of which is unknown. The strong possibility of point defects on the Zn and Cu sublattices may lead to a reduction in solar cell efficiency. Recently there have been reports of a low temperature (200 ± 20 °C, for the selenide) order/disorder transition identified by Raman spectroscopy. This transition is thought to be reordering of the Zn and Cu sublattice but direct evidence of this by Raman is difficult. The tunable energy x-rays available at modern synchrotron sources provide a site and element specific probe to investigate such disorder. We have used resonant XRD techniques to quantitatively determine the level of CuZn, ZnCu, VCu, and VZn point defects present in thin films of polycrystalline CZTSe in order to shed light on this low temperature transition. By annealing just below and quenching from just above the transition temperature we have targeted both ordered and highly disordered films in the Cu/Zn sublattice. We aim to understand and characterize the structural differences and defect levels of films annealed under different conditions.

V.IV.8
15:30 Coffee break
16:00
Authors : F. Aousgi, N. khemiri, M. Karyaoui, M. Kanzari, R. chtourou
Affiliations : 1 Laboratoire de Photovoltaïque (LPV), Centre de Recherches et des Technologies de l'Energie (CRTEn), Tech-nopole Borj Cédria B.P N°95 - 2050 Hammam-Lif – Tunisie. 2 Laboratoire de Photovoltaïque et Matériaux Semi-conducteurs, ENIT-Université Tunis El Manar, BP 37, Le belvédère, 1002 Tunis, Tunisie. 3 Institut Préparatoire aux Etudes d’Ingénieurs de Tunis Montfleury -Université de Tunis.

Resume : Abstract Sb2S3 and Sb2S3:Snx (x=1, 2, 3 at. Sn %) thin films have been deposited by single source vacuum thermal evaporation onto glass substrates. The substrate temperature Ts and the annealing temperature Tr vary between 30 °C and 350 °C. The films have amorphous structure, but after annealing at temperatures above 250 °C for 1 hour, they change to polycrystalline structure. The structure and surface morphology of the films were characterized by X-ray diffraction (XRD) and scanning electron microscopy (SEM). The optical absorption coefficient becomes higher for subgap absorption at higher annealing temperatures. The optical investigation showed that, films have direct allowed transitions in the range 1.72-2.2 eV depending on the annealing temperature. The dark electrical resistivity shows a decrease by about an order of magnitude when increasing the isothermal annealing treatment. Doping by tin makes the P-type layers and the electrical resistivity decreases from 2.6 107 to 6 105 Ω cm by increasing the percentage of doping.

V.P2.1
16:00
Authors : J.Ben naceur *, F.joudi , Ibtissem Ben Assaker, Radhouane Chtourou
Affiliations : Laboratoire de Photovoltaïques du Centre des Recherches et des Technologies de l’Energie, Route touristique Soliman, 2050 Hammam-Lif, Tunisia.

Resume : Titanium dioxides (TiO2) has been the subject of numerous studies for a long time, for its potential chemical, electrical and optical properties [ ]. Also TiO2 as one of the most important photo-catalysts due to its high photocatalytic activity under UV light irradiation [ ] However, the practical applications of TiO2 are limited by the ineffective utilization of visible light [ ].Therefore to enlarge the photoresponse spectrum, considerable efforts have been made, such as doping with transition and/or noble metals [ , ], non-metals [ , ], construction of heterojunctions with other semiconductors [ - - - - - ]. Among semiconductor, CdSe has attracted great attention in the past decades. Cadmium selenide is well known as a II–VI compound semiconductor suitable for solar energy conversion with a photovoltaic cell [ ]. CdSe has a high optical absorption coefficient and direct band gap of 1.74 eV [ ] that match the preferred range of the solar radiation spectrum. More importantly, it has a higher conduction band edge than TiO2, allowing effective injection of photogenerated electrons from CdSe. In this work, CdSe were deposited by electrochemical protocol into TiO2/ITO thin film elaborated by sol gel spin coating technique. The structural, morphological and optical properties were investigated, as well as the electrical properties using potentiostatic (I−V) measurements under xenon lamp illumination in aqueous electrolyte. The X-ray diffraction combined with Raman spectroscopy showed that CdSe has formed in hexagonal structure and TiO2 thin films was formed in anatase phases. Moreover, photoluminescence spectroscopie confirm the efficient separation of photogenerated electron and hole charge carriers between CdSe and TiO2. As a consequence, the photoelectrochemical results of the developed nanocomposite show a high activity than TiO2 under visible light irradiation. Hence, it is so recommended for photovoltaic and photocatalytic application.

V.P2.2
16:00
Authors : Shahara Banu1, 2, Se Jin Ahn1, 2, Jihye Gwak1, Young Joo Eo1, Ara Cho1,2*
Affiliations : 1 New and Renewable Energy Research Division, Photovoltaic Laboratory, Korea Institute of Energy Research (KIER), Daejeon, South Korea 2 University of Science and Technology (UST), Daejeon, South Korea

Resume : Among the ongoing investigated absorber materials, SnS has attracted interest as a photovoltaic absorber material due to its simpler composition and potential for large-scale, cost-effective and environmentally friendly power generation. It possesses favorable optical properties including an energy band gap of 1.3 eV and a high optical absorption coefficient greater than 104 cm-1. Moreover, it also exhibits tunable carrier concentrations in the range of 1015 to 1018 cm−3 and hole mobilities as high as 100 cm2V-1s-1 or higher. Additionally, a single-junction SnS-based solar cell shows a high spectroscopic limited maximum efficiency (SLME) of 32%. Nevertheless, the best conversion efficiency of SnS solar cell has been recorded 4.36% by ALD deposition technique until now. In addition, it is difficult to obtain pure SnS phase due to the various oxidation state of Sn (0, +2 and +4), which makes other phases of Sn-S (Sn, SnS2 and Sn2S3) along with SnS. In our study, to overcome the weakness, solution and liquid precursors were used to fabricate pure SnS thin films on Mo-coated soda lime glass using direct solution coating method and subsequent annealing at different reaction temperatures. Direct solution coating is easy, cost-effective and rapid process for large scale fabrications, comparing to ALD. Also, it is very easy to control the exact stoichiometry. The compositional, morphological, and structural characterization of the films prepared by both the precursors will be presented.

V.P2.3
16:00
Authors : Ara Cho1,2 *, Shahara Banu1,2, SeJin Ahn1, Jae Ho Yun1, Jihye Gwak1, Seung Kyu Ahn1, Young-Joo Eo1, Jun Sik Cho1, Ju Hyung Park1, Jin Su Yu1, Kihwan Kim1, Keeshik Shin1
Affiliations : 1 New and Renewable Energy Research Division, Photovoltaic Laboratory, Korea Institute of Energy Research (KIER), Daejeon, Republic of Korea; 2 Renewable Energy Engineering, University of Science and Technology (UST), Daejeon, Republic of Korea

Resume : Recently, Cu-Sb-S phase has been studied as an absorber in solar cell because of its low toxicity, low cost and an abundant of raw materials. In the Cu-Sb-S phases, there are four major phases (CuSbS2, Cu3SbS3, Cu3SbS4, Cu12Sb4S13) and most of research have reported only about synthesis and characteristics of nanocrystals. However, in order to be used as an absorber, the synthesis of thin films with these materials is important. In this study, thin films of Cu-Sb-S phases were formed using non-vacuum process which is cost-effective. To obtain single phase thin films of each material, different Cu/Sb ratios of hybrid ink was firstly considered and different sulfurization conditions were also required, such as sulfurization temperature, reaction time, and reaction pressure. The fabricating thin films were analyzed and confirmed as target phases. The characteristics of each Cu-Sb-S absorber and photovoltaic performances of fabricated cells will be presented.

V.P2.4
16:00
Authors : M. Dhaouadi1. 2, M.Jlassi 3, I.Sta 1. 2, M.Hajji 4, and W. Dimassi1.
Affiliations : 1 Laboratoire de Photovoltaïque, Centre de Recherche et des Technologies de l’Energie, Technopole de Borj-Cédria, BP 95, 2050 Hammam-Lif, Tunisie, 2 Faculté des sciences de Bizerte, université de Carthage, Tunisie. 3 Institut supérieur des beaux-arts de Tunis, Université de Tunis, Tunisie. 4 Institut Supérieur d’Electronique et de Communication de Sfax, Université de Sfax, BP 868, 3018 Sfax, Tunisie.

Resume : Copper oxide thin films were prepared by sol–gel method and spin coating technique onto glass substrates. The physical properties of the prepared films were studied as a function of the number of spin-cast layers. Structural properties of the CuO films were characterized by X-ray diffraction (XRD) and Raman, with respect to the films thickness. The XRD analysis reveals that the film with four layers have better crystallinity with mixed cuprite and tenorite phases, whereas all the Raman spectra revealed the existence of two CuO and Cu2O phases. Optical transmission was studied by UV–vis spectrophotometer, which shows a decrease in transmission with increasing number of layers. The transmission is less than 80 % when we deposit more than three layers. The electrical measurements show that the resistance of the films decreases with increasing number of layers. The resistance of the films with one and two layers were unstable and could not be measured. The conductivity of samples with three, four and five layers was measured 0.232 Ω-1cm-1, 0. 149 Ω-1cm-1 and 0, 118 Ω-1 cm-1 respectively. The copper oxide thin films were used as a working electrode in the application of photoelectrochemical solar cell (PECS).

V.P2.5
16:00
Authors : Na Kyoung Youn, SeJin Ahn, Ara Cho, Jihye Gwak, Kyunghoon Yoon, Keeshik Shin, Seung Kyu Ahn, Jun Sik Cho, Joo Hyung Park, Jin Soo Yoo, Kihwan Kim, Jae Ho Yun, and Young-Joo Eo
Affiliations : Photovoltaic Laboratory, Korea Institute of Energy Research(KIER),Daejeon, Korea

Resume : Tin mono-sulfide (SnS) thin film has been investigated as a photovoltaic absorber material due to not only a high optical absorption coefficient but also non-toxicity and earth abundance. However, the highest photovoltaic conversion efficiency is as low as 4.4%. One of the reasons for the low efficiency is considered to be the poor quality of the SnS layer, such as the formation of secondary phases and a high grain boundary density. Thus, many research groups have dedicated their own effort to obtaining a high quality of SnS thin film. Nano-particle based approach can be one of the suitable fabrication methods of SnS thin films because the thin film can be prepared by a simple coating process using the nano-particle based ink, and the subsequent thermal annealing. The thermal annealing can transform the nano-particle precursors into the thin film and promote the grain growth. Moreover, it can affect the micro-crystalline structure of the thin film. Thus, we can control the physical properties of the SnS thin films by the modification of the thermal annealing condition. In this study, we focused on the effect of the thermal annealing condition on the properties of the SnS thin films. We have found that the crystallinity and band gap (Eg) of thin film are highly dependent on the thermal annealing temperature. The partial pressure of hydrogen sulfide (H2S) gas during the thermal annealing affects the valence of Sn atom and the composition of the thin film. Finally, we demonstrate a SnS thin film solar cell and characterize its photovoltaic performance.

V.P2.6
16:00
Authors : Thomas Feurer (thomas.feurer@empa.ch), Fan Fu (fan.fu@empa.ch), Johannes Löckinger (johannes.loeckinger@empa.ch), Enrico Avancini (enrico.avencini@empa.ch), Benjamin Bissig (benjamin.bissig@empa.ch), Shiro Nishiwaki (shiro.nishiwaki@empa.ch), Stephan Buecheler (stephan.buecheler@empa.ch), Ayodhya N. Tiwari (ayodhya.tiwari@empa.ch).
Affiliations : Laboratory for Thin Films and Photovoltaics, Empa ‐ Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstrasse 129, 8600 Duebendorf, Switzerland

Resume : A promising concept to surpass some of the inherent limitations of single junction solar cells are tandem approaches stacking high- and low-bandgap cells, thus reducing thermalization losses and increasing the efficiency potential. The emergence of perovskites as high efficiency, high bandgap solar cells opened up the possibility for tandem devices with a Cu(In,Ga)Se2 (CIGS) bottom cell. In order to reach the current matching conditions for a Perovskite/CIGS monolithic tandem, a low bandgap CIGS or even CIS is necessary. Unfortunately, even the best pure CIS cells published so far suffer from comparatively low VOC and FF, rendering the gain in current ineffective for tandem solar cells. One possible reason for the observed reduced device quality is the misalignment of the conduction band between buffer and absorber layer. In this work, two possible approaches to circumvent this shortcoming are reported: i) downward shifting of the conduction band in the buffer layer ; ii) upward shifting of the conduction band in the absorber layer by applying a Ga front grading at the surface. We will show how the electrical properties improve due to composition gradings and the influence of buffer adaptation in low Gallium CIGS on single cell parameters. The resulting cells are implemented into CIGS/perovskite tandem solar cells.

V.P2.7
16:00
Authors : Hasan Huseyin Gullu1-2, Mehmet Parlak1-2
Affiliations : 1. Department of Physics, Middle East Technical University (METU), Ankara 06800, Turkey 2. Center for Solar Energy Research and Applications (GÜNAM), METU, Ankara 06800, Turkey

Resume : In this work, Cu0.5Ag0.5InSe2 (CAIS) thin film structure was deposited by thermal evaporation technique on n-Si wafer substrate in order to characterize p-CAIS/n-Si heterojunction diode. This quaternary compound is an electronic chemical analogue of I-III-VI2 ternary semiconductor compounds, CuInSe2 (CIS) and AgInSe2 (AIS). It has been a subject of interest since quaternary alloys can provide opportunity to a large degree of variation of their properties as a function of change in the elemental composition, and as a result of this, it provides to adjust the properties of these materials. The thin film charactersitics of CAIS thin film deposited on glass substrates were investigated by EDS, XRD, transmission, dark resistivity and Hall Effect measurements. Then, in order to determine the device parameters of In/p-CAIS/n-Si/Ag heterojunction, I-V characteristics of the diode at the temperature range of 220-360 K was measured. This p-n junction showed a good diode behavior with about 2 order rectification factor. The series and shunt resistance values were calculated from the parasitic resistance relation in the forward and reverse bias, respectively. In addition, the ideality factor n and the barrier height values of the diode were determined by performing different I-V plots according to Schottky diode equation. Calculated n values were higher than unity and it indicated that there can be other transport mechanisms different from the pure thermionic emission mechanism. Thus, the main current transport mechanism of this heterojunction was found tunneling-like transport of the dark diode current. As observed in the forward transport behavior, the leakage current characteristics of the junction was found to be approximated by the tunneling mechanism. The temperature dependence at reverse bias indicated that they were in between 10^1 to 10^2 number of tunneling steps and about 10^5 traps act role in the reverse current mechanism across the barrier. In addition, C-V measurements were carried out at room temperature under dark condition. The barrier height of the device was found around 0.70 eV and the number of interface states was estimated as in the order of 4.8x10^10 cm-2V-1. From these results, the energy band diagram of the p-CAIS/n-Si heterojunction was constructed by Anderson’s model.

V.P2.8
16:00
Authors : Hasan Huseyin Gullu1-2, Emre Coskun3, Ozge Bayrakli1-2, Mehmet Parlak1-2
Affiliations : 1. Department of Physics, Middle East Technical University (METU), Ankara 06800, Turkey 2. Center for Solar Energy Research and Applications (GÜNAM), METU, Ankara 06800, Turkey 3. Department of Physics, Canakkale Onsekiz Mart University, Canakkale 17100, Turkey

Resume : In this work, ZnInSe2 (ZIS) polycrystalline thin films were prepared by sequential evaporation of its elemental sources on ultrasonically cleaned soda lime glass substrates. Their compositional, structural and surface characteristics were checked by energy dispersive X-ray spectroscopy (EDS), X-ray diffraction (XRD), Raman spectroscopy, scanning electron microscopy (SEM) and atomic force microscopy (AFM) measurements. Moreover, post-thermal annealing were applied under nitrogen atmosphere to see the effect of annealing and to provide the thermal energy to the constituent elements to complete thermal kinetics for the nucleation stage in the thin film structure. Under this aim, the crystallinity of the films improved as annealing temperature with increasing up to 500°C by 100°C step. With the insight into the structural information, ZIS films were found in n-type semiconductor behavior with tetragonal crystal structure oriented along (112) direction. The optical properties and constants for deposited ZIS thin films as well as the effect of heat treatments were estimated from their transmission spectra in the wavelength interval of 200-2000 nm. The refractive indices were calculated by using envelope method (EM) and also modeled by Cauchy fitting processes to get a continuity in the whole wavelength range. The absorption coefficients in the visible and near-infrared region (NIR) were computed from the transmission values. Then, the extinction coefficient calculations were done and also by using the results of the refractive index calculations, the real and imaginary part of the dielectric constant were found. Analysis of the absorption coefficient data showed the existence of allowed direct transition and corresponding band gap values were calculated from their Tauc plots. These values were found to decrease with increasing annealing temperature. The refractive index dispersion over the measured wavelength range was investigated with single-oscillator model (SOM) and the related parameters were obtained.

V.P2.9
16:00
Authors : L. Ion1, A. Radu1, S. Iftimie1, V. Ghenescu3, M.M. Gugiu2, G.A. Nemnes1,2, N. Korganci1, O. Toma1, S. Antohe1,4
Affiliations : 1University of Bucharest, Faculty of Physics, Bucharest, Romania; 2Horia Hulubei National Institute for R&D in Physics and Nuclear Engineering (IFIN-HH), Magurele, Romania; 3Institute of Space Science, Magurele, Romania; 4Academy of Romanian Scientists, Bucharest, Romania

Resume : We report the changes induced by alpha particles irradiation on the physical properties of zinc selenide layers (ZnSe) deposited by rf-magnetron sputtering onto optical glass substrates covered with indium tin oxide (ITO) thin films. Deposition time was varied in the range 2 – 10 minutes and the other working parameters, power, pressure and substrate temperature, were maintained constant during the procedure. ZnSe/ITO interface was irradiated using Cockcroft-Walton Tandreton accelerator with 1.5 MeV energies and 1012 particles/cm2 fluencies. Induced changes by irradiation on the optical properties were analyzed using a UV-VIS Lambda 35 spectrometer and by spectroscopic ellipsometry. Bandgap energy of ZnSe thin films slightly decreased for both as grown and irradiated samples with decrease of deposition time. Optical transmittance was higher than 70% and no important changes were observed after irradiation procedure.Structural and morphological features were investigated by X-ray diffraction (XRD) and scanning electron microscopy (SEM), for as grown and irradiated fabricated thin films. To completely understand the changes induced by alpha particles irradiation Monte-Carlo numerical simulations were also discussed. Keywords: ZnSe, alpha particles, irradiation Acknowledgements: This work was supported by Romanian Executive Unit for Financing Higher Education, Research and Innovation (UEFISCDI) under PN-II-PCCA program, grant no. 288/2014.

V.P2.10
16:00
Authors : A. Jebali, N. Khemiri, M.Kanzari
Affiliations : Université Tunis ElManar, Ecole National d’Ingénieurs de Tunis, Laboratoire de Photovoltaïque et Matériaux Semi-conducteurs 1002, Tunis, Tunisie.

Resume : SnSb4S7 powder is one of the most promising compounds used as evaporation source material for the next generation of optoelectronic and thin films photovoltaic devices. SnSb4S7 powder was synthesized by horizontal Bridgman method using high purity tin (Sn), antimony (Sb) and sulfur (S) elements. Structural, chemical and morphological properties of the obtained powder were investigated by X-ray diffraction (XRD), Raman spectroscopy, energy dispersive X-ray (EDX) and transmission electron microscopy (TEM), respectively. The XRD results demonstrated that the powder was polycrystalline in nature and crystallizes in monoclinic structure with a preferred orientation along ( 1 ) plane. This analyses also reveal that the lattice parameters of the powder were a = 11.51 Å, b = 4.17 Å, c = 13.96 Å and β = 105.41°. The formation of SnSb4S7 powder is also confirmed by Raman spectroscopy. This analysis shows that the Raman modes for the SnSb4S7 powder were observed at 117, 140, 155, 187, 250, 303, 371 and 450 cm-1. TEM/EDX was also used to determine the chemical composition of the SnSb4S7 powder. The EDX analysis of various grains of the powder shows that the compositions vary from one grain to another. Transmission Electron Microscopy (TEM) and high-resolution transmission electron microscopy (HREM) were employed to establish the crystalline nature of the SnSb4S7 powder. The TEM observations demonstrated that the SnSb4S7 powder polycrystalline in nature with rod shaped structure.

V.P2.11
16:00
Authors : D. Abdelkader1, N. Khemiri1, I. Trabelsi1, F. Antoni2, M. Kanzari1,3
Affiliations : 1 Université Tunis ElManar, Ecole National d’Ingénieurs de Tunis, Laboratoire de Photovoltaïque et Matériaux Semi-conducteurs 1002, Tunis, Tunisie. 2 ICube-Laboratoire des sciences de l’Ingénieur, de l'Informatique et de l’Imagerie, Université de Strasbourg-CNRS, 23, rue du Loess, 67037 Strasbourg Cedex,France. 3 Institut Préparatoire aux Etudes d'Ingénieurs de Tunis-IPEIT, Université de Tunis, 2, Rue Jawaher Lel Nehru, 1089 Montfleury, Tunisia

Resume : In this work, we investigated the physico-chemical properties of Indium-free Sn-Sb-S materials as promising candidates for thin films solar cells. SnSb4S7, SnSb2S4, Sn4Sb6S13, Sn2Sb2S5 and Sn3Sb2S6 thin films were deposited by single source vacuum thermal evaporation onto unheated glass substrates. The as-deposited samples were annealed at 300 °C under nitrogen during 2 hours. The structural properties of annealed films were studied using X-ray diffraction (XRD), Raman and FTIR spectroscopies. The surface morphology was investigated by scanning electron microscopy (SEM) and atomic force microscopy (AFM). The optical properties were carried out using UV-Vis spectroscopy and the electrical measurements were focalised on the impedance spectroscopy. XRD results revealed that the nitrogen annealing improves considerably the crystallinity of these films, which is confirmed by the Raman measurement. The surface images show that the roughness increases when the Sn content increases. The optical properties of the films were obtained from the analysis of the transmittance and reflectance data. All films exhibit a high absorption coefficient (104-105 cm-1) in the visible region which is a good advantage for solar cells applications. The band gap energy decreases from 1.71 to 1.39 eV by increasing Sn content. We exploited the models of Wemple-DiDomenico and Spitzer-Fan for the analysis of the dispersion of the refractive index and the determination of the optical constants of the films.

V.P2.12
16:00
Authors : Hye Jin Kim(1, 2), Chae-Woong Kim(1), Kilim Kim(1), Lee Sunhwa(1), Duk Young Jung(2) and Chaehwan Jeong(1*)
Affiliations : 1 Korea Institute of Industrial Technology (KITECH) 2 Sunkyunkwan University

Resume : Chalcopyrite of the general composition Cu(In, Ga)Se2 (CIGS) solar cells offer a wide range of band gaps from 1.0 eV for CuInSe2 (CIS) to 2.4 eV for CuGaSe2 (CGS). The wide band gap CGS solar cell among chalcopyrite solar cell has received considerable attention with respect to development of the tandem solar cells and thin-film modules. The wide bandgap of CGS absorber layers for Tandem solar cells are desirable because of their higher open-circuit voltage and lower currents for better module performance and current matching in tandem cells. The theoretical efficiencies are very close to but the achieved efficiency is only half. The key to solve this problem of fabrication of wide band gap devices are a slightly Ga-rich absorber composition, the use of Na-containing substrates, and a buffer layer deposition temperature which is optimized for CGS absorbers. We are experimented CGS absorber layers according to controlled temperature were grown by co-evaporation method of Cu, Ga, and Se with three-stage process. And the thickness of CGS absorber layers was controlled by first stage process of three stage process with co-evaporation method. And then, the character of CGS absorber layers according to thickness and temperature were discussed and improved. And we were tried to application of the optimization and high-efficiency of CGS top cells of the tandem solar cell. The optimal top cell process temperature resulted in the efficiency 2.96% at CGS / CIGS tandem cell. The fabricated CGS absorber layers were investigated by X-ray diffraction (XRD), Raman, scanning electron microscope (SEM) and GD-OES. The CGS / CIGS monolithic tandem solar cells were characterized by light induced current-voltage (LIV) and external quantum efficiency (EQE).

V.P2.13
16:00
Authors : V.Kosyak 1, A.Vozny 1, P. Onufrijevs 2, L.Grase 2, J. Vecstaudža 2, A. Opanasyuk 1, A. Medvids 2 and G. Mezinskis 2.
Affiliations : 1 Sumy State University, 2, Rymsky Korsakov Str., 40007 Sumy, Ukraine 2 Riga Technical University, 3/7, Paula Valdena Str., LV-1048 Riga, Latvia

Resume : In this study, the effect of post-growth thermal annealing and laser irradiation on phase composition, structural, optical and electrical properties of SnS2 obtained by the close-spaced sublimation on ITO substrates was studied. It was found, by using EDS, XRD and Raman methods that as-grown samples have single phase SnS2 structure and their chemical composition is close to stoichiometric. In order to determine annealing conditions for phase transition from SnS2 to SnS the samples were annealed in vacuum under different temperature and time. It was determined that annealing in the vacuum of SnS2 films at 500 0C for 90 min leads to the formation of single phase stoichiometric SnS. The laser annealing of the SnS2 thin films sample was performed by the Nd:YAG laser, with two intensities of radiation of 8.5 and 11.5 MW/cm2. It was established, that irradiation of the samples with 8.5 MW/cm2 intensity leads to the coalescence of grains accompanied with smoothing of the surface. The EDS line scan of the samples cross section shows that chemical composition of the layer at the irradiated surface is close to SnS, while near the substrate the chemical composition remains the same as before irradiation. Formation of SnS phase was also confirmed by the XRD and Raman methods. The application of 11.5 MW/cm2 laser radiation leads to the formation of SnS phase not only at the surface but in the whole volume of samples. The I-V characteristics of the ITO/SnxSy/Al samples show ohmic behaviour in a case of non-irradiated and irradiated with high 11.5 MW/cm2 intensity samples. While for the samples irradiated with 8.5 MW/cm2 intensity the diode behaviour of I-V curve was observed. It could be considered as an evidence of formation of p-SnS/n-SnS2 hetorojunction structure.

V.P2.14
16:00
Authors : Thierno Sall, Miguel Mollar, Bernabé Marí
Affiliations : Institut de Disseny i Fabricació Universitat Politècnica de València València (SPAIN)

Resume : Orthorhombic SnS thin films doped by silver with various percentages were deposited onto glass substrate by Chemical Spray Pyrolysis technique. Structural, morphological, composition, optical, and electrical properties were studied using X-Ray Diffraction (XRD), Scanning Electron Microscopy (SEM), Atomic Force Microscopy (AFM), Energy Dispersive Analysis of X-Ray (EDAX) attached to SEM, spectrophotometry, and four points probe technique, respectively. XRD shows that the crystallinity of films enhanced by the increase of silver dopant with (111) as preferential peak for all films. EDAX revealed the presence of sulphur, tin and silver in all films with good stoichiometry and an increase of silver proportional to silver doping. All films had almost same surface morphology. Atomic force microscopy confirms the results of scanning electron microscopy in the sense that Ag-doping had no effect on the topography of films. The resistivity decreases with the percentage of silver doping reaching the lowest value (108 Ω·cm) for films sprayed with solutions containing 10% of Ag. Band gap energy measurement of 1.45 eV was obtained by film doped with silver at 5%.

V.P2.15
16:00
Authors : Jorge Sergio Narro-Ríos (1), Dalia Martínez-Escobar (1), Aarón Sánchez-Juárez (1)
Affiliations : (1) Instituto de Energias Renovables, Universidad Nacional Autónoma de México, Privada Xochicalco S/N, Col. Centro, Temixco, Morelos C.P. 62580, Mexico

Resume : In this study, p-n junction and the thin films of SnSe and ZnO used were investigated. The properties of the deposited films and the p-n junction were studied by means of X-ray diffraction (XRD), UV-VIS spectrophotometry, Profilometry, Hall Effect and I-V Solar Simulator. SnSe material obtained by ultrasonic spray pyrolysis, has a forbidden gap of 1.1 eV and p-type conductivity, which is adequate to be used as an absorber in a p-n junction. ZnO obtained by sputtering, has n-type conductivity and an energy gap of 3.3 eV who made the material a candidate to use it as a window layer. Stainless Steel 430 (Steel) was used as substrate and back contact, obtaining the following configuration Steel/SnSe/ZnO/ZnO:Al, where ZnO:Al was deposited by sputtering and has been used as transparent conductor oxide (TCO). A theoretical and a physical p-n junction were form, the theoretical junction obtained by Solar Cell Capacitance Simulator (SCAPS) fed by the measured parameters shows a Voc= 0.9 V and a Isc= 22 mA/cm2 regardless serial and shunt resistance. The theoretical results show the ability to improve the physical p-n junction (working on improving results) so as the principal parameters of the solar cell. This solar cell do not contain toxic materials and all the constituents are earth abundant elements which is now, one of the principal reasons to study, improve and fabricate thin film solar cells.

V.P2.16
16:00
Authors : K. NEFZI 1, 2, A. RABHI 1 and M. KANZARI 1, 3
Affiliations : 1Université de Tunis El Manar (UTM), Ecole Nationale d'Ingénieurs de Tunis Laboratoire de Photovoltaïque et Matériaux Semi-conducteurs (LPMS), BP 37 le Belvédère 1002, Tunis, Tunisie. 2 Département de Physique, Faculté des Sciences de Bizerte, Jarzouna 7021 Bizerte, Tunisie. 3 Université de Tunis, IPEITunis Montfleury, Tunis, Tunisie.

Resume : In this paper, Schottky diodes (Al/p- Cu3SbS3/Mo) were fabricated by simple deposition of pure Aluminum on the front side of the Cu3SbS3 thin films. The current-voltage (I–V) characteristics show that the Aluminum makes Schottky contact with p- Cu3SbS3. Ideality factors and serial resistances were extracted from the experimental data. The capacitance-voltage (C-V) characteristics reveal the values of the barrier height of the heterostructures. Impedance spectroscopy technique was used to evaluate the conduction processes of the samples as a function of temperature. We found a decrease with temperature of the entire serial resistances Rs, the parallel resistances Rp and the capacitances Cp. In effort to modeling these results equivalent electrical circuits were used. From the Arrhenius diagrams, we estimated activation energies which represent the energy difference between the trap level and the valence band.

V.P2.17
16:00
Authors : Yahuitl Osorio Mayon, Thomas P. White, Rongping Wang, Zhiyong Yang, Kylie R. Catchpole
Affiliations : Centre for Sustainable Energy Systems, Research School of Engineering, College of Engineering and Computer Science, Australian National University

Resume : We fabricate inorganic planar solar cells of the pin type with a Sb2S3 absorber using thermal evaporation, and compare the results to solution-processed cells. The efficiency of the evaporated Sb2S3 solar cell is more than double the efficiency of the solution deposited Sb2S3 solar cell. The evaporated Sb2S3 film is sulphur-rich, which results in perfect flattening of the film surface during the annealing step. Having a flat Sb2S3 surface allows deposition of a thin and uniform hole transport layer. In contrast, the solution deposited Sb2S3 is sulphur deficient and does not flatten during the annealing step. The internal quantum efficiency is also higher for the evaporated Sb2S3 solar cells, suggesting longer diffusion lengths. We attribute this to differences in the preferred crystal plane orientation for the evaporated and solution deposited Sb2S3 films and the 30% larger grain sizes in the evaporated films. The difference in the preferred crystal plane orientations is consistent with studies of Sb2Se3 solar cells that also showed a correlation between crystal plane orientation and efficiency. For Sb2Se3 the difference in efficiency with different preferred crystal plane orientations is due to more efficient carrier transport and lower recombination along particular crystal planes. Given that Sb2S3 and Sb2Se3 are closely-related materials, it is very likely that our results for Sb2S3 solar cells can be explained by the same mechanism, although confirmation of this will require a detailed theoretical analysis of atomic bonding in Sb2S3. These insights are useful for the progress of solar cells of Sb2S3 and related materials.

V.P2.18
16:00
Authors : S. Polivtseva, A. Katerski, E. Kärber, I. Oja Acik, A. Mere, V. Mikli, M. Krunks
Affiliations : Department of Materials Science, Tallinn University of Technology, 19086 Tallinn, Ehitajate tee 5, Estonia

Resume : SnS is an attractive absorber material for solar cells due to its high absorption coefficient, non-toxicity and availability of tin and sulfur. Chemical spray pyrolysis is a simple, fast and inexpensive method to deposit thin film. Acidic aqueous solutions containing tin chloride (SnCl2) and thiourea (SC(NH2)2) at molar ratios of 1:1 and 1:8 were pulverized onto glass substrates at 200 °C in air to obtain SnS films. In this study we investigated the influence of post-deposition annealing in nitrogen and vacuum at 450 °C for 60 min on properties of sprayed SnS films. Films were characterized by X-ray diffraction (XRD), Raman and UV-Vis spectroscopies, scanning electron microscopy (SEM) and energy dispersive X-ray analysis (EDX). As-deposited films are composed of cubic SnS as the main crystalline phase independent of precursors’ molar ratio in the spray solution, the mean crystallite size is 35 and 17 nm for 1:8 and 1:1 films, respectively. Thermal treatment of 1:8 films in nitrogen results in Sn2S3 as the main phase, SnS is present as the minor phase. Annealing of 1:8 films in vacuum results in orthorhombic SnS phase, films show optical band gap of 1.4 eV. Thermal annealing of 1:1 films in vacuum leads to metallic Sn, whilst annealing in nitrogen results in films composed of a mixture of SnS and SnO2 phases. Formation of SnO2 in an inert atmosphere indicates presence of oxygen containing phases already in the as-grown film. Chemical reactions taking place during thermal treatments as well as optimal deposition and post-deposition treatment conditions for fabrication of SnS single phase films will be discussed.

V.P2.19
16:00
Authors : Grzegorz Wisz, Piotr Potera, Igor Virt, Piotr Sagan
Affiliations : G.Wisz1, P.Potera1*, I.Virt1,2, P.Sagan1 1)Faculty of Mathematics and Natural Sciences, Rzeszow University, Rejtana 16c 35-959 Rzeszow, Poland 2) Drohobych Ivan Franko State Pedagogical University, Drohobych, Franko, 34, 82100, Drohobych, Ukraine *corresponding author

Resume : Metal oxide semiconductors are promising for photovoltaic applications; many metal oxide semiconductors are abundant, non-toxic and chemically stable which allows material deposition under ambient conditions. The metal oxide semiconductors are already widely used as active or passive components in a broad range of available commercial applications such as active channel layer in transistors that constitute the active matrix of displays or in solar cells as transparent conducting front electrodes and as electron or hole transport layers [1]. The perspective materials can be TiO2 and Cu2O layers because they are cheap in obtaining and not degrade in time. In this work the optical properties of TiO2 layers growth in different conditions by PVD method were studied for obtaining the most photosensitive material. Also the optical studies were performed for different Cu2O layers for optimization of growth parameters. For selected optimal growth parameters of Cu2O and TiO2 single layers the sandwich Cu2O/TiO2/ITO/glass layers were obtained. This layers were studes by optical spectroscopy and also current-voltage characteristic were obtained. For one of the sample the photosensitivity for lighting was observed. [1]M Pavan, S.Rühle, A.Ginsburg, D.Keller, H.Barad, P.Sberna, D.Nunes , R.Martins, A.Anderson, A.Zaban, E.Fortunato, Solar EnergyMaterials&SolarCells132(2015)549–556

V.P2.20
16:00
Authors : Simone Di Mare°, Andrei Salavei°, Daniele Menossi°, Fabio Piccinelli*, Elisa Artegiani°, and Alessandro Romeo°.
Affiliations : °LAPS-Laboratory for Applied Physics, Department of Computer Science, University of Verona, Ca' Vignal 1, Strada Le Grazie 15, 37134 Verona, Italy; *Department of Biotechnology, University of Verona, Strada Le Grazie 15, 37134 Verona, Italy

Resume : The limited amount in nature of Te and In and the toxicity of Cd and Se in CdTe and CuInGaSe2 solar devices could be overcome with alternative thin film absorbers like Cu2ZnSnS4 or SnS. Recently we presented SnS solar cells with 1.5% efficiency, now we report a detailed study of the SnS growth by congruent vacuum evaporation, producing solar cells in superstrate configuration. The SnS layers have been deposited under different substrate temperatures from 150 to 400 °C. Morphology, grain size, and crystalline structure of SnS thin films are strongly influenced by the substrate temperature. Samples grown at low temperature exhibit small flake-like grains and a poor adhesion, whereas those grown at high temperature show a very compact structure with rectangular grains. Moreover, we found that while in the low and high temperature regimes there are two different preferred orientation of crystallites, in the 250 – 270 °C mid region samples exhibit a lower degree of preferential orientation of the grains. We also investigated the effects of different temperatures of the SnS evaporation source on the deposited absorber layer. The evaporation rate has been kept fixed to 0.5 nm/s, despite the source temperatures were varied (600 – 810 °C) by adding source caps to the crucible. It seems that the congruent evaporation of SnS occurs in a narrow range of temperatures. These evidences and their correlation with the electrical performance of SnS solar cells will be presented and discussed.

V.P2.21
16:00
Authors : L. Acebo(1), Y. Sánchez(1), X. Alcobé(2), A. Pérez-Rodríguez(1,3), P. Pistor(1), V. Izquierdo-Roca(1), E. Saucedo(1)
Affiliations : (1) Catalonian Institute for Energy Research (IREC), Jardin de les Dones de Negre 1, 08930 Sant Adrià del Besòs, Spain; (2) Centres Científics i Tecnològics de la Universitat de Barcelona (CCiTUB). LLuís Solé i Sabarís 1-3, 08028, Barcelona, Spain; IN2UB, (3) Departament d’Electrònica, Universitat de Barcelona, C. Martí i Franquès 1, 08028 Barcelona, Spain

Resume : SnS is considered a promising candidate for cost-efficient solar cell devices using earth abundant elements. Being formed by only two elements, this material can simplify the processing involved in the preparation of photovoltaic devices. Nevertheless, the record efficiencies achieved for SnS are still low, requiring further efforts to solve main fundamental and technological problems such as the coexistence of multiple SnxSy phases (including SnS2 and Sn2S3). In this work, we synthesize SnS thin films using a sequential process based in the sputtering of Sn layers onto Mo-coated soda lime glass substrates, followed by a reactive annealing under S+Sn atmosphere. We focus on the variation of the annealing conditions (total pressure between 0.1-10 mBar and temperature 300-550 ºC). The layers were characterized using XRF, SEM, XRD and Raman spectroscopy, and solar cells were fabricated and tested using a CdS/i-ZnO/ITO front-end design. Combining XRD and Raman spectroscopy we determine the p-T zone for the preparation of SnS single phase materials. The morphology and composition of the layer is strongly influenced by the reactive annealing conditions. Synthesizing the SnS layer at 10 mBar and 500 ºC, we report devices with rectifying behaviour, but still poor efficiency (<1%). Further challenges of the material system and the involved technology will be discussed.

V.P2.22
16:00
Authors : David So, Gerasimos Konstantatos
Affiliations : ICFO – The Institute of Photonic Sciences

Resume : Colloidal semiconductor nanocrystals are providing for new opportunities for the design and fabrication of competitively-performing optoelectronic devices but are largely based on materials containing Cd and Pb. Here, we investigate the use of copper indium sulfide (CuInS2) as an alternative nanocrystal material system, having no toxic component and having already demonstrated high conversion efficiencies in the bulk. We synthesized various sizes of emitting copper-poor zinc-treated CuInS2 nanocrystals with long luminescence lifetimes, broad and tunable emission spectra and high exciton binding energies. We found that these nanocrystals couple to each other as the distance between them is reduced. With a ligand exchange procedure, these films became conductive, with modest mobilities, low carrier concentrations and a slow response to illumination. These properties were implied to cause the observed limitation in the thickness of the CuInS2 absorber in heterojunctions with titania, showing a cap in photocurrent. This limitation was overcome by increasing the CuInS2-titania interface through nanostructuring and by reducing the energetic barrier between nanocrystals. This has led to an increase of more than 10 times in photocurrent and power conversion efficiencies of >1%, which is a record for non-annealed solid-state CuInS2 nanocrystal devices.

V.P2.23
16:00
Authors : Mohammad Mahdi Tavakoli 1,2, Rouhollah Tavakoli 2, َAashir Waleed 1, Arash Simchi 2, Zhiyong Fan 1
Affiliations : 1 Department of Electronic and Computer Engineering, Hong Kong University of Science and Technology, Clear Water Bay, Kowloon, Hong Kong E-mail: mmtavakoli@ust.hk 2 Department of Materials Science and Engineering, Sharif University of Technology, Tehran, P.O. Box 11365-9466, Iran

Resume : During the last decade, PbS colloidal quantum dot (CQD) are attracting tremendous attention due to its excellent optoelectronic properties for photovoltaic applications. Up to now, a maximum power conversion efficiency (PCE) of 10.6% has been reported by surface modification of PbS CQD, resulting in reduction of the deep trap states. Herein, we synthesize PbS CQDs with hot injection method and modify the dots surface by using solid-state ligand exhchange. We utilize short ligands of methylammonium iodide (MAI) for ligand exchange. The results show that the MAI-passivated dots have higher life time and lower charge-transfer resistance compared with the passivated dots by mercaptoperopionic acid (MPA). The photovoltaic measurements of the devices demonstrate that MIA-passivated PbS CQDs solar cell has a slightly higher performance than its counterpart. Besides, we fabricate three-dimensional plastic nanostructure using inverted-nanocone structure of Anodized-Aluminum oxide. This layer has attached to the FTO glass in order to increase the absorption. In fact, the nanostructure thin film on PbS CQDs solar cell works as not only anti-reflection but also self-cleaning layer. The results of UV-visible and external quantum efficiency tests confirm the effect of this nanostructured layer on device performance. Finally, we achieve a PCE of 6.35% and 7.1% for PbS CQDs solar cell without and with anti-reflection layer, respectively.

V.P2.24
16:00
Authors : Joop van Deelen, Marco Barink
Affiliations : TNO/Solliance

Resume : CIGS cells form an excellent platform for tandem cells. Not only can the band gap of the bottom cell be tuned, also the optical characteristics of the top layers of the CIGS cell can be made to match the demands of a top cell. For instance, perovskite cells can be processed on top of CIGS. However, optical losses reduce the benefit. Our modeling shows that texturisation can increase the efficiency for both single cell and tandem cell configurations. In part this is because of reduced internal reflection. In addition, we verify the impact of the thickness of the toplayer and show various ways to tune the top and bottom cell to get current matching. Furthermore, the impact of the transparent conductor is detailed for the case of tandem cells, which create specific demands. By combining all these aspect, the design can be optimized for device performance.

V.P2.25
16:00
Authors : S. Vatavu1,2, N. von Morze1, S. Wiesner1, S. Moras3, V. Hinrichs1, J. Gasiorowski3, D. R. T. Zahn3, M.-Ch. Lux-Steiner1, and M. Rusu1
Affiliations : 1 Institut für Heterogene Materialsysteme, Helmholtz-Zentrum Berlin für Materialien und Energie, Hahn-Meitner-Platz 1, 14109 Berlin, Germany 2 Moldova State University, 60 A. Mateevici str., 2009 Chisinau, Moldova 3 Technische Universität Chemnitz, Reichenhainer str. 70 , 09126 Chemnitz, Germany

Resume : This research focuses on the fabrication of stoichiometric CuInSe2 nanostructures with controllable height, spacing and size of the nanocrystals, suitable for hybrid (organic/inorganic) photovoltaics. The CuInSe2 nanostructures were prepared by the chemical close-spaced vapor transport (CCSVT) method [1] onto Mo/barrier/glass substrates by using In2Se3 source material (volatilized by HCl at 550C) and three different types of Cu precursors: (i) Cu thin films (6-250 nm thick), (ii) Cu nanoparticles deposited by spray pyrolysis (at substrate temperatures of 220-500C), and (iii) Cu nanoparticles formed by applying shadow nanosphere lithography (using a monolayer of 450 nm nanospheres). The CCSVT process parameters were varied to reveal the influence of the precursors on the formation of the CuInSe2 nanostructures. A summary of structural characterization by x-ray diffraction in both grazing incidence and theta-2theta configuration confirmed the presence of CuInSe2 chalcopyrite phase independent on the applied precursor approach. The elemental composition of the as-prepared CuInSe2 nanostructures was analyzed by laser ablation-inductively coupled plasma mass-spectrometry. An excess of Se compared to stoichiometric composition was detected and was attributed to the formation of molybdenum selenide and indium selenide phases. However, the formation of the latter secondary phases was suppressed by tuning of the deposition parameters. 1. M. Rusu et al. Thin Solid Films 451–452 (2004) 556

V.P2.26
16:00
Authors : A. Voznyi, V. Kosyak, L. Grase, A. Medvids, A. Opanasyuk
Affiliations : Sumy State University, 2, Rymsky Korsakov Str., 40007 Sumy, Ukraine Riga Technical University, 3/7, Paula Valdena Str., LV-1048 Riga, Latvia

Resume : Presently, the earth-abundant and non-toxic SnS2 and SnS compounds could be considered as the promising optoelectronic material. This is due the fact that SnS2 has n-type conductivity, high carrier mobility and wide band gap of 2.2 eV. These properties make it possible to use SnS2 as a window layer in solar cells. Whereas SnS has p-type conductivity, high absorption coefficient and band gap of about 1.3 eV is suitable material for absorber layer in thin film solar cells. Also opposite conductivity of SnS and SnS2 gives an opportunity to create n - SnS2/p - SnS heterojunction. SnS2 films were obtained by the close-spaced vacuum sublimation method. SEM images of the surface and cross-section of the obtained samples shows that films consist of plate-like crystallites with average grain size of 2 µm. Thickness of the films was 4 µm. The annealing of the samples was carried out at 300, 400 and 500 0C for 30, 60 and 90 min for each of temperatures in vacuum. In order to study phase composition of the SnxSy films XRD and Raman spectroscopy were used. It was determined that annealing in vacuum of SnS2 films at 500 0C for 90 min leads to the formation of single phase SnS. While, the smaller time and temperature of annealing leads to the mixed phase composition of SnS, Sn2S3 and SnS2. Annealing at 500 C for 90 min lead to the porous structure of the material. EDS analysis shows that the non-annealed films has typical for SnS2 value of Sn:S ratio of 0.49 . Annealing at higher temperature of 500 0C for 90 min shows that films have Sn:S ratio of 0.96. That is close to stoichiometric composition of SnS compound. These results confirm the XRD and Raman data indicating that annealing at 500 0C for 90 min lead to phase transition from hexagonal SnS2 to orthorhombic SnS.

V.P2.27

Poster 2: Novel materials & devices, CdTe solar cells : E. Saucedo, E. Ahlswede
16:00
Authors : Fengyan Zhang, Xin Cui, Wenzhi Chen, Xuan Huang, Chao Li, Ran Zhang, Chuwei Zhong, Qijin Cheng, Daqin Yun
Affiliations : Institute of Solar Energy College of Energy Xiamen University Xiamen, CHina

Resume : This paper will discuss our research approaches for printable CZTS/CIGS thin film solar cell, which will include CZTS/CIGS nanoparticle syntheses using thermal injection method; forming high quality CZTS/CIGS layer by solution based method and annealing; Using MoNa electrode or Na ion solution process to further improve the crystalline of the CZTS/CIGS layer ; forming printable Mo back contact using Mo ink; and using solution method to form AZO nanorod sandwich layer to improve light absorption. We have observed significant improvement on the efficiency of CZTS/CIGS solar cell by optimizing MoNa back contact, using Na ion solution, by special ambient annealing process and using AZO nanorod sandwich layer as the window layer. Detail will be addressed at the presentation.

V.P2.28
16:00
Authors : F Bittau (1), A Abbas (1), T Fiducia (1), A Munshi (2), K.L. Barth (2), W.S. Sampath (2), J W Bowers (1), J M Walls (1)
Affiliations : 1. Centre for Renewable Energy Systems Technology (CREST), School of Electronic Electrical and Systems Engineering, Loughborough University, Leicestershire, LE11 3TU, UK 2. NSF I/UCRC for Next Generation Photovoltaics, Colorado State University, Fort Collins, USA

Resume : The use of a High Resistant Transparent (HRT) layer has been shown to increase the efficiency of thin film CdTe heterostructure solar cells. However, the precise mechanisms involved are not fully understood. This study aims to examine the physical properties of ZnO films with their effectiveness as a HRT layer for CdTe devices. The microstructure of ZnO was manipulated by variation of the deposition parameters. The ZnO layers were deposited by RF magnetron sputtering using different deposition working gas pressures and substrate temperatures. The pressure during deposition was varied between 1mTorr (1.33 x 10^-1 Pa) and 9mTorr (1.2Pa). The substrate temperature was varied from 20°C to 400°C. UV-VIS spectrophotometry, Hall Effect measurements and X-Ray Diffraction (XRD) spectroscopy were used to characterize the ZnO films. The deposition pressure influenced the transparency of ZnO films while temperature did not. The resistivity of ZnO films increased steadily with increasing pressure. No trend was observed by increasing temperature. Resistivity was minimised at 100°C and was maximised at 300°C. All films displayed a strong (002) XRD peak indicating a strong c-axis orientation. CdS/CdTe solar cells were fabricated on ZnO coated TEC 10 glass. Transmission Electron Microscopy (TEM) was used to investigate the cross-sectional microstructure of completed devices and J-V measurements were obtained to relate ZnO HRT microstructure to cell performance.

V.P2.29
16:00
Authors : M.L. Albor-Aguilera1, C. Hernandez-Vasquez1, J.M. Flores-Marquez1, S. Gallardo-Hernandez2, M.A. Gonzalez-Trujillo3, U. Galarza-Gutierrez1, G. Ortega-Cervantes1
Affiliations : 1ESFM-IPN, Depto. Fisica, U.P.A.L.M., Zacatenco, Mexico D.F. 07738, Mexico; 2CINVESTAV-SEES-IPN, Av. IPN 2508, Zacatenco, Mexico D.F. 07360, Mexico; 3ESCOM – IPN, Formacion Basica, U.P.A.L.M., Zacatenco, Mexico D.F., 07738, Mexico.

Resume : The polycrystalline CdTe/CdS thin-film solar cell is one of the most important photovoltaic devices for cost-effective generation of solar electricity on terrestrial applications. The typical superstrate structure of a CdTe/CdS solar cell is composed of four layers: one of them, a transparent and conducting oxide (FTO) which acts as front contact, the window and absorbent layers CdS and CdTe films were used respectively, and finally Te/Cu:Au was deposited as back contact. CdS and CdTe thin films have been prepared by chemical bath deposition and by close space vapour transport (CSVT) technique respectively. An efficiency of 12% has been reached on laboratory scale. Higher short-circuit current densities (Jsc) can be achieved by reducing the CdS thickness (60nm) and using an appropriated thermal annealing process. Elemental composition was analyzed by using SIMS (Secondary Ion Mass Spectrometry) system along the solar cell volume focusing on Cd, Te, S, Cu, Au elements distribution and their relation with the final photovoltaic efficiency.

V.P2.30
16:00
Authors : A. Gonzalez-Cisneros1, M.A. Gonzalez-Trujillo1, M.L. Albor-Aguilera2, C. Hernandez-Vasquez2, J.M. Flores-Marquez2, F. L. Castillo-Alvarado2, P. A. Hernández-Leon2.
Affiliations : 1ESCOM – IPN, Formación Básica, U.P.A.L.M., Zacatenco, México D.F., 07738, México; 2ESFM-IPN, Depto. Física, U.P.A.L.M., Zacatenco, México D.F. 07738, México.

Resume : CdS/CdTe heterojunctions are used on photovoltaic devices. Substantial evidence exists that interdiffusion between CdTe and CdS layers occurs during CdCl2 treatment and post annealing processes. A sulphur diffusion into the CdTe layer leads to the formation of a ternary CdTe1-xSx phase within the CdTe layer. In this work was studied some electrical properties by using a simple model known as matching method considering a ternary compound in the interface. Comparing theoretical results with I-V experimental measurements on CdS/CdTe solar cells good results were obtained, due to using a x= 0.75 concentration were obtained a match with the theoretical and experimental values.

V.P2.31
16:00
Authors : Daniele Menossi°, Elisa Artegiani°, Andrei Salavei°, Simone Di Mare°, Fabio Piccinelli*, and Alessandro Romeo°
Affiliations : °LAPS-Laboratory for Applied Physics, Department of Computer Science, University of Verona, Ca' Vignal 1, Strada Le Grazie 15, 37134 Verona, Italy; *Department of Biotechnology, University of Verona, Strada Le Grazie 15, 37134 Verona, Italy

Resume : CdTe solar cells have recently reached the highest conversion efficiencies, comparable to CuInGaSe2 and Si devices. Moreover they still are a step ahead in terms of industrial scalability and reproducibility. One of the key factors for this success is the so-called “activation” treatment, which typically consists in depositing a CdCl2 film on the CdTe absorber layer and in a subsequent annealing in air or nitrogen atmosphere. Nevertheless CdCl2 is a carcinogenic and water-soluble compound; for this reason recent studies have found MgCl2 as a good alternative. In this work we have studied devices (exceeding 13% efficiency) prepared by low-substrate temperature CdTe deposition and activated with MgCl2 treatment (applied by wet deposition). The devices were characterized by of capacitance-voltage, drive level capacitance profiling and admittance spectroscopy techniques. Carrier concentration and also concentration and distribution of shallow and deep defects are presented and compared with data taken from analogous devices but made with the standard CdCl2 activation treatment. Despite similar structural properties of the CdTe layers treated with the two different processes (analyzed by X-ray diffraction and atomic force microscopy), the distribution of deep and shallow defects resulted to be different in the two cases and admittance spectroscopy technique reveals the presence of different defects.

V.P2.32
16:00
Authors : Elisa Artegiani°, Daniele Menossi°, Andrei Salavei°, Simone di Mare°, Fabio Piccinelli*, and Alessandro Romeo°
Affiliations : °Laboratory for Applied Physics, Department of Computer Science, University of Verona, Ca' Vignal 1, Strada Le Grazie 15, 37134 Verona, Italy; *Department of Biotechnology, University of Verona, Strada Le Grazie 15, 37134 Verona, Italy

Resume : CdTe solar cells have demonstrated very high efficiency with latest results from First Solar that have shown a record efficiency of 21.5%. One of the crucial points for high efficiency is the insertion of copper that dopes CdTe and delivers a good ohmic contact, however it contributes to cell degradation. For this reason other degradation effects are generally neglected. However in a recent work we have shown that the performance degradation of the solar cells (measured at different time steps, having stored the devices under one sun at 80°C) is also depending on the TCO. In this work CdTe solar cells were prepared with different transparent conductive oxides (TCO), namely indium tin oxide (ITO), fluorine doped tin oxide (FTO) and a bi-layer ITO/ZnO. The finished devices perform quite similar conversion efficiencies and exhibit similar morphology (analyzed by atomic force microscopy) and structural properties (studied by x-ray diffraction). We confirm that aged cells show that stability is connected with the different TCOs: ITO based devices show a limited stability compared to the other ones. Analysis of capacitance-voltage and drive level capacitance profiling shows a different defects distribution for solar cells with less stable front contact. Moreover here we reveal by admittance spectroscopy (performed at different temperatures) the presence of impurities coming from the glass and from the front contact degrading the cells conversion efficiency.

V.P2.33
16:00
Authors : N. Spalatu, V.Mikli, J. Hiie, M. Krunks
Affiliations : Laboratory of Thin Film Chemical Technologies, Department of Materials Science, Tallinn University of Technology, Ehitajate tee 5, 19086 Tallinn, Estonia

Resume : Traditional CdCl2 thermal treatment of CdTe/CdS heterostructure results in grain growth, sintering and incorporation of Cl into CdTe lattice, substantially improving performance of the cells. The process is complicated by high vapor pressure of CdCl2 and presence of oxygen. Considering volatility of CdCl2 and presence of residual oxidation products we provide systematic comparative study of CdCl2 treatment in air, in evacuated quartz ampoules and in a process tube under nitrogen normal pressure for CSS CdTe films (thickness 2-3 µm) deposited at 200 and 500 oC onto roughned glass. The films treated in air at 420 oC have high resistivity (106 Ω×cm) , high dark to light resistance ratio (25≤KF≥13 and 50≤KF≥35 for 200 and 500oC respectively) and intense photoluminescence band at 1.5 eV. Treatment in ampoules and in the process tube at 600 oC decreases the resistivity up to 4 orders of magnitude and dark to light resistance ratio (1.3≤KF≥1.2) of the films. P-type resistivity around 102 Ω×cm and dark to light resistance ratio KF ~1.02 of CdTe films was achived by subsequent vacuum annealing at 470 oC. Hall effect measurements indicate a p-type conductivity with carrier density of 1015 cm-3 and hole mobility about 1 cm2 V−1 s−1. The low value of mobility suggests the need for optimization of CdCl2 concentration for stronger sintering which implyies dcreased density of grain boundaries. By controlling the thermal annealing conditions, substantial improvement of CdTe opto-electronic properties has been achieved.

V.P2.34
16:00
Authors : H. Y. Ueng*, H. M. Weng**
Affiliations : :*Department of Electronic Engineering, Chang Gung University, 333 ; Taiwan **Institute of Electronics Engineering, National Chiao Tung University, Hsinchu, 300 Taiwan

Resume : In this study, the p-i-n structure of homojunction CdTe solar cell was fabricated by electrodeposition. The kinetic model based on the Butler-Volmer equation was developed and used to obtain the potential of perfect stoichiometric (PPS) under a variety of deposited conditions. Kinetically model and numerical simulation of CdTe thin film deposition process were confirmed experimentally. Owing to the critical quality of the CdTe layer of i-region is required, which leads to high efficiency photovoltaic cell. Therefore , the electrodeposition process of i-layer of CdTe cell is improved to act as the best the dominant strategies to achieve the ideal efficiency of CdTe solar cell. By precise potential-control during electrodeposition process, the intrinsic CdTe thin film with near-stoichiometric, n-type CdTe film with Cd-rich and p-type CdTe film with Te-rich non-stoichiometric films were obtained, respectively. The defect engineering process was used to improve the quality CdTe thin film for photovoltaic cell. Theoretical approach was used to improve the performance of solar cell by varying the electrodeposition parameters, Hence, the high efficiency p-i-n CdTe photovoltaic cell can then be achieved. CdTe with special property is very well suited for use as active material in thin-film solar cells s [1]. [1] R.D. Engelken and T.P. Van Doren, J. Electro -chem. Soc., I32 (1985) 2910.

V.P2.35
16:00
Authors : B. Späth(1), C. Drost(1), V. Krishnakumar(1), C. Kraft(1), B. Siepchen(1), A. Delahoy(2), X. Tan(2), K. Chin(2), S. Peng(3), D. Hirsch(4), O. Zywitzki(4), and H. Morgner(4)
Affiliations : (1) CTF SOLAR GmbH, Zur Wetterwarte 50, Haus 303, 01109 Dresden, Germany (2) Physics Department and CNBM New Energy Materials Research Center, New Jersey Institute of Technology, Newark, NJ 07102, USA (3) China Triumph International Engineering Co. Ltd, Shanghai, China (4) Fraunhofer Institute for Organic Electronic, Electron Beam and Plasma Technology FEP, Winterbergstrasse 28, 01277 Dresden, Germany

Resume : Close spaced sublimation (CSS) is one of the leading technologies for the deposition of absorber layer for CdTe solar cells. For the large scale production CSS means a dynamic process where the substrates are moved above the crucible at a close distance. CdTe layers of 3-4 µm can be grown in less than one minute. In this study oxygen as a process gas is injected during dynamic CSS deposition. Solar cells are prepared from these layers by chlorine activation, copper doping and back contact deposition. The samples are investigated using current voltage measurement, quantum efficiency (EQE), scanning electron microscopy (SEM) of cross sections, deep level transient spectroscopy (DLTS) and photo reflectance (PR). The results show that the precise introduction of oxygen can improve the solar cell efficiency. The reasons of this effect are discussed in this study.

V.P2.36
16:00
Authors : E. Zielony1, E. Płaczek-Popko1, A. Racino1, Z. Gumienny1, S. Chusnutdinow2 and G. Karczewski2
Affiliations : 1 Department of Quantum Technologies, Faculty of Fundamental Problems of Technology, Wroclaw University of Technology, Wybrzeże Wyspiańskiego 27, 50-370 Wroclaw, Poland 2 Institute of Physics, Polish Academy of Sciences, al. Lotnikow 32/46, 02-668 Warsaw, Poland

Resume : We report on the electrical properties of CdTe-based photocells grown by MBE method on the semi-insulating (100) GaAs substrate. The diodes with two different absorbers: CdTe and CdMgTe were analyzed. The dark current–voltage (I–V) characteristics measured in the temperature range of 77–320K reveal the dominant carrier transport mechanisms through the junctions. The studied diodes exhibit strong rectifying properties, however the obtained ideality factor value is greater than unity suggesting that the diodes are not ideal ones. The double logarithmic forward bias dark I–V plots indicate that the charge transport mechanism in a wide voltage range is governed by the space charge limited current, moreover, in the case of the diodes with CdMgTe absorber - with the participation of deep traps which are exponentially distributed in the band gap. From the temperature dependence of saturation current the activation energies of the traps present in the studied junctions were calculated and their possible origin has been ascribed. The light I–V characteristics were measured under 1-sun illumination. The diodes exhibit a significant photosensitivity for different light intensities proving that they can be regarded as good candidates for photodiode applications. From the analysis of double logarithmic plot of short-circuit current vs. applied illumination it was found that the trapping centers govern the current flow through the junction what is in agreement with dark I-V analysis.

V.P2.37
Start atSubject View AllNum.Add

CZTSSe growth : C. Platzer-Björkman, A. Redinger
08:30
Authors : G. Larramona1, S. Bourdais1, A. Jacob1, C. Choné1, B. Delatouche1, C. Moisan1, F. Donatini2, G. Rey3, S. Siebentritt3, A. Redinger4, T. Unold4, and G. Dennler1
Affiliations : 1 IMRA Europe S.A.S., 220 rue Albert Caquot, F-06904 Sophia Antipolis (France); 2 Université Grenoble Alpes, CNRS Institut NÉEL, F-38042 Grenoble, France; 3 Laboratory for Photovoltaics, University of Luxembourg, 41, rue du Brill, L-4422 Belvaux, Luxembourg; 4 Helmholtz-Zentrum Berlin für Materialien und Energie (HZB), Hahn-Meitner-Platz 1, D-14109 Berlin, Germany.

Resume : Our CZTSSe technology, based upon the instantaneous precipitation of CZTS nanoparticles, the spray coating of a water-ethanol colloid and the subsequent annealing of the films in a chemically controlled environment, allowed us recently to reach an efficiency of 10.8%. Among the various possible levers we have tuned, it appeared that controlling the Sn content was essential to reduce the number of deep defects, and thereby achieve this level of performances. Further light-management optimizations yielded an increase in the photocurrent that translated in a maximum of 11.5% power conversion efficiency under AM1.5G. In spite of this encouraging value close to the best ones reached with vacuum processes or liquid processes based upon less environment friendly solvents, the Voc deficit at work in these devices still appears prohibitive. We have performed detailed investigations in order to identify the potential sources of this major loss. Our study reveals that i) the Cu/Zn order/disorder is not the main culprit of the Voc deficit, ii) in spite of the latter observation, high ordered CZTSSe is preferred because of much lower non-radiative recombination, iii) Quasi-Fermi-Level-Splitting measurement suggest that the majority of the Voc losses occur in the bulk of the photoactive materials and not at an interface. All these new results obtained on efficient devices will be discussed together with the strength, impact, and potential origin of Urbach tails.

V.V.1
09:00
Authors : G. Altamura1*, S. Temgoua1,3, N. Naghavi1,3, R. Bodeux1,2,3
Affiliations : 1 Institut Photovoltaïque d’Île-de-France (IPVF), 8, rue de la Renaissance 92160 Antony, France 2 EDF R&D, IRDEP, 6 Quai Watier, 78400 Chatou Cedex, France 3 CNRS, IRDEP, 6 Quai Watier, 78400 Chatou Cedex, France

Resume : Cu2ZnSnS4 (CZTS) compound with a bandgap of 1.5 eV is a promising candidate for low-cost, high-efficiency thin film as well as tandem solar cells. These earth abundant elements make this compound a feasible option for photovoltaic (PV) thin film technologies scalable to TW/year. The key limitation to high efficiency PV conversion for this compound remains optimization of the growth conditions. In this paper we present the possibility to increase PV efficiency in Mo/CZTS/CdS/ZnO solar cells fabricated by two step annealing process starting from co-sputtering precursor performing (i) sequential etching of CZTS using KCN, KMnO4/H2SO4 + Na2S, HCl solutions [1-2] allowing to adjust cationic ratio at the absorber surface, (ii) sodium incorporation using NaCl and NaF powders during annealing allowing to increase absorber grain size, (iii) post-annealing treatment of completed device ranging from 200 to 250 °C which improved CZTS/CdS interface. A comparative study of Cu2ZnSnS4 and Cu2ZnSnSe4 absorbers was later performed. Overall efficiency of more than 8% has been obtained for Cu2ZnSnSe4 based solar cells. Also an open circuit voltage of 510 mV was extracted after post-annealing treatment due to an increase of carrier concentration. [1] A. Fairbrother et al., J. Am. Chem. Soc. 2012, 134, 8018 [2] S. López-Marino et al., Chem. Eur. J. 2013, 19, 14814

V.V.2
09:15
Authors : J.K. Larsen, Y. Ren, N. Ross, E. Särhammer, C. Platzer-Björkman
Affiliations : Ångström Solar Center, Solid State Electronics, Engineering Sciences, Uppsala University, Box 534, 75121 Uppsala, Sweden; Ångström Solar Center, Solid State Electronics, Engineering Sciences, Uppsala University, Box 534, 75121 Uppsala, Sweden; Ångström Solar Center, Solid State Electronics, Engineering Sciences, Uppsala University, Box 534, 75121 Uppsala, Sweden. Centre for Materials Science and Nanotechnology, University of Oslo, Box 1126, Blindern, 0318 Oslo, Norway; Ångström Solar Center, Solid State Electronics, Engineering Sciences, Uppsala University, Box 534, 75121 Uppsala, Sweden; Ångström Solar Center, Solid State Electronics, Engineering Sciences, Uppsala University, Box 534, 75121 Uppsala, Sweden

Resume : While substantial research on the Cu2ZnSn(SxSe1-x)4 [CZTSSe] materials system is focused on either the pure selenide (x=0) or sulfide (x=1), the highest efficiencies are obtained for alloys containing both sulfur and selenium. One of the potential advantages of such alloys is the possibility to obtain a band gap grading. This work presents initial experiments aiming for this goal. A sulfur containing Cu-Zn-Sn-S precursor was deposited by reactive sputtering from binary targets. This precursor was then annealed in a graphite box containing selenium. Various process parameters were investigated to optimize the process including background pressure, temperature and annealing time. It is demonstrated how the precursor gradually selenizes as a function of annealing time, but no S/Se gradient is observed in initial experiments. As part of the optimization air annealing of the bare absorber was investigated. A significant improvement of the device efficiency was observed when increasing the air annealing temperature from 100 C to 300 C. The effect of air annealing on the absorber surface was investigated by XPS. The results indicate that SnO, SeOx and Na compounds form on the surface during air annealing. These are removed in the subsequent etching in either ammonia or KCN. The highest efficiency obtained for an air annealed CZTSSe solar cell in this study was 9.7%. Starting from devices with efficiencies in this range, we will aim to introduce an S/Se grading.

V.V.3
09:30
Authors : S. Giraldo(1), P. Pistor(1), L. Arqués-Farré(1), V. Izquierdo-Roca(1), A. Pérez-Rodríguez(1,2), E. Saucedo(1)
Affiliations : (1) Catalonia Institute for Energy Research (IREC), Jardins de les Dones de Negre 1, 08930 Sant Adrià de Besòs, Spain; (2) IN2UB, Departament d’Electrònica, Universitat de Barcelona, C. Martí i Franquès 1, 08028 Barcelona, Spain

Resume : Among the possible new photovoltaic materials, kesterites is one of the most promising due to the combination of abundant elements, stability, technological robustness and potential for good devices performance. The reactive annealing process under chalcogen atmosphere (sulfurization and/or selenization) is the most critical process step during sequential kesterite absorber preparation. Here, we report on the optimization of the reactive thermal annealing in Se atmosphere for the synthesis of CZTSe absorbers. In our sequential approach, the metallic precursors are first sputter-deposited and then selenized during the reactive thermal annealing. We compare thermal routines with two and three stages and varying temperature, dwelling time, heating ramps and Se partial-pressure. It is observed that efficiencies in the 9.0-10.0% range can be obtained with two and three stage processes. In general, we find best efficiencies with fast ramping (>50ºC/min), intermediate dwelling time for the high temperature steps (<30 min), high Se vapor pressure (400 mg of Se in 69 cm3 volume), and higher temperatures (570-600 ºC). Using a set of complementary morphological, optical, structural and electrical characterization techniques, we demonstrate that these conditions promote the formation of large grains with better crystal quality and improved charge transport properties. These conditions lead to devices with a maximum efficiency of 10.6%.

V.V.4
09:45
Authors : Charles J. Hages (1), Sergej Levcenco (1), Alex Redinger (1), Hengameh Navirian (1), Dieter Greiner (2), Thomas Unold (1)
Affiliations : (1) Dept. of Structure and Dynamics of Energy Materials, Helmholtz-Zentrum Berlin für Materialien und Energie, Berlin, Germany; (2) PVComB, Helmholtz Zentrum für Materialien und Energie, Berlin, Germany

Resume : Recent work has aimed to determine the origin of performance limitations in kesterite solar cells, namely through current-voltage (JV) and quantum efficiency (QE) analysis [1,2]. In this work, detailed voltage-, temperature-, and intensity-dependent QE analysis is applied and further developed to understand recombination and diffusion limitations for kesterites; devices with a variety of processing conditions, compositions, and efficiencies are considered. Analysis on related materials, namely CIGSe with >17% efficiency, is also performed for comparison of the analysis method and results in understanding the performance gap relative to kesterites. First, voltage-dependent QE is used to distinguish between collection/voltage losses due to diffusion and that of photocarrier recombination; this analysis affords relevant diffusion, absorption, and recombination parameters. Next, light-bias QE and intensity-dependent JV is used to characterize non-idealities of the injection current/collection efficiency and their impact on data analysis. Lastly, temperature-dependent QE is considered to understand the origin of photocarrier recombination as well as to investigate photoconductivity and the temperature-dependence of diffusion and absorption parameters. While CZTSSe and CIGSe can exhibit similar diffusion limitations, CZTSSe is characterized with detrimental photocarrier recombination in forward bias.[1] Hages et al., JAP, 115, 23504 (2014); [2] Hages et al., JAP, 119, 014505 (2016)

V.V.5
10:00 Coffee break

CZTSSe growth and other aspects : J. Larsen, C. Hages
10:30
Authors : Yi Zhang, Jianjun Li, Hongxia Wang
Affiliations : Y. Zhang and J. Li: Institute of Photoelectronic Thin Film Devices and Technology, Nankai University, Tianjin 300071, P.R. China; H. Wang: School of Chemistry, Physics and Mechanical Engineering, Science and Engineering Faculty, Queensland University of Technology, Brisbane, QLD4001, Australia

Resume : It is known that charge carrier depletion width at the hetero-junction interface is one of the key parameters that affect the performance of thin film solar cells. The relative dielectric constant of kesterite Cu2ZnSn(Sx,Se1-x)4 varies from 6.8 to 8.6 as x changes from 1 to 0 according to theoretical calculation and experimental results. Based on this result, the carrier density of CZTSSe absorber is generally in the range of 5×1015 ~ 1×1016 cm−3, and the depletion region width (Wd) is typically in the range of 150~220 nm. Generally speaking, a narrow depletion region is not only adverse to the photo-generated charge carrier collection in thin film solar cell, especially for the charge generated at the long wavelength region close to band edge, but also may lead to increased interface recombination and tunnel recombination, which result in significant open circuit voltage (VOC) loss. Hence, increase of the depletion region width of CZTSSe solar cells is crucial to push the performance of CZTSSe solar cells to a higher level. In this study, high performance Cu2ZnSn(S,Se)4 (CZTSSe) solar cells are fabricated by selenization of the precursor films of Mo/Sn/Cu/ZnS/Sn/ZnS/Cu deposited by magnetron sputtering. The investigation of the solar cells with different Zn/Sn ratio in CZTSSe film discloses that the charge carrier concentration and depletion region width of the device is very sensitive to Zn/Sn ratio of CZTSSe layer. The CZTSSe film with Zn/Sn=1.05 has lower carrier density (5.0 × 1015 cm−3), which is half of the cell with Zn/Sn=1.12, whereas the depletion region at the CdS/CZTSSe hetero-junction interface of the former (200-250 nm) is 100 nm longer than the latter. As a result, better collection of photo-generated charge carrier is found with the cell with longer Wd in the longer wavelength region above 800 nm. Therefore, the average power conversion efficiency is increased from 6.53% to 9.16% with enlarged depletion region width, and the best performance with 10.2% efficiency is achieved.

V.VI.1
10:45
Authors : A. Crossay, D. Colombara, M. Melchiorre, M. Guennou, B. Mendis, P. J. Dale.
Affiliations : Physics and Materials Science Research Unit, Université du Luxembourg, 41, rue du Brill, L-4422 Belvaux, Luxembourg; Physics and Materials Science Research Unit, Université du Luxembourg, 41, rue du Brill, L-4422 Belvaux, Luxembourg ; Physics and Materials Science Research Unit, Université du Luxembourg, 41, rue du Brill, L-4422 Belvaux, Luxembourg ; Luxembourg Institute of Science and Technology, 41, rue du Brill, L-4422 Belvaux, Luxembourg; Department of Physics — Durham University, Durham DH13LE, United Kingdom; Physics and Materials Science Research Unit, Université du Luxembourg, 41, rue du Brill, L-4422 Belvaux, Luxembourg.

Resume : Efficient Kesterite devices require absorber layers free from detrimental secondary phases. The highest efficiency devices are grown in the two phase Kesterite + Zn(S,Se) region. To reduce its current blocking effects, Zn(S,Se) should preferably form on the absorber surface and grow in nanometer sized islands or be removed. Zn(S,Se) formation and distribution is not well understood for absorber layers synthesized from metallic precursors. We show that the size and distribution of the ZnSe phase depends on the size and distribution of the metal alloys that form during the heating of the precursor, before selenization. This conclusion was enabled by a method that we developed to perform all analyses (SEM, EDX, micro-Raman, micro-PL) on a sample in one identical location, therefore tracking all changes occurring during each step of the process. Absorbers were prepared by electrodeposition of Cu/Sn/Zn layers followed by pre-alloying at 350°C and annealing in Se/SnSe atmosphere, allowing us to achieve a best efficiency of 7%, comparable to the best reported device of 8.2 % with a similar process. As-deposited metals form smooth continuous layers, whilst after pre-alloying 5-20 micron CuZn alloy islands are formed surrounded by a Sn rich matrix. After selenization, analysis reveals that Kesterite forms everywhere but ZnSe mostly formed on the Sn rich matrix! In order to reduce the size of the ZnSe areas on the absorber, smaller CuZn islands or longer selenization times are required.

V.VI.2
11:00
Authors : Hong Nhung Pham(1,2), Yoon Hee Jang(1), Bo-In Park(3), Seung Yong Lee(3), and Doh-Kwon Lee(1,2)*
Affiliations : (1) Photo-electronic Hybrids Research Center, Korea Institute of Science and Technology (KIST), Seoul, KOREA; (2) Department of Nanomaterials Science and Engineering, Korea University of Science and Technology (UST), Daejeon, KOREA; (3) Center for Materials Architecturing, Korea Institute of Science and Technology (KIST), Seoul 136-791, Korea;

Resume : In the Cu2ZnSnSe4-based device structure, a proper thickness of MoSe2 layer in the back contact is known to enhance adhesion and ohmic contact between the Mo back contact and absorber layer. However, a high-temperature chalcogenization process to realize highly crystalline absorber films with large grains often induces the formation of thick MoSe2 layers, which may cause additional series resistance in the system, thus resulting in low device performance. In this study, by in-situ deposition of an ultra-thin molybdenum nitride film as a barrier layer in the back contact structure without substantially increasing its total resistance, we were able to control the thickness of MoSe2 layer. The evolution of crystalline phase and stoichiometry were thoroughly investigated as a function of nitrogen partial pressure during sputtering of Mo-N interlayers. As the nitrogen partial pressure increased, cubic Mo, cubic Mo2N, and hexagonal MoN phases were developed in sequence. All of the Mo-N phases were found to be effective as a barrier layer against MoSe2 formation in the Cu2ZnSnSe4 devices prepared from mechanochemically-synthesized quaternary nanocrystals. Among different Mo-N phases, however, the Mo2N phase turned out to offer the best intermediate layer in the Mo/Mo2N/Mo multi-layered back contact structure, leading to the greatest improvement in the solar cell efficiency up to 8.31%.

V.VI.3
11:15
Authors : Stefan G. Haass, Matthias Diethelm, Christian Andres, Yaroslav E. Romanyuk, Ayodhya N. Tiwari
Affiliations : Empa – Swiss Federal Laboratories for Materials Science and Technology, Laboratory for Thin Films and Photovoltaics, Ueberlandstrasse 129, 8600 Duebendorf, Switzerland

Resume : Post deposition treatment (PDT) of CIGS solar cells with Potassium is known to be beneficial to both open circuit voltage and fill factor and is therefore crucial for obtaining the highest efficiencies. Here we investigate the impact of Potassium incorporation at different stages of the solution processing of kesterite CZTSSe absorbers and its effect on the opto-electronic properties of solar cells. The different incorporation strategies include the addition of potassium to the precursor solution, pre-deposition of a KF layer onto the precursor before the selenization step, and a PDT with KF of the selenized absorber in a separate annealing step. The experiments were conducted with and without additional Sodium doping in order to understand the intrinsic and combined effects of two alkali dopants. The respective solar cells were examined utilizing advanced characterization methods as admittance spectroscopy (AS), time-resolved photoluminescence (TRPL) and external quantum efficiency (EQE) measurements. Potassium incorporation before the selenization step yields an improved grain growth similar to the effects of Sodium, resulting in a higher minority carrier lifetime, improved EQE in the long-wavelength region, and improved short circuit current. Incorporation of Potassium prior to selenization changes the doping concentration as revealed by AS. Interesting results are observed for the PDT with KF, which leads to a blocking of the device resulting in a collapse of the fill factor, the short circuit current and hence the efficiency, whereas the open circuit voltage and the minority carrier lifetime improve on the other hand.

V.VI.4
11:30
Authors : C. Platzer-Björkman, C. Frisk, J. K. Larsen, T. Ericson, S.-Y. Li, J. Scragg, J. Keller, F. Larsson and T. Törndahl
Affiliations : Ångström Solar Center, Solid State Electronics, Engineering Sciences, Uppsala University, Box 534, 75121 Uppsala, Sweden

Resume : We investigate exchange of the standard CdS buffer layer in Cu2ZnSnS4 (CZTS) solar cells with Zn1-xSnxOy (ZTO). For sulfide CZTS, the band alignment between CZTS and CdS is not ideal (“cliff-like”), which enhances interface recombination. In this work, we show how a ZTO buffer layer results in improved open circuit voltage values (Voc) for CZTS devices as compared to using a CdS buffer layer. The ZTO is deposited by atomic layer deposition (ALD), with a process previously developed for Cu(In,Ga)Se2 solar cells. By varying the ALD process temperature, the position of the conduction band minimum of the ZTO is varied in relation to that of CZTS. A ZTO process at 95°C is found to give higher Voc and efficiency values as compared to the CdS reference devices. For a ZTO process at 120 °C, the Voc and efficiency values are similar to those of the CdS reference. This is compatible with an expected conduction band alignment similar to that of CdS. The position of the conduction band minimum can be further increased as compared to CZTS by lowering the ZTO deposition temperature to 80 °C. These devices show blocking of forward current and reduced fill factor, which is consistent with barrier formation at the junction. Temperature-dependent current voltage analysis measures the activation energy for recombination to be 1.36 eV for the best ZTO device as compared to 0.98 eV for CdS. Therefore, we argue that the Voc of the best ZTO devices is limited by bulk recombination, which is in agreement with a room temperature photoluminescence peak at around 1.3 eV for both devices, while the CdS devices are limited by interface recombination.

V.VI.5
11:45
Authors : Alex Redinger, Thomas Unold
Affiliations : Helmholtz-Zentrum Berlin für Materialien und Energie, Department Structure and Dynamics of Energy Materials, Hahn-Meitner-Platz 1, 14109 Berlin, Germany

Resume : Kesterite absorbers often undergo a post deposition chemical and/or heat treatment in order to improve the power conversion efficiency of the resulting solar cell devices. Passivation of grain boundaries and changes in the chemical composition in the near surface region and at the grain boundaries are discussed in literature. In order to investigate the origins of the efficiency improvements amplitude modulated Kelvin Probe Force Microscopy (KPFM) is carried out on selenium based absorbers with efficiencies in the range of 6-7%. We measure large variations in the workfunction on the as-grown absorbers (FWHM>100meV). Upward and downward band bending at grain boundaries are observed. The workfunction variations can be divided in two categories: Grain to grain changes, which can be linked to the different crystallographic orientations and small intra-grain variations on the length scale of roughly 100nm. All measurements are carried out on as-grown absorbers, after rinsing with H2O and NH4OH and after several different heat treatments in order to study the evolution of the workfunction after the different processing steps. In order to quantify the impact of the treatments on device performance the KPFM measurements are supplemented with calibrated photoluminescence measurements where the quasi-fermi level splitting and consequently the open-circuit voltage can be extracted.

V.VI.6
12:00 Lunch break
14:00
Authors : Soraya Abdelhaleem (1,3), A. E. Hassanien (1,4), Matthias Schuster (1), Monica Distaso(2), Peter Wellmann (1)
Affiliations : (1) Materials Department 6, Friedrich-Alexander-University Erlangen-Nürnberg (FAU), Martensstraße 7, 91058 Erlangen, Germany; (2)Institute of Particle Technology, Friedrich-Alexander-Universität Erlangen-Nürnberg (FAU), Cauerstr. 4, 91058 Erlangen, Germany; (3) Radiation Physics Department, National Center for Radiation Research and Technology, Po Box 29, Nasr City, Cairo, Egypt; (4) Physics Department, Faculty of Science, Helwan University, 11795 Helwan, Egypt.

Resume : Cu2ZnSnS4 (CZTS) nano-particles ink was successfully synthesized by a simple solvothermal method. A low cost non-vacuum method was used to deposit the ink on Mo-coated glass substrates by doctor blade process followed by selenization in a tube furnace to form CZTSSe layer. Different selenization conditions and particle concentrations were considered in order to improve the crystallinity and surface morphology, the annealing temperature was varied between 400 oC to 550 oC and the annealing time was varied between 5 to 20 min in selenium containing nitrogen atmosphere. The influence of selenization conditions variation on the structural and morphological characteristics of the films was investigated to reach the optimum conditions. To figure out the structure of the deposited layers and the presence of secondary phases, X-ray diffraction analysis and Raman spectroscopy were used. The morphology and the homogeneity of the layer were investigated using SEM. The best layers and homogeneous films were achieved using CZTS nano-particles concentration of 150 g/l, temperature range of 475 - 525 oC and time of 10 min.

V.P3.1
14:00
Authors : Christian Andres (1), Stefan G. Haass (1), Manoj Vishwakarma (2), Deepak Varandani (2), Bodh R. Mehta (2), Yaroslav E. Romanyuk (1), Ayodhya N. Tiwari (1)
Affiliations : (1) Laboratory for Thin Films and Photovoltaics, Empa-Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstr. 129, 8600 Duebendorf, Switzerland; (2) Thin Film Laboratory, Department of Physics, Indian Institute of Technology Delhi, New Delhi 110016, India.

Resume : Kesterite solar cells (Cu2ZnSn(S,Se)4) are considered to be a sustainable alternative to highly efficient chalcopyrite (CIG(S,Se)2) solar cells albeit the highest efficiency is currently limited to 12.6%. Preparation of kesterite absorber by sputtering of metal precursor with subsequent annealing is a well-established technique to obtain controlled and reproducible compositions with a possibility to introduce metal gradients with respect to bandgap engineering at the interfaces. In contrast to a stacked layer arrangement, where intermixing of the individual elements is highly dependent on the annealing conditions, we employ confocal co-sputtering of elemental metal targets to obtain homogenous precursor. An evaporated Se top layer guarantees uniform absorber formation during rapid thermal annealing. Based on a reproducible baseline process yielding >7% solar cells on 5x5cm2 substrates, a systematic study is performed on how precursor composition influence the absorber morphology and device performance. By reducing the Zn content, the formation of ZnSe is decreased as revealed by EDX, XRF and SEM measurements. An enhanced grain growth is observed using higher temperatures during the annealing step. KPFM measurements are performed on complete devices using a novel contacting approach to highlight the contribution of grain boundaries and compositional inhomogeneities to the Voc.

V.P3.2
14:00
Authors : Remi Aninat, Luis-Enrique Quesada-Rubio, Emilio Sanchez-Cortezon, Jose-Maria Delgado-Sanchez
Affiliations : Abengoa; Abengoa; Abengoa; Abengoa

Resume : Kesterite absorber layers are promising in terms of cost and material abundance, but still lag relatively far behind Cu(In,Ga)Se2 (CIGS) in terms of device efficiency. This raises questions about their potential for large scale production. This work aims at assessing the challenges of scaling up the existing PVD processes of Cu2ZnSnSe4, Cu2ZnSnS4 or Cu2ZnSn(S,Se)4 for industrial fabrication. Through literature review and exchanges within the European project Kestcells, the main issues that can affect kesterite and their causes are listed. These issues are then prioritized in terms of criticality for the process, using the methodology of Design Failure Mode and Effects Analysis (D-FMEA). This analysis indicates, in particular, that bandgap and electrostatic potential fluctuations are the most critical risks to date for the fabrication process, not so much because of their impact on efficiency than because of the inability to detect them or prevent them in the current state of our understanding. Applying the acquired knowledge to the known fabrication routes for kesterite, it is shown that some of the most critical shortcomings can originate from unsuitable metallic ratios in the precursor and the absorber. In this respect, the volatility of Sn in kesterite fabrication processes is an important challenge. In the current state of the technology, this volatility forces the sequential route (i.e. deposition/selenisation) even on co-evaporation processes that would otherwise have benefited from the maturity of the higher throughput 1-step industrial processes currently used for CIGS by companies such as Solibro, Manz or Miasolé for example.

V.P3.3
14:00
Authors : Özge BAYRAKLI^1,2, Hasan Huseyin GULLU^1,2, Mehmet PARLAK^1,2
Affiliations : 1Department of Physics, Middle East Technical University (METU), Ankara 06800, Turkey; 2Center for Solar Energy Research and Applications (GÜNAM), METU, Ankara 06800, Turkey

Resume : Copper Zinc Tin Selenide (Cu2ZnSnSe4, or CZTSe) is emerging as an potential absorber material to the present thin film solar cell technologies, alternative to the industrially produced thin film solar cell structures, Cu(In,Ga)Se2 (CIGS) and CdTe. Although CIGS thin film based solar cell applications can reach to the world record efficiency, in the availability on In for highly demand on these type cells, have been directed the market to the cost-effective materials. Therefore, by identifying the earth’s abundant solar energy materials with suitable material characteristics to reduce the cost of solar cell have been attracted to technologically material changes from In/Ga to Zn/Sn [1]. In fact, compared to the traditional thin film based solar cell absorber layers, all the elements in CZTSe are abundant, environmental-friendly, and inexpensive [1, 2]. In addition, CZTSe has suitable band gap energy of 1.4–1.5 eV which is the ideal range for converting the maximum amount of energy from the solar spectrum into electricity. CZTSe has a good light absorption characteristics with high absorption coefficients (>104cm^-1 in the visible region) and only a few micron thick layer of CZTSe can absorb all the photons with energies above its band gap. In addition, solar cells based on these novel structures have already reached power conversion efficiency >10% [3, 4]. However, there are still limited works on CZTSe, and in this study, CuZnSnSe2 quaternary structure has been studied under different post-thermal heating processes to determine the stoichiometric, single phase and poly crystalline structure. Then, these different kinds of CZTS thin film samples have been characterized to provide structural, optical and electrical properties of the samples under the insight of possible solar cell application. To obtain this film structure, elemental Cu, Zn and Sn and Se sources were thermally evaporated on ultrasonically cleaned soda-lime glass substrates in a stacked layer form. During the deposition process, the substrate temperature was kept at about room temperature and the vacuum was controlled at about 10^-6 Torr. Then, different annealing procedures were applied both during and the after the deposition. Firstly, after the deposition process, the films were selenized with Se evaporation at the substrate temperature of 200 °C under the pressure of 10^-6 Torr. Under this ambiance, thin films annealed for one hour (CZTSe-1). After annealing, three sample sets were prepared; one of them were kept in as-grown form, another set were annealed at 300 °C under vacuum condition (CZTSe-2) and the other samples were annealed at 400 °C under Se environment (CZTSe-3). The structural and the morphological evolution were analyzed by means of X-ray Diffraction (XRD), Raman spectroscopy, energy dispersion X-ray spectroscopy (EDS), scanning electron microscopy (SEM) and atomic force microscopy (AFM). Moreover, the optical characteristics of these samples for selenized just after the deposition, and annealed under vacuum and Se evaporation conditions were determined in detail and it was observed that there has been a remarkable influence of annealing on these quantities. It was determined that these changes affected the band gap values relating with the structural changes with annealing. To complete the material characterization processes, the electrical and photo electrical properties of the films have been investigated by carrying out temperature dependent conductivity, photo conductivity under different illumination intensities in the temperature range 100–400 K, and Hall effect and photo response measurements between 300 and 1200 nm at room temperature. [1] S. R. Kodigala, Thin Film Solar Cells from Earth Abundant Materials, Elseiver, USA, 2014 [2] X. He, H. Shen, W. Wang, B, Zhang, Y. Dai and Y. Lu, J. Mate.r Sci: Mater. Electron. 24 (2013) 572–575 [3] I. V. Bodnar, V. F. Gremenok, W. Schmitz, K. Bente ve T. Doering, Crys. Res. Technol. 39 (2004) 301-307 [4] T.K. Todorov, J. Tang, S. Bag, O. Gunawan, T. Gokmen, Y. Zhu, and D.B. Mitzi, Adv. Energy Mater. 134 (2012) 15644–7

V.P3.4
14:00
Authors : M. Ben Rabeh, M. Kanzari
Affiliations : Université de Tunis El Manar, Ecole Nationale d’Ingénieurs de Tunis, Laboratoire de Photovoltaïques et Matériaux Semi-conducteurs, 1002, Tunis, Tunisie.

Resume : Cu2FeSnS4 (CFTS) compound was prepared by direct reaction of high-purity elemental copper, iron, tin and sulfur. Cu2FeSnS4 thin films were deposited by thermal evaporation under vacuum method on to well-cleaned glass substrates at temperatures ranging from 30 to 200°C. After the deposition, all CFTS thin films were annealed in a furnace in sulfur atmosphere in quartz ampoule sealed at pressure of 10-5Torr and at temperature of 400°C during 1hour so as to optimize the stannite CFTS phase. The formation of stannite structure with (112), (004) and (204) planes in the powder and thin films was confirmed using X-ray diffraction measurements and the crystallites were found to have a preferred orientation along the (112) direction. The estimated absorption coefficient was close to 105 cm−1 in the visible region for all CFTS films, and the values obtained for the optical band gap energy of the films were between 1.30 and 1.46eV. The electrical studies showed that all these samples had p-type conductivity. KEYWORDS: Thin films, Semiconductors, Vapor deposition, X-ray diffraction, Raman spectroscopy.

V.P3.5
14:00
Authors : E. Garcia-Llamas1, J.M. Merino1, R. Gunder2, K. Neldner2, A. Steigert2, D. Greiner2, Y. Sánchez3, E. Saucedo3, R. Klenk2, M. León1, S. Schorr2, R. Caballero1*
Affiliations : 1Universidad Autónoma de Madrid, Departamento de Física Aplicada, C/ Francisco Tomás y Valiente 7, 28049 Madrid, Spain 2Helmholtz Zentrum Berlin für Materialien und Energie, Hahn-Meitner Platz 1, 14109 Berlin, Germany 3IREC, Catalonia Institute for Energy Research, C. Jardins de les Dones de Negre 1, Sant Adriá del Besòs, 08028 Barcelona, Spain

Resume : Cu2ZnSnS4 (CZTS) thin films were deposited onto Mo/glass substrates by thermal evaporation and subsequent thermal treatment in Ar+S atmosphere. CZTS powder was synthesized previously by solid state reaction of the elements to be used as precursor material. 1.5 µm-CZTS films were evaporated at a nominal substrate temperature of 250º C for only 12 minutes. Different thermal treatments at 550º C by using different heating rates were performed. CZTS thin films were investigated by grazing incidence X-ray diffraction (GIXRD), scanning electron microscopy, X-ray fluorescence and Glow Discharge Optical Emission Spectroscopy (GDOES) measurements. SnS secondary phase was identified next to the Mo layer by GIXRD and corroborated by GDOES depth profiles. Solar cells were fabricated by deposition of a CdS buffer and ZnO/ITO or i-ZnO/AZO layers. Different chemical etchings were performed, KCN or (NH4)2S just before the CdS deposition. Moreover, Cd-free solar cells were fabricated by using Zn(O,S) buffer layer. I-V and external/internal quantum efficiency measurements were used to characterize the photovoltaic devices. The presence of SnS limited the efficiency up to 3.2 % (active area) and 1.8 % (total area) for Cd- and Cd-free devices respectively. In this presentation, the effect of the different thermal treatments on the CZTS thin film properties and the device performance will be discussed. These results show the potential of this simple and fast absorber thin film growing method.

V.P3.6
14:00
Authors : Rosa Chierchia, Claudia Malerba, Matteo Valentini, Enrico Salza, Pietro Mangiapane, Alberto Mittiga
Affiliations : Enea C.R. Casaccia DTE-FSN-TEF Dip. di Ingegneria Civile, Ambientale e Meccanica, Università di Trento Dip. di Fisica, Università di Roma, "Sapienza" Enea C.R. Casaccia DTE-FSN-TEF Enea C.R. Casaccia DTE-FSN-TEF Enea C.R. Casaccia DTE-FSN-TEF

Resume : Cu2SnS3 (CTS) is an abundant, less expensive, and non-toxic alternative to other chalcogenide compounds such as CdTe and Cu(In,Ga)(S,Se)2 (CIGS) used as absorber layers in thin-film solar cells. Its low bandgap makes it a good candidate for heterojunction structures with Si. The low diffusion length of the carriers due to the presence of spurious phases, holes, defects and small grain size hampers its use. To improve the crystalline quality we have grown CTS by co-sputtering of target of Cu/SnS on soda lime glass /Mo substrates and later annealed with a two-step process at 250°C for 15 min and 550 °C for 60 min in the presence of sulfur. The intermediate annealing temperature decreases holes, defects and spurious phases in the layer. The quality of our samples has been improved by studying the influence of the deposition and sulphurization parameters on its structural characteristics. Once optimized the film of CTS an heterojunction with Si will be fabricated and characterized.

V.P3.7
14:00
Authors : C.S. Cooper 1,2*, P. Arnou 2, L. Wright 2, S. Ulicna 2, J.M. Walls 2, A.V. Malkov 1 and J.W. Bowers 2
Affiliations : 1 - Department of Chemistry, Loughborough University, Loughborough, Leicestershire, LE11 3TU, UK 2 - Centre for Renewable Energy Systems Technology (CREST), School of Mechanical and Manufacturing Engineering, Loughborough University, Loughborough, Leicestershire, LE11 3TU, UK

Resume : Solution processing of thin film semiconductors is a key area of research in thin film solar cells. These methods avoid the high costs of vacuum based deposition techniques and have a high throughput, ideal for large scale manufacturing. Currently the record efficiency for CZTS was obtained using solutions of binary chalcogenides in hydrazine; however, more recently a solvent combination of dithiol and diamine has been shown as a viable safer alternative. In this study, a novel approach has been developed to deposit CZTSe absorber layers. Using a new safer thiol source, elemental Cu, Zn, Sn and S/Se can be fully dissolved in solution at ambient conditions, with the composition easily controlled. The preparation and the spray deposition of these solutions are performed in air, allowing a quick, easy and inexpensive process. Upon selenization, large crystals can be observed which are identified as CZTSe using XRD and Raman, the latter showing no distinctive signs of any binary or ternary phases. Using this method, high quality CZTS absorber layers have been prepared for use in thin-film solar cells. The sprayed absorbers have been successfully implemented in a solar cell with promising initial results. Further device optimisation and characterization will result in improved device performance. This novel approach is a simple, safe and inexpensive method which is scalable, and can therefore serve as a safer alternative to the hydrazine based process.

V.P3.8
14:00
Authors : Özden Demircioğlu, Jose Fabio Lopez Salas, Germain Rey, Thomas Weiss, Susanne Siebentritt, Jürgen Parisi, Levent Gütay
Affiliations : Laboratory for Chalcogenide Photovoltaics, Energy and Semiconductor Research Laboratory, University of Oldenburg, Oldenburg, Germany; Laboratory for Photovoltaics, University of Luxembourg, Belvaux, Luxembourg

Resume : We have investigated Cu2ZnSnSe4 (CZTSe) two thin films by using spectroscopic ellipsometry (SE), optical transmission, Raman scattering and photoluminescence (PL). Samples were prepared by high temperature co-evaporation. The front surface and the back interface region of the films were analyzed after absorber lift-off from the substrate. We show detailed modeling of SE data which allows extraction of optical parameters from the SE experiments, such as refractive index and extinction coefficient. These were then used to extrapolate the band gap of the absorbers which match the results from optical transmission/reflection measurements and amount to 0.92 and 0.97 eV. The detailed modeling of the SE results further allows for detection of the secondary phases MoSe2 and ZnSe which is confirmed by Raman and PL measurements. PL measurements were done at different excitation wavelengths with the aim of differentiating between the optical transitions of the absorber and of present secondary phases. Surprisingly the position of the main PL peak appears to be at around 0.83 eV for both samples, independently of the extracted band gaps. Furthermore, we discuss a PL peak at 1.2eV which has been assigned as a ZnSe defect transition in literature. We show that the detection of secondary phase ZnSe by observation of this PL peak depends strongly on the excitation wavelength. The results support and complement the findings from SE and Raman for detection of the secondary phase ZnSe.

V.P3.9
14:00
Authors : Sara Engberg, Stela Canulescu, Yeng Ming Lam, Jørgen Schou
Affiliations : DTU Fotonik, Technical University of Denmark, DK-4000 Roskilde, Denmark; DTU Fotonik, Technical University of Denmark, DK-4000 Roskilde, Denmark; School of Materials Science and Engineering, Nanyang Technological University, Singapore; DTU Fotonik, Technical University of Denmark, DK-4000 Roskilde, Denmark

Resume : The non-toxic, abundant material Cu2ZnSnS4 (CZTS) is promising for thin film solar cells, where solution processing allows fast and inexpensive large-scale fabrication. However, crystal growth during selenium-free annealing is far more pronounced in films prepared from precursor inks compared to those made from nanoparticle (NP) inks. It is not well understood why annealing in sulfur atmosphere is challenging, but it is clear that sintering of CZTS NPs is strongly impeded by remnants, e.g. ligands or other contaminants, on the NPs’ surface. Here, we attempt to design a suitable annealing procedure for NPs with and without organic ligands. We study the effect of the annealing atmosphere on grain growth behavior of CZTS NP-based thin films by thermal analysis. We use thermogravimetric analysis (TGA) and differential thermal analysis (DTA) coupled with mass spectrometry (MS) to simultaneously monitor the mass and heat flow changes of both NP powders and inks. The investigation focuses on annealing in air, nitrogen and forming gas (5% H2 in Ar), i.e. oxidizing, inert, and reducing atmosphere. We observe that most of the grain growth occurs for both ligand-coated and ligand-free samples in reducing atmosphere. We find that the organic ligands thermally decompose in smaller fragments, with the highest decomposition rate in reducing atmosphere. The results from the TGA-DTA-MS measurements are compared with the structural changes of the samples after annealing in a sulfurization oven.

V.P3.10
14:00
Authors : Tove Ericson, Tomas Kubart, Charlotte Platzer-Björkman
Affiliations : Ångström Solar Center, Solid State Electronics, Uppsala University, Box 534, SE-75121 Uppsala

Resume : Several routes to produce the solar cell material Cu2ZnSnS4 exist. Most successful are still the two stage methods, starting with precursor deposition and thereafter annealing to crystallize into Cu2ZnSnS4. We have investigated reactively sputtered, homogeneous, precursors with a composition close to stoichiometric Cu2ZnSnS4, and how a limited variation of sulfur content in the precursor affects the annealed films in terms of crystal quality. A reason to investigate this is that compound sputtering, an alternative sputtering route which has the advantage of possibly omitting the corrosive gas H2S in the process, may yield sulfur poor precursors. In this work, the sulfur content was lowered by reducing the H2S/Ar-ratio in a 3-target reactive sputtering process, while target power was adjusted to compensate for the change in deposition rate that occurs as the targets switch from compound to metallic mode. Comparison is also made to precursors from compound sputtering, using CuS, ZnS and SnS targets. Annealing was done in a graphite box with added elemental sulfur. Characterization was made by scanning electron microscopy, x-ray diffraction and Raman scattering. The annealing time and temperature have a large influence on the film quality. However, we find no strong correlation between precursor sulfur content and grain size after annealing, within the compositional range investigated. This is positive since it allows larger flexibility in precursor deposition by sputtering.

V.P3.11
14:00
Authors : René Gunder (1), Alexandra Franz (1), Susan Schorr (1,2)
Affiliations : (1) Helmholtz Zentrum Berlin für Materialien und Energie; (2) Freie Universität Berlin, Institut für Geologische Wissenschaften

Resume : In comparison to other compound semiconductor materials kesterites are more favorably because the composition can be chosen such that it facilitates the utilization of only abundant and non-toxic elements. Also, the optical band gap fits well to the solar spectrum and, additionally, can be tuned by different anion ratios in the solid solution CZTS – CZTSe. However, the difficulties in controlling the anion ratio gave rise to consider alternative means which facilitate the band gap to be designed more easily. Such an alternative is given by the cationic substitution Sn ↔ Ge (i.e. CZGSe), as done in this study. In dependence of the route of off-stoichiometry, the kesterite phase, then, accommodates particular defect types and defect complexes. According to the different types of off-stoichiometric kesterite proposed by Lafond et. al two series of powder samples were synthesized by solid state reaction in a one-zone tube furnace at Tmax = 700 °C. These sample series comprise Cu-poor A-type (Cu2-2xZn1+xGeSe4) and Cu-rich C-type (Cu2+2zZn1-3zGe1+zSe4) kesterite. The powder samples stoichiometrically are in the range of, respectively, 0 ≤ x ≤ 0.2 and 0 ≤ z ≤ 0.125, and have been synthesized by solid state reaction of the pure elements in sealed, evacuated silica ampoules. The produced powder material has been pre-characterized by quantitative electron microprobe analysis using WDX spectroscopy as well as X-ray and neutron powder diffraction, respectively. This study aims to provide an overview of the structural response both to the cationic substitution as well as the different off-stoichiometric types, especially in consideration of the extent of deviation from stoichiometry.

V.P3.12
14:00
Authors : A. E. Hassanien(1,3), Soraya Abdelhaleem(1,4), Matthias Schuster(1), Monica Distaso(2), A. A. Ramadan(3), Peter Wellmann(1)
Affiliations : (1) Materials Department 6 (i-MEET), Friedrich-Alexander-Universität Erlangen-Nürnberg (FAU), Martensstr. 7, 91058 Erlangen, Germany.; (2) Institute of Particle Technology, Friedrich-Alexander-Universität Erlangen-Nürnberg (FAU), Cauerstr. 4, 91058 Erlangen, Germany.; (3) Physics Department, Faculty of Science, Helwan University, 11795 Helwan, Egypt.; (4) Radiation Physics Department, National Center for Radiation Research and Technology, Po Box 29, Nasr City, Cairo, Egypt.

Resume : CZTS nanoparticles were synthesized by solvothermal method. The ink of CZTS nanoparticles dispersed in chloroform was deposited on Mo-coated glass substrates by Doctor blade technique, which is cheap, simple and suitable technique for large scale production. In the present work, Effect of annealing conditions (temperature, duration and the annealing atmosphere) on the structural, morphological and optical properties of CZTS thin films was investigated. X-ray diffraction analysis and Raman scattering measurements were used to confirm the formation of the crystalline CZTS. The morphology and the chemical composition of the CZTS thin films were studied by scanning electron microscope (SEM) and energy dispersive X-ray spectroscopy (EDX), respectively. It was found that CZTS films show the diffraction peaks of (112), (220) and (312) with slight appearance of diffraction peaks of (112) and (332) attributed to kesterite CZTS (JCPDS: 26-0575). At elevated annealing temperatures (≈ 550 °C), the CZTS phase decomposes to other secondary phases. Annealing with elemental sulfur enhances the intensity of the diffracted peaks of CZTS but it also may results in the appearance of Cu2S or CuS as a secondary phases. Keywords: Cu2ZnSnS4, Kesterite, Doctor blade, CZTS nanoparticles.

V.P3.13
14:00
Authors : Anastasia Irkhina, Sergiu Levcenco, Justus Just, Thomas Unold
Affiliations : Helmholtz-Zentrum Berlin für Materialien und Energie GmbH, Hahn-Meitner-Platz 1, 14109 Berlin, Germany

Resume : Over the past years solution-processed absorbers for photovoltaics got highly competitive in comparison to vacuum-processed films. For kesterite and chalcopyrite materials nanoparticle ink-based film deposition is one of the main directions. Nevertheless, the synthesis of monodispersed phase-pure CZTS colloidal nanocrystals with a desired composition without secondary phases is challenging. In this work the influence of the injection temperature and growth time on the formation process of CZTS nanoparticles and their final properties have been systematically investigated applying TEM, XRD, XRF, ICP-MS, Raman spectroscopy and thermogravimetry coupled with mass spectrometry. The analysis of aliquots has been used to investigate the growth process of nanoparticles in its intermediate stages. CZTS nanocrystals have been obtained by hot-injection of a sulfur/oleylamine solution into a metal salts mixture with a high-boiling temperature solvent under N2 atmosphere, using a Schlenk line. Within this approach a preferable formation of small sized nanoparticles (in the range from 3 to 10 nm) has been achieved. Based on XRF and ICP-MS analysis we show that an increase of the injection temperature results in significant changes in the Cu/Sn- and Zn/Sn-ratios of the nanoparticles. By Raman analysis of aliquots we find that the crystalline quality of the nanoparticles depends on the injection temperature and growth time, while for all processes Cu2-xS is detected as the initial phase.

V.P3.14
14:00
Authors : Juran Kim, Gee Yeong Kim, William Jo
Affiliations : Department of Physics, Ewha Womans University, Seoul, 03760, Korea

Resume : Cu2ZnSnSe4 (CZTSe) compound is one of promising light absorber candidates for thin-film solar cells. Nonetheless, its band gap needs to be increased to the optimal band gap for high light absorption efficiency. Herein, the front band gap tuning of Cu2Zn(Sn,Ge)Se4 (CZTGSe) thin films is investigated, depending on the Ge ratio. CZTSe thin films were deposited by electron beam co-evaporation on Mo-coated soda lime glass. After that, for front band gap grading, Ge layers of various thicknesses are added on the absorber layers with diverse annealing time up to 50 min. Furthermore, we examined its structural, electrical, and optical properties of CZTGSe thin films with different composition ratio of Ge/(Ge+Sn). As the annealing time is long, Ge can diffused into the CZTSe layers well, resulting in the increase in the grain size and the thickness of precursor layers. The phase shift of the CZTGSe thin films occurs as Ge ratio is high because Ge will substitute for Sn. Moreover, with large Ge composition, the increase in the band gap is observable. CZTGSe thin films annealed less than 30 min shows only single work function peak, whereas several work function peaks appear in the samples annealed more than 30 min. From this, we can comprehend the band alignment between an absorber layer and a buffer layer in thin-film solar cells. Accordingly, the front band gap grading of CZTGSe thin films will present high conversion efficiency.

V.P3.15
14:00
Authors : Tsz-Ki Lau, Ye Feng, Jiangquan Mai, Chunlei Yang*, Xinhui Lu*, Xudong Xiao*
Affiliations : Y. Feng, Prof. C. L. Yang Center for Photovoltaic Solar Energy, Shenzhen Institutes of Advanced Technology, Chinese Academy of Sciences, Shenzhen, 518055, China T.-K. Lau, J. Mai, Prof. X.H. Lu, Prof. X. D. Xiao Department of Physics, The Chinese University of Hong Kong, Shatin, Hong Kong, China * Corresponding authors, E-mail: xhlu@cuhk.edu.hk, cl.yang@siat.ac.cn, xdxiao@phy.cuhk.edu.hk

Resume : A novel low temperature Cu2ZnSnS4 (CZTS) formation path using co-sputtered SnS2-ZnS-Cu precursors has been employed for CZTS solar cell fabrication*. This method involves a low-temperature annealing stage for CZTS phase formation with a followed short high-temperature annealing stage for grain growth and secondary phase removal. The two stage process wisely separates the phase formation and crystal coalescence, thus makes the fabrication of CZTS film more controllable. Furthermore, given the controllability of the two stage process, the effect by the atmosphere at different stages of the process has been studied separately and the process has thus been further optimized. The demonstration of the low temperature formation path provides new opportunities to fabricate high efficiency, cost-effective and environmental friendly CZTS solar cells, in the hope of rivalling CIGS solar cells, its predecessor. * Y. Feng, T.-K. Lau, G. Cheng, L. Yin, Z. Li, h. luo, Z. Liu, X. Lu, C. Yang and X. Xiao, CrystEngComm, 2016, DOI: 10.1039/C5CE02279G.

V.P3.16
14:00
Authors : R. Garza-Hernández, S. Lugo-Loredo, F.S. Aguirre-Tostado
Affiliations : Centro de Investigacion en Materiales Avanzados S. C. Unidad Monterrey, Alianza Norte # 202, Autopista Monterrey-Aeropuerto Km.10., C.P. 66628 Apodaca, Nuevo León, México.

Resume : Copper zinc tin sulfide (Cu2ZnSnS4) has gained attention as one promising quaternary absorber material for photovoltaic applications. Solution based methods could represent a low processing temperature and low cost alternative for the synthesis of CZTS. In this work, Cu2ZnSnS4 thin films have been deposited by the Successive Ionic Layer Adsorption and Reaction (SILAR) method on top CdS films deposited on glass substrates. Some parameters such as the concentration of the metal precursors and the complexing agent were optimized for the deposition of homogeneous CZTS thin films. Thin films were prepared using metal chlorides as the cationic precursor, sodium citrate as complexing agent and sodium sulfide as the anionic precursor, applying 70 cycles and post-deposition thermal annealings at 450 and 500 °C under N2 flow. The films were characterized using X-ray Diffraction (XRD), X-ray Photoelectron Spectroscopy (XPS), Raman Spectroscopy and Scanning Electron Microscopy (SEM). Due to the similarity between the position of diffraction peaks for the two structural phases corresponding to the ternary Cu2SnS3 and quaternary Cu2ZnSnS4, XRD analysis is not conclusive to determine which one other two phases dominates. A Raman peak at 332 cm-1 corresponding to the A vibrational mode of the quaternary Cu2ZnSnS4 was observed. XPS depth profiling analysis using Ar+ ions revealed that the annealed films are poor in Zn and rich in Cu, also a Cd diffusion caused by temperature was observed.

V.P3.17
14:00
Authors : Stefano Marchionna,(I)* Federico Cernuschi,(I) Alessia Le Donne,(II) Simona Binetti,(II) Maurizio Acciarri,(II) Marco Merlini (III)
Affiliations : (I) RSE-Spa Ricerca sul Sistema Energetico, Via Rubattino 54, Milano, Italy (II) Dept. Of Materials Science and MIBSOLAR Center, University of Milano-Bicocca, Via Cozzi 55, Milano, Italy (III) Earth science dept. Milano University , Via Botticelli, 23, Milano, Italy.

Resume : An attractive possibility for the synthesis of In and Ga free chalcogenides which may allow terawatt range photovoltaic (PV) applications relies on I2-II-IV-VI4 species, such as copper zinc tin sulfide, copper zinc tin selenide and their sulfur-selenium alloy. They share similar structure with the first developed chalcopyrite matrix (i.e. CuInS2): half of the In atoms is replaced with Zn and another half with Sn, resulting in the kesterite phase. A further alternative belonging to this class of materials is Cu2MnSnS4 (CMTS), which consists of abundant and non-toxic elements and shows high absorption coefficient and direct band gap suitable for PV applications. In this work, a two-step process (evaporation in vacuum of the metal precursors followed by annealing in Sulfur vapors) has been implemented to grow CMTS thin films (TFs) on Mo-coated soda lime glasses. The effects of the most critical growth parameters on TFs quality (homogeneity and stoichiometry) have been investigated, paying particular attention to the order of the metal precursors in the evaporated stack and to the annealing temperature. Several techniques, including Scanning Electron Microscopy, Energy Dispersive Spectroscopy, Raman, X-ray Diffraction and Photoluminescence have been used to test the CMTS TFs and to identify possible secondary phases. Good layer compactness, high absorption coefficient (5x104 cm-1) and direct band (1.26 eV) suitable for PV applications have been obtained.

V.P3.18
14:00
Authors : J. Marquez 1, L. E. Valle 2-3, R. Gunder 2, G. Gurieva 2, N. M. Pearsall 1, I. Forbes 1 and S. Schorr 2-3
Affiliations : 1. Northumbria Photovoltaic Applications Group, Department of Physics and Electrical Engineering, Northumbria University, Newcastle upon Tyne, UK 2. Helmholtz-Zentrum Berlin for Materials and Energy, Hahn-Meitner-Platz 1, 14109 Berlin, Germany 3. Free University Berlin, Institute of Geological Sciences, Malteser str.74-100, Berlin, Germany

Resume : One of the main challenges that the kesterite community faces is the reduction of the Voc deficit of the Cu2ZnSnS(e)4 solar cells. We present the synthesis of Cu2ZnSnSe4 (CZTSe) absorber layers by the selenisation of Cu-Zn-Sn sputtered metallic precursors with different compositions. It observed that the tetragonal distortion parameter c/2a has, in all samples, a value below 1. The value of c/2a decreases monotonically as the composition of the samples becomes Cu poorer and Zn richer. Solar cells were fabricated from this series of absorbers. It is observed that the efficiency of the solar cells increases from 6.9% to over 8% as the Cu/(Zn Sn) ratio of the film decreases and the Zn/Sn ratio increases. This increase in performance is mainly driven by a monotonic increase of Voc, which in the best case reaches a value of 450 mV, being comparable with and even larger than the current record CZTSe device and appearing to be linked to c/2a. These results are compared with 29 CZTSe kesterite powders with different composition which show a minimum c/2a value located in the Cu-poor and Zn-rich region, which is the range of composition where all the best kesterite based solar cells are produced and consistent with the trends of this work. We propose that the determination of c/2a (which partly determines the crystal field splitting) could be used as a predictor of the quality of CZTSe based solar cells, and, to some extent, as an indicator of phase inhomogeneity in the absorbers. Furthermore, we suggest synthesis routes to induce a decrease of c/2a that could help to solve the problem of Voc deficit that kesterite solar cells are facing.

V.P3.19
14:00
Authors : Aniket Mule (1,2,3), Bart Vermang (1,2), Sylvester Sahayaraj (1,2), Guy Brammertz (4,5), Samaneh Ranjbar (1,2,6), Marc Meuris (4,5), Jef Poortmans (1,2,5)
Affiliations : 1) IMEC – partner in Solliance, Kapeldreef 75, 3001 Leuven, Belgium; 2) Department of Electrical Engineering (ESAT), KU Leuven, Kasteelpark Arenberg 10, 3001 Heverlee, Belgium; 3) Department of Mechanical and Process Engineering (D-MAVT), ETH Zurich, LEE K, Leonhardstrasse 21, 8092 Zurich, Switzerland; 4) IMEC division IMOMEC - partner in Solliance, Wetenschapspark 1, 3590 Diepenbeek, Belgium; 5) Institute for Material Research (IMO) Hasselt University, Wetenschapspark 1, 3590 Diepenbeek,Belgium; 6) I3N - Departamento de Física, Universidade de Aveiro, Campus Universitário de Santiago, 3810-193 Aveiro, Portugal;

Resume : It is well established that the addition of sodium (Na) to chalcopyrite (CIGSSe) or kesterite (CZTSSe) solar cells markedly increases solar cell performance. An enhancement of the grain size and increase of the mobility of carriers is typically shown but the fundamental reasons for these improvements are still a matter of debate. In this work, we explore the impact of other alkali elements – like potassium, rubidium, caesium and lithium (K, Rb, Cs and Li) – on pure selenide CZTSe solar cells. Therefore, alkali salts are first dissolved in water, then deposited at low temperature, and finally introduced into the CZTSe absorber layer at high temperature. Deposition of the solution is by spin or dip coating using moderate conditions, very easily scalable techniques. Two different sets of substrates are applied: Type (i) soda lime glass (SLG) / silicon nitride (barrier layer) / Mo (rear contact) / Cu, Zn, Sn (metal precursors), and Type (ii) SLG / Mo / Cu, Zn, Sn. Hence, using the samples with barrier layer in between the SLG and Mo, the alkali elements are introduced in a well-controlled manner. We have successfully deposited Na on type (i) substrates using spin coating achieving an efficiency of 8 % (without anti reflection coating). Preliminary results of K-deposition are equally promising, and work on Rb, Cs and Li is ongoing. Characterization techniques such as Scanning Electron Microscopy, X-ray Diffraction, Time Resolved Photoluminescence Spectroscopy, Current-Voltage and Quantum efficiency measurements are employed to study the physical and optoelectronic properties of solar cells. With this study, we explore the effect of alkali metals on CZTSe solar cell performance and enhance its understanding.

V.P3.20
14:00
Authors : F.A. Pulgarín 1, F. Oliva 2, E. Garcia-Llamas 3, Y. Sánchez 2, R. Caballero 3, J.M. Merino 3, M. León 3, O.Vigil-Galán 1, Victor Izquierdo-Roca 2
Affiliations : 1 Escuela Superior de Física y Matemáticas-Instituto Politécnico Nacional (IPN), C.P. 07738, México DF, México. 2 Catalonia Institute for Energy Research (IREC), Jardins de les Dones de Negre 1, 08930 Sant Adrià del Besòs-Barcelona, Spain. 3 Universidad Autónoma de Madrid, Departamento de Física Aplicada, C/Francisco Tomás y Valiente 7, 28049 Madrid, Spain

Resume : Cu2ZnSn(S,Se)4 (CZTSSe) material is one of the most promising solution for low cost production of thin film based solar cells mainly due to its use of abundant material. Standard manufacturing processes usually require high control of material composition and long deposition and post-treatment processes. CZTS powders synthesized by ball milling followed by doctor blade deposition in thin films and post reactive annealed in Se atmosphere, have already been reported, leading to the fabrication of CSZTSe solar cells with efficiency of 6.7%. Synthesis by ball milling allows an accurate control of composition, and the avoidance of secondary phases which are critical parameters for high efficiency CZTSSe solar cells. Moreover this technique is compatible with mass production requirements as it is a fast and cheap process which has a high production yield. In this work, we propose a fast dry process based on the direct synthesis of nanometric CZTSSe powder by ball milling, followed by its thermal evaporation on Mo substrates (evaporation rate of 30 Å/s) and finally recrystallized. Crystallinity, morphology and composition of the final absorber layers have been characterized by XRD, XRF, SEM and Raman techniques Additionally, because of its high control over composition and thickness of synthetized layers, we discuss about the application of this process for the growth of layers with a controlled gradient composition leading to band gap engineering of CZTSSe devices.

V.P3.21
14:00
Authors : F.A. Pulgarín-Agudelo, O. Vigil-Galán, Maykel Courel, M.M. Nicolás-Marín, J.A. Andrade-Arvizu, F. Oliva, D. Sylla, M. Rohini, Víctor Izquierdo-Roca
Affiliations : Escuela Superior de Física y Matemáticas-Instituto Politécnico Nacional (IPN), C.P. 07738, México DF, México; Catalonia Institute for Energy Research (IREC), Jardins de les Dones de Negre 1, 08930 Sant Adrià del Besòs-Barcelona, Spain; Program on Nanoscience and Nanotechnology, CINVESTAV-IPN, México city, Gustavo A. Madero, México.

Resume : In this research work, CZTS, CZTSe and CZTSSe powders were prepared by mechanochemical ball-milling process using Tungsten carbide balls. Using the source materials of Cu, Zn, Sn, S, Cu, Zn, Sn, Se and Cu, Zn, Sn, S and Se for the CZTS, CZTSe and CZTSSe, in the ratio 1.6:1.1:0.9:4, which correspond to [Cu]/([Zn] [Sn]) and [Zn]/[Sn] values of 0.8 and 1.22, respectively. Furthermore, was chosen [Se]/[Se] [S]=0.4 for the synthesis of CZTSSe powders. These relationships are considered as the optimum for high efficiency solar cells. The powders are investigated by X-Ray Diffraction (XRD), Scanning Electron Microscopy (SEM) and Transmission Electron Microscopy (TEM) for structural and morphological studies, EDS and XRF for compositional studies and Raman Spectroscopy technique for the existence of possible secondary phase formation, defects and crystalline quality of the powders. Our results are discussed in terms of using these powders in the processing of low-cost and high efficiency solar cells, as alternative technique to traditional methods used so far.

V.P3.22
14:00
Authors : V.V. Rakitin, M.V. Gapanovich, G.F. Novikov
Affiliations : The Institute of Problems of Chemical Physics, RAS

Resume : In this study the influence of the synthesis conditions on the phase composition, optical properties and photoconductivity of the Cu-Zn-Sn-Se thin film absorbing layers prepared by the one-stage electrodeposition method from lactic solution was investigated. The cyclic voltammograms showed that all the four components can be deposited simultaneously at –700 mV [vs. 3M SSCE] to obtain the CZTSe precursor layer from lactic solution. Analysis of XRD data shows that the resulting non-annealed precursor films were amorphous, apparently, due to hydrogen evolution in this potential range. The minimum content of impurity phases is characteristic of films deposited at –700 mV followed by annealing in selenium atmosphere. This fact was also proved due to Raman spectroscopy showed that all samples consist of kesterite phase (193 cm-1 and 172 cm-1); however all of them contain molybdenum selenide. The band gap energy of CZTSe compounds was found about 1eV which is in good agreement with published data. The analysis of dependence of applied potential on current density in the photoelectrochemical cell with impulse light (PEC) showed that all samples are photoconductive.

V.P3.23
14:00
Authors : G. Rey, F. Babbe, T. P. Weiss, H. Elanzeery, M. Melchiorre, S. Siebentritt
Affiliations : Laboratory for photovoltaics (LPV), FSTC, University of Luxembourg, 41 rue du Brill 4422 Belvaux, Luxembourg

Resume : We investigated the effect of sodium and potassium incorporation in Cu2ZnSnSe4 (CZTSe) thin films via a post-deposition route. The CZTSe thin films were grown by co-evaporation, then they were coated with the alkali fluoride and annealed to promote the alkali metals in-diffusion. The average efficiency was 6.4%, 7.8% and 7.7% for solar cells based on untreated, Na-treated and K-treated CZTSe absorber respectively. The efficiency improvement for alkali-treated devices was due to an increase in fill factor (ff), open-circuit voltage (Voc) and short-circuit current (Jsc). The effect of the annealing itself was investigated separately in order to disentangle the improvement truly attributed to Na or K incorporation. Quantum efficiency measurements revealed that alkali-treated devices show lower Voc loss (Eg/q-Voc) and better collection length. The electrical properties of solar cells were further investigated by means of temperature dependent JV and admittance spectroscopy. As the activation energy of the main recombination path was not significantly modified by the post-deposition treatment, the lower Voc loss was attributed to passivation of recombination channels by the alkalis. The net doping density was decreased by a factor of 2, which explains the better current due to a wider space charge region.

V.P3.24
14:00
Authors : M.Ya.Valakh(1), A.P. Litvinchuk(2), V.M. Dzhagan(1,3), V.O.Yukhymchuk(1), A.M.Yaremko(1), Yu.A. Romanyuk(1), M. Guk(4,5), I.V. Bodnar(6), V. Izquierdo-Roca(4), A. Perez-Rodriguez(4)
Affiliations : (1) Institute of Semiconductor Physics, NAS of Ukraine, Kiev, 03028, Ukraine (2) Texas Center of Superconductivity and Department of Physics, University of Houston, Texas 77204-5002, USA (3) Semiconductor Physics, Technische Universitat Chemnitz, D-09107 Chemnitz, Germany (4) IREC, Catalonia Institute for Energy Research, Barcelona 08930, Spain (5) Institute of Applied Physics, Academy of Sciences of Moldova, Chisinau MD 2028, Moldova (6) Department of Chemistry, Belarusian State University of Informatics and Radioelectronics, Minsk, Belarus

Resume : Cu2ZnGeS4 (CZGS) and mixed Cu2Zn(Ge,Sn)S4 (CZGTS) semiconductors have a strong interest for the development of cost efficient photovoltaic devices with suitable band gap engineering. Development of these materials requires for a deeper knowledge of their fundamental properties, which have been very little explored for these Ge based compounds. In this frame, this work reports a first theoretical and experimental detailed study of the vibrational properties of these compounds, This includes the theoretical DFT analysis of the lattice dynamics of CZGS wurtzstanite and kesterite structures, that has allowed deriving pictures of the atomic displacements in the unit cell for all the optical vibrations. These theoretical results are compared with the experimental spectra measured in the kesterite structure at low temperature in non-resonant and resonant excitation conditions. For most vibrations, an excellent agreement (≤ 2-5 cm-1) has been achieved. Higher differences (15-20 cm-1) observed in fully symmetrical modes are related to the existence of an anharmonic Fermi resonance mechanism. For the mixed CZGTS, in spite of the small frequency differences between the dominant A bands from CZGS and CZTS, the spectra measured in crystals with different composition show the existence of a two mode behaviour that has been experimentally confirmed from resonant Raman 2nd and 3rd order peaks. This is related to the small dispersion of the phonon branches in the Brillouin zone.

V.P3.25
14:00
Authors : M. Sylvester1,2,4 ,Guy Brammertz1,2 , Bart Vermang3,4 , Samaneh Ranjbarrizzi6, Marc Meuris1,2 , Jef Vleugels 5 and Jef Poortmans 2,3,4.
Affiliations : 1 imec division IMOMEC - partner in Solliance, Wetenschapspark 1, 3590 Diepenbeek, Belgium 2 Institute for Material Research (IMO) Hasselt University, Wetenschapspark 1, 3590 Diepenbeek, Belgium 3 imec- partner in Solliance, Kapeldreef 75, 3001 Leuven, Belgium 4 Department of Electrical Engineering (ESAT), KU Leuven, Kasteelpark Arenberg 10, 3001 Heverlee, Belgium 5 Department of Materials Engineering (MTM), KU Leuven, Kasteelpark Arenberg 44, 3001 Heverlee, Belgium. 6 I3N - Departamento de Física, Universidade de Aveiro, Campus Universitário de Santiago, 3810-193 Aveiro, Portugal.

Resume : The influence of the duration of the KCN etching step on the efficiency of Cu2ZnSnSe4 (CZTSe) solar cells has been explored. The KCN/KOH chemical etching approach, originally developed for the removal of CuxSe phases in Cu(In,Ga)(S,Se)2 thin films, is applied to CZTSe thin film absorbers. Polycrystalline CZTSe thin films were made by selenization of an e-beam evaporated Sn/Zn/Cu metal stack using 10% H2Se at 450˚C followed by 5wt% KCN/KOH chemical etching before solar cell processing. Upon increasing the KCN etching time removal of secondary phases such as CuSe, SnSe & SnSe2 from the absorbers within the first 120 seconds was observed, and solar cells etched for more than 120 seconds exhibited a deterioration of solar cell parameters and therefore a decrease in efficiency. From detailed optoelectronic and physical characterizations we were able to find that the decrease in efficiency with prolonged etching is strongly related to changes taking place at the CZTSe/CdS interface and not the bulk. Surface characterization by XPS showed compositional changes at the surface. Upon annealing the solar cells at 200°C in inert atmosphere either an improvement or degradation of efficiencies was observed. The physical and electrical characterization of the solar cells before and after annealing showed that the bulk is hardly affected and strongly suggest that the annealing modifies the CZTSe/CdS interface which is responsible for the change in efficiency of CZTSe solar cells.

V.P3.26
14:00
Authors : Mohamed H. Sayed, Christiane Stroth, Christine Chory, Jürgen Parisi, Jörg Ohland, Levent Gütay
Affiliations : Laboratory for Chalcogenide Photovoltaics (LCP), Energy and Semiconductor Research Laboratory (EHF), Department of Physics, University of Oldenburg, Carl-von-Ossietzky-Straße 9-11, 26129 Oldenburg, Germany

Resume : Chemical solution deposition techniques have been widely used for the production of kesterite thin films [1,2]. The processing conditions such as selenization parameters (e.g. temperature, pressure etc.) play a critical role and have significant impact on the properties of the resulting CZTSSe thin films and hence the device performance [3]. In this study we have deposited CZTS thin films by spin coating technique followed by an annealing step in selenium atmosphere to obtain CZTSSe thin films. Two different configurations for the selenization process were used, one in a tube furnace and the other one in a rapid thermal processor (RTP). The effect of the different selenization processes on the structural and morphological properties of the prepared thin films were investigated using SEM, XRD and Raman spectroscopy. Depth profiling Raman analysis was employed with different excitation wavelengths in order to study the formation of CZTSSe and secondary phases during selenization. CZTSSe thin film solar cells were fabricated and the resulting efficiencies are discussed in context of the varied selenization parameters. [1] X. Zeng et al., Sol. Energy Mater. Sol. Cells 124 (2014) 55–60. [2] H. Xin, J.K. Katahara, I.L. Braly and H.W. Hillhouse, Adv. Energy Mater. (2014) 1301823. [3] Y.E. Romanyuk et al., Sol. Energy Mater. Sol. Cells 119 (2013)181–189.

V.P3.27
14:00
Authors : Daniel M. Többens, Galina Gurieva, Susan Schorr
Affiliations : Helmholtz-Zentrum Berlin for Materials and Energy, Department Structrure and Dynamics of Energy Materials Freie Universitaet Berlin, Department of Geosciences

Resume : Kesterite-type Cu2ZnSnSe4 (CZTSe) based PV devices are limited by a low open-circuit voltage [1]. A possible reason is an effective band gap reduction due to structural inhomogeneities [2] like disorder among Cu and Zn in lattice planes perpendicular to the crystallographic c-axis at z=¼ and ¾ [3]. Decreasing Cu/Zn disorder was reported at T<533 K (CZTS) [4] and T<473 K (CZTSe) [2]. The implications of such a low critical temperature TC would be significant, because such absorber layers are grown far above TC. The exact extent of disorder by the end will depend only on the part of cooling that occurs below TC, a temperature region in which cooling history often is neither controlled nor reported. Indeed, low T postdeposition annealing has been shown to increase efficiency significantly [5]. However, low temperature ordering effects were only deduced indirectly, e. g. by Raman spectroscopy [4]. We used anomalous X-ray diffraction on the Cu- and Zn-K absorption edges to determine the Cu-Zn distribution over the crystallographic sites in a B-type CZTSe kesterite powder (Cu1.949Zn1.059Sn0.983Se4), thus determine the Cu/Zn disorder directly. Rietveld refinement allowed a quantitative determination of occupancies for all relevant sites. From this, the temperature dependency of a structure-based, quantitative order parameter could be determined. The critical temperature of the phase transition was confirmed at 460±10 K. The mechanism is in agreement with an order-disorder transition.

V.P3.28
14:00
Authors : Teoman Taskesen1,2, Taavi Raadik1, Kaia Ernits2, Joël Bleuse3, Jüri Krustok1, Dieter Meissner1
Affiliations : 1 Department of Materials Science, Tallinn University of Technology, Ehitajate tee 5, 19086 Tallinn, Estonia; 2 crystalsol OÜ, Akadeemia tee 15a, 12618 Tallinn, Estonia; 3 Univ. Grenoble Alpes, INAC-PHELIQS, F-38000 Grenoble, France; CEA, INAC-PHELIQS, F-38000 Grenoble, France; CNRS, PLUM, F-38000 Grenoble, France

Resume : Doping with alkaline metals is one of the approaches for achieving high efficiency thin film chalcogenide solar cells. The latest record of 21.7% for Cu(In,Ga)Se2 (CIGS) solar cell which is achieved by alkali post-deposition treatment shows the importance of introducing impurities to absorber material. Similar type of doping can be also applied for Cu2ZnSnS4 (CZTS) solar cells. In this work, potassium iodide (KI) treatment for CZTS monograins is studied to improve the performance of CZTS monograin layer solar cells. CZTS monograins are submitted to high temperature heat-treatment in the presence of KI. Photovoltaic parameters of the solar cells were compared as a function of KI amount used in treatment. The highest efficiency of 5.8% is achieved with 10% KI treatment (percentage of the KI/CZTS mass ratio). I-V measurement shows an increase of Jsc by 10%, compared to corresponding untreated CZTS. The gain in Jsc could be a result of band gap decrease of CZTS and improved current collection. Bias-dependent EQE results confirm the improvement of carrier collection. In contrast to the improvement in Jsc, decreasing tendencies are observed in Voc and FF with increasing amount of KI. In addition, time-resolved photoluminescence (TRPL) is used to investigate PL decay time constants of KI treated monograins at low temperatures to understand the influence of KI treatment on charge carrier dynamics.

V.P3.29
14:00
Authors : Solange Temgoua, Romain Bodeux, Giovanni Altamura, Negar Naghavi
Affiliations : IRDEP, 6 Quai Watier, 78400 Chatou Cedex, France EDF R&D, 6 Quai Watier, 78400 Chatou Cedex, France CNRS IRDEP, 6 Quai Watier, 78400 Chatou Cedex, France IPVF, 8 rue de la Renaissance 92160, Antony Cedex, France

Resume : A comparative study of Cu2ZnSn(Sx,Se1-x)4 (CZTSSe) thin films absorbers annealed on ZnO:Al (AZO), SnO2:F (FTO) and Mo substrates was investigated. Cu-Zn-Sn-S sulfide and Cu-Zn-Sn metallic precursors with a near stoichiometry composition were deposited by cosputtering followed by an annealing in an atmosphere containing Se or Se/S vapors. Detailed comparisons of structural, morphological and optical properties were performed using X-ray diffraction, Raman spectroscopy, scanning electron microscopy and glow discharge optical emission spectroscopy. The optoelectronic properties of the solar cells have been characterized by the means of PL, C(V), I(V) measurements. The results show different trends depending on the precursor and back contact used. While efficiencies more than 8% are reached whatever the precursor used on Mo back contact, preliminary studies on TCO substrates show that: the precursor morphology is strongly dependent on the substrate, AZO substrate reacts with the chalcogens while FTO is very chemically stable, however Se diffuse more easily in CZTSSe using AZO back contact compared to FTO. Moreover pure Se annealing compared to Se/S annealing exhibits a stronger gradient of S/(S+Se) in the CZTSSe absorber. In this work the impact of the substrate on the kinetic rate of selenization and sulfurization, the reaction occurring at the interface CZTSSe/substrate and their impact on the optoelectronic properties of solar cells will be discussed.

V.P3.30
14:00
Authors : K. Timmo a, M. Kauk-Kuusik a, T. Raadik a, M. Altosaar a, M. Pilvet a, K. Ernits b
Affiliations : a Department of Materials Science, Tallinn University of Technology, Ehitajate tee 5, 19086 Tallinn, Estonia b crystalsol OÜ, Akadeemia tee 15a 12618 Tallinn, Estonia

Resume : A disordering in kesterites due to [ZnCu+CuZn] antisite defect pairs has attracted significant interest in recent years. Cu–Zn disorder and different defect clusters are the primary cause of the absorber material band gap fluctuations. Degree of Cu–Zn disordering can be changed by using different cooling regimes after high temperature treatments. Currently, there are no experimental results about order-disorder affect to the Cu2ZnSnS4 (CZTS) solar cell parameters. In this study we investigated the influence of different cooling regimes after annealing of CZTS powder in S and/or SnS2 vapor to the performance of monograin layer solar cells. In the first experimental series the powders were cooled to room-temperature by using different cooling rates and in the second series, the powders were annealed additionally at low-temperature for different time periods. EDX analysis showed that the bulk composition of CZTS monograin powders did not change significantly by increasing cooling time after post-treatment. PL studies showed that slow cooling increased the level of ordering in crystals by shifting the PL band maxima from 1.27 to 1.34 eV. Current-voltage measurements revealed that increased amount of ordered kesterite makes significant impact on the CZTS monograin layer solar cell characteristics, mostly, the values of Voc were increased. EQE measurements confirmed that additional low-temperature annealing increases bandgap energy about 60 meV.

V.P3.31
14:00
Authors : Rachmat Adhi Wibowo1*, Bernhard Klampfl1, Martin Bauch1, Raad Hamid2, Neha Bansal1, Theodoros Dimopoulos1
Affiliations : 1) AIT Austrian Institute of Technology, Energy Department, Photovoltaic Systems, Giefinggasse 2, 1210 Vienna, Austria 2) AIT Austrian Institute of Technology, Mobility Department, Electric Drive Technologies, Giefinggasse 2, 1210 Vienna, Austria

Resume : The emerging of kesterite Cu2ZnSn(S,Se)4 photovoltaic is foreseen to open a new application of white bronze CuSnZn alloy films. This is due to white bronze compositional range which can be tuned to meet the kesterite metallic composition. In order to obtain device-quality kesterite film, a white bronze precursor with smooth surface morphology is demanded. Typical rough and irregular corrugated surface has been found in white bronze precursors prepared by wide film deposition methods such as evaporation, electrodeposition and sputtering. The rough precursor surface is caused by the formation of Volmer-Weber Sn islands as a direct consequence of Sn high surface tension. In this contribution, a systematic study to improve the white bronze film surface morphology by preventing the Volmer-Weber Sn island formation is presented. The white bronze alloy films were electrochemically deposited by successive deposition of Cu, Sn and Zn on Mo-coated glass substrates. The effects of additional 0.025 g/l to 0.4 g/l sodium dodecyl sulfate (SDS) in citrate-based Sn electrolyte on the Sn surface morphology were investigated and discussed. The Sn island formation on Cu layer was significantly inhibited as SDS concentration increases toward an optimum SDS concentration of 0.1 g/l, where a smooth and highly reflecting Sn layer was produced. A new approach to evaluate the white bronze film morphological improvement by using reflectance measurement is also proposed. The application of white bronze was demonstrated by sulfurizing the CuSnZn films at 560 °C for 30 minutes which yields single phase and large grain of Cu2ZnSnS4 films.

V.P3.32
14:00
Authors : Akiko Mochihara1, 2, Masato Imai1, 2, Kenji Yoshino1, 2, *, Minobu Kawano3, Yuhei Ogomi2, 3, Shyam S. Pandey2, 3, Qing Shen2, 4, Taro Toyoda2, 4 and Shuzi Hayase2, 3
Affiliations : 1Department of Electrical and Electronic Engineering, Miyazaki University,1-1 Gakuen Kibanadai-nishi, Miyazaki 889-2192, Japan 2CREST, Japan Science and Technology Agency (JST), 4-1-8 Honcho, Kawaguchi,Saitama 332-0012, Japan. 3Department of Engineering Science, Faculty of Informatics and Engineering,The University of Electro-Communications, 1-5-1 Chofugaoka, Chofu,Tokyo 182-8585, Japan. 4Graduate School of Life Science and Systems Engineering, Kyushu Institute of Technology, 2-4 Hibikino, Wakamatsu, Kitakyushu 808-0196, Japan

Resume : In recent years, the Cu2ZnSnS4 (CZTS) and Cu2ZnSnSe4 (CZTSe) compound semiconductors are potential alternative materials to CuInGaSe2 (CIGS) for thin film photovoltaic absorber layers. This is because all of the elements in CZTS and CZTSe are abundant in the earth, and the bandgap energy is controlled by the ratio of S and Se. Therefore, environmental concerns are eliminated with these materials, paving the way for gigawatt scale mass production of solar cells. Despite their brief history in solar cell technology, CZTS, CZTSe, and Cu2ZnSn(S,Se)4 (CZTSSe) solar cell devices are rapidly advancing in the solar cell markets. For example, CZTSSe solar cells fabricated at IBM have achieved an efficiency of 11.1% using a hydrazine solution process [1]. Shin et al. have reported CZTS thin-film solar cell with an efficiency of 8.4% using a vacuum based thermal evaporation process [2]. Repins et al. have reported CZTSe solar cells with an efficiency of 9.2% using co-evaporation process [3]. In this work, CZTS thin film on glass substrate is grown by dipping-coat from Cu-, Zn- and Sn-xanthate solution as precursor materials. The samples are annealed under nitrogen atmosphere. X-ray diffraction (XRD), electron probe microanalysis (EPMA), scanning electron microanalysis (SEM), thermoprobe analysis and the four-point probe method are carried out. The XRD spectra indicate that a peak of CZTS (112) starts to observe at 150 °C. This temperature is lowest in non-vacuum process of CZTS film. The all samples indicate chalcopyrite structure and polycrystalline as evidenced by the XRD spectra. A value of full width at half maximum of (112) peak increases with increasing temperature. This indicates that an grain size increases with increasing annealing temperature. The samples are non-uniform composition such as Cu-poor and Zn-rich at low temperature and become S-poor with increasing temperature. Sulfur evaporates because vapor pressure of sulfur is high. The all samples are p-type conductivity by thermo prove analysis because Cu vacancy (VCu) defects is dominant in the samples from EPMA results. The resistivity increases with the increasing annealing temperature. It is assumed that this reason is due to decreasing carrier concentration. Donor type defects such as (Vs) increases with increasing the annealing temperature. [1] T. K. Todorov, J. Tang, S. Bag, O. Gunawan, T. Gokmen, Y. Zhu, and D. B. Mitzi, Adv. Energy Mater. 3, 34 (2013). [2] B. Shin, O. Gunawan, Y. Zhu, N. A. Bojarczuk, S. J. Chey, and S. Guha, Prog. Photovol: Res. Appl. 21, 72 (2013). [3] I. Repins, C. Beall, N. Vora, C. DeHart, D. Kuciauskas, P. Dippo, B. To, J. Mann, W. C. Hsu, A. Goodrich, and R. Noufi, Sol. Energy Mater. Sol. Cells 101, 154 (2012).

V.P3.33

Poster 3: CZTSSe solar cells : S. Siebentritt, A.N. Tiwari
14:00
Authors : Sergiy Zamulko(1), Rongzhen Chen(2), Clas Persson(1-3)
Affiliations : (1) Centre for Materials Science and Nanotechnology, University of Oslo, P. O. Box 1048 Blindern, NO-0316 Oslo, Norway; (2) Department of Physics, University of Oslo, P.Box 1048 Blindern, NO–0316 Oslo, Norway; (3) Department of Materials Science and Engineering, Royal Institute of Technology, Stockholm, SE–100 44, Sweden

Resume : Despite progress and developments of quaternary Cu2ZnSnS4 and Cu2ZnSnSe4 (CZTS). today solar cells with initial efficiency of about 12.6%, further understanding of CZTS as well as ways for its improvement is necessary. The control of formation/stability of point defects is one of promising approaches for increase of efficiency and stability of CZTS solar cells, because defects are one of major factors, related to phase formation, electrical and optical properties. Because of this, in this work, using hybrid functional calculations, we perform investigation of not only CZTS but also its alloys with Ge or Si. In particular, we analyze trends in electronic properties of CZTS materials with Ge or Si doping at different dopant concentrations. We further analyze optical properties of the materials in term of dielectric function and absorption coefficient. Based on the predicted results, we expand understanding of Cu-based solar cell materials and ways for controlling CZTS properties by doping. References: C. Persson, R. Chen, H. Zhao, M. Kumar and D. Huang, in Copper Zinc Tin Sulfide-Based Thin-Film Solar Cells, John Wiley & Sons Ltd, 2014, DOI: 10.1002/9781118437865.ch4, pp. 75-105. W. Wang, M. T. Winkler, O. Gunawan, T. Gokmen, T. K. Todorov, Y. Zhu and D. B. Mitzi, Adv. Energy Mater., 2014, 4, 1301465

V.P3.34
14:00
Authors : H. Xie (1), L. Calvo-Barrio (2,3), Y. Sánchez (1), M. Espindola-Rodríguez (1), A. Pérez-Rodríguez (1,3), E. Saucedo (1)
Affiliations : (1) IREC, Catalonia Institute for Energy Research, Jardins de les Dones de Negre 1, 2ª, 08930 Sant Adrià del Besòs, Spain; (2) Centres Científics i Tecnològics de la Universitat de Barcelona (CCiTUB), Lluís Solé i Sabarís 1-3, 08028 Barcelona, Spain; (3) IN2UB, Departament d’Electrònica, Universitat de Barcelona, Martí i Franquès, 1-11, 08028 Barcelona, Spain.

Resume : The best efficiency of Cu2ZnSn(S,Se)4 (CZTSSe) solar cells is still far below Cu(In,Ga)Se2 solar cells, mainly due to a large Voc deficit (about 600 mV), which is linked to band tails and interface recombination caused by non-optimized CZTSSe/CdS interface and CZTSSe grain boundaries. In this work, we managed to passivate the kesterite absorbers surface with group Ⅲ-S (Al-S, Ga-S) compounds by a wet chemical treatment, which was confirmed by XPS measurements. After the passivation process, the Voc and FF of the devices have improved 30-40 mV and 5-15%, respectively, while Jsc is almost unaffected, leading to 1-2.5% increased efficiency in absolute. A best CZTSSe device with 8% efficiency (Jsc=25.7 mA/cm2, Voc=459 mV, FF=68.1%) was obtained after passivation of the 5.6% reference device (Jsc=24.6 mA/cm2, Voc=428 mV, FF=53.4%). This passivation effect can be explained by: 1) Voc increase and less Voc deficit: better p-n junction quality, less interface recombination and increased hole concentration linked to a decrease of diode factor and saturation current, higher electronic band gap and possible removal of donors, which is studied by I-V, IV-T and C-V measurements; 2) FF increase: lower series resistance and higher shunt resistance could be related to better CZTSSe/CdS band alignment and decrease of shunt paths; 3) Jsc unaffected: better EQE in the p-n junction region while lower EQE in the back, which is ascribed to better p-n junction quality and shorter depletion width.

V.P3.35
14:00
Authors : Taavi Raadik1, Jüri Krustok1, Marit Kauk-Kuusik1, Kristi Timmo1, Kaia Ernits2, Joël Bleuse3
Affiliations : 1 Deparment of Materals Science, Tallinn University of Technology, Ehitajate tee 5, 19086 Tallinn, Estonia 2 crystalsol OU, Akadeemia tee 15a, 12618 Tallinn, Estonia 3 Univ. Grenoble Alpes, INAC-PHELIQS, F-38000 Grenoble, France CEA, INAC-PHELIQS, F-38000 Grenoble, France CNRS, PLUM, F-38000 Grenoble, France

Resume : The quaternary compound Cu2ZnSnS4 (CZTS) is a promising non-toxic absorber material for solar cells made from earth abundant elements. It is known that CZTS is subject to disorder in the Cu and Zn containing lattice planes of the kesterite structure by Cu-Zn exchanges. The impact of Cu/Zn disorder on properties of CZTS is an intensely discussed field and there are still unresolved problems. In this work we performed time resolved photoluminescence (TRPL) studies of small CZTS single crystals grown in molten KI salt. The ordered/disordered structure of CZTS was varied by the post thermal treatment temperature. PL spectra measured at T=5K showed an asymmetric band with a peak position of 1.33 eV and 1.27 eV for ordered and disordered structures, respectively. TRLP was measured for both crystals and their decay curves were fitted with a stretched exponential function. The differences in the TRPL decays of ordered and disordered crystals and the mechanisms causing such kind of behaviors are discussed in the paper.

V.P3.36
14:00
Authors : Samaneh Ranjbar 1,2,5, , Guy Brammertz 2,3, Bart Vermang 2,3,4, Afshin Hadipour 4, M. Sylvester 4,5, Aniket Mule 2,5,6, Marc Meuris 2,3 , Jef Poortmans 3,4,5 ,A. F. da Cunha1
Affiliations : 1 I3N - Departamento de Física, Universidade de Aveiro, Campus Universitário de Santiago, 3810-193 Aveiro, Portugal. 2 imec division IMOMEC - partner in Solliance, Wetenschapspark 1, 3590 Diepenbeek, Belgium 3 Institute for Material Research (IMO) Hasselt University, Wetenschapspark 1, 3590 Diepenbeek, Belgium 4 imec- partner in Solliance, Kapeldreef 75, 3001 Leuven, Belgium 5 Department of Electrical Engineering (ESAT), KU Leuven, Kasteelpark Arenberg 10, 3001 Heverlee, Belgium 6 Department of Mechanical and Process Engineering (D-MAVT), ETH Zurich, Rämistrasse 101, 8092 Zurich, Switzerland

Resume : It is well known that Molybdenum (Mo) is not an ideal rear contact for Cu2ZnSn(S,Se)4 (CZTSSe) solar cells: (i) CZTSSe reacts with Mo and decomposes to secondary phases which contribute to recombination currents, and (ii) the band alignment between Mo and CZTSSe is not optimum to extract charges leading to recombination. Here, in order to address those issues, we present two approaches. (i) Increasing the thickness of the absorber layer to increase the distance between the pn junction and the rear contact. (ii) Introducing a metal oxide layer to improve the interface quality and match its energy levels. CZTSSe absorber layers were prepared by selenization of e-beam evaporated Sn/Zn/Cu stacks using H2Se diluted gas at 460 ºC. The thickness of Sn/Zn/Cu stack has been changed while the composition was constant. Solar cells were fabricated for absorbers with different thicknesses. These cells were characterized by illuminated-dark current-voltage, capacitance-voltage, scanning electron microscopy, energy dispersive spectroscopy and time resolved photoluminescence. The results indicate that by increasing the thickness from 0.7 µm to 2.0 µm, open circuit voltage improves from 330 mV to 420 mV, while short circuit currents saturate after 1 µm. The highest efficiency of 7.3 % (without antireflection coating) was achieved for a sample with 1.2 µm thickness, as this sample had lower series resistance and higher fill factor compared to thicker samples. Yet introducing suitable metal oxide buffer layers using Mo/MoO3 as rear contact is in progress.

V.P3.37
14:00
Authors : Carrie L. McCarthy, Richard Brutchey
Affiliations : University of Southern California, 840 Downey Way, LJS 265, Los Angeles, CA 90089, U.S.A.

Resume : Our group has developed a relatively benign binary solvent system consisting of ethylenediamine and a short chain thiol that is capable of dissolving a myriad of bulk inorganic materials under ambient conditions. Upon thermal annealing at low temperatures, phase pure, crystalline chalcogenide materials can be recovered. This method is a simple and safe alternative to using hydrazine chemistry to solution process similar materials. Recently this binary solvent system has been used to solution process thin films of ternary materials such as CuIn(S,Se)2 (CIGS) and Cu2ZnSn(S,Se)4 (CZTS) for photovoltaic (PV) applications. In the work presented here, the thiolamine solvent mixture is used to dissolve bulk inorganic oxides and chalcogenides to generate precursor inks that can be spin coated onto a desired substrate, and upon mild annealing, yield phase-­‐pure chalcogenide thin films. For example, thin films of Sb2S3 and Sb2Se3 can be recovered from inks made with bulk Sb2O3, or Sb2O3 in the presence of Se, respectively, and show high photoelectrochemical current response. More interestingly, by varying the nominal composition of Se in the precursor ink, a series of Sb2Se3-xSx alloys can be recovered and their direct band gaps can be tuned from 1.2­-1.6 eV, thus covering the optimal range for a PV absorber material in a single junction cell. Thin films of CuSbS2 (Eg = 1.5 eV) are also readily prepared using this ink formulation method with Cu2S and Sb2S3 as precursors.

V.P3.38
Start atSubject View AllNum.Add

CIGS characterization : S. Ishizuka, T. Lepetit
08:30
Authors : A. Kanevce, D. Kuciauskas and T. Barnes
Affiliations : National Renewable Energy Laboratory

Resume : Nonradiative recombination is one of the major sources of loss in thin film solar cells. Therefore, device improvement requires understanding and quantifying of recombination at surfaces, interfaces, grain interior and grain boundaries. In a time-resolved photoluminescence (TRPL) measurement, the light is absorbed according to Beer’s law. For CdTe and Cu(In,Ga)Se2, most of the carrier generation occurs in the vicinity of the surface. As a result, surface recombination and potential impact or dominate the results, and bulk minority-carrier lifetime can not be accurately determined. Two-photon excitation (2PE) TRPL allows focusing the laser beam away from the surface and enables minority-carrier lifetime determination at an arbitrary location in the material and device. 2PE carrier generation allows spatial probing, lateral and in depth, to reveal spatial nonuniformities in carrier lifetime and to create 2D or 3D maps of carrier recombination. However, diffusion of carriers inevitably affects the measured decays, especially in high quality materials with long diffusion lengths. To reduce the impact of diffusion, a larger spot size is needed, which reduces the measurement resolution. We present 2D TCAD numerical simulations describing carrier dynamics during the decays. The simulations determine the impact of material parameters, such as carrier lifetime and diffusion length, as well as surface recombination and potential on the measured results. This knowledge is important for accurate data interpretation and to establish the conditions under which one can unambiguously separate bulk and surface recombination.

V.VII.1
09:00
Authors : Benjamin Bissig(1), Carlos Guerra-Nunez(2), Shiro Nishiwaki(1), Fabio La Mattina(3), Fabian Pianezzi(1), Enrico Avancini(1), Romain Carron(1), Patrick Reinhard(1), Stefan Haass(1), Martina Lingg(1), Thomas Feurer(1), Ivo Utke(2), Stephan Buecheler(1), and Ayodhya N. Tiwari(1)
Affiliations : 1) Empa - Laboratory for Thin Films and Photovoltaics 2) Empa - Laboratory for Mechanics of Materials and Nanostructures 3) Empa - Laboratory for Electronics/Metrology/Reliability Empa - Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstrasse 129, 8600 Duebendorf Switzerland

Resume : In this contribution the electron beam induced current technique (EBIC) is used to investigate residual near infrared losses in the external quantum efficiency (EQE) of state of the art Cu(In,Ga)Se2 based thin film solar cells. Such losses are generally ascribed to optical- (reflection, parasitic absorption in window/buffer or non-sufficient absorption in the absorber) and/or collection losses (photo carrier recombination). A direct assessment of the respective share appears to be difficult as the development of a reliable optical model of rough and CGI/GGI graded material - as used in real devices - is challenging. Depth resolved information about collection probability can be obtained from EBIC measurements, however, the results tend to be strongly affected by cross section surface recombination. Here, we present an approach to reduce the recombination at the fractured cross section surface by exploiting the passivation properties of atomic layer deposited Al2O3. It is found that collection remains efficient (>75 %) up to 300 nm away from the back contact of a 2.2 μm thick absorber. A model for the passivation mechanism is illustrated by investigating the effect of electron beam parameters on EBIC measurements. Such Al2O3 enhanced profiles are used to compare calculated and measured EQE which show a significant improvement of the predictive power of EBIC measured on passivated surfaces as compared to the uncoated case. Implications on the understanding of residual EQE losses and absorber design are discussed. Finally it is shown that this concept also holds for other technologies such as CdTe and Cu(Zn,Sn)(S,Se)2.

V.VII.2
09:15
Authors : F. Werner, T. Bertram, C. Spindler, and S.Siebentritt
Affiliations : Physics and Materials Science Research Unit, University of Luxembourg, Rue du Brill 41, L-4422 Belvaux, Luxembourg

Resume : The net dopant concentration of the absorber layer is a crucial parameter for understanding and optimizing the performance of a solar cell. Reported dopant concentrations for comparable specimen however often vary by more than one order of magnitude. Most data on the dopant concentration of polycrystalline thin film absorbers is obtained by either Hall or capacitance-voltage (C-V) measurements. Although both in principle permit a fast and convenient characterization, the simple models almost exclusively employed in the analysis neglect any influence of grain boundaries on the measurements. In our contribution, we obtain the dopant concentration for a set of Cu-poor Cu(In,Ga)Se2 thin film absorbers from Hall measurements, carefully taking into account the effect of grain boundaries on the analysis. We obtain the same net dopant concentrations for films grown on glass and for films mechanically ripped from a conductive molybdenum back contact, which permits to compare Hall and C-V measurements on the same sample. Furthermore, the low mobility values well below 1 cm2/Vs agree with theoretical predictions of a depleted grain boundary and allow us to identify the dopant concentration obtained from Hall measurements with a lower limit of the true in-grain dopant concentration. However, C-V measurements on the same absorbers yield significantly lower dopant concentrations. This might be linked to the potential distribution in the absorber, which can no longer be described adequately by a one-dimensional model in the presence of grain boundaries.

V.VII.3
09:30
Authors : M. Igalson1, K. Macielak1, A. Urbaniak1, N. Barreau2, J. Larsen3
Affiliations : 1 Faculty of Physics, Warsaw University of Technology, Poland; 2 Institut des Materiaux Jean Rouxel, Universite de Nantes, Nantes, France; 3 Ångström Solar Center, Uppsala University, Sweden

Resume : Photoinduced current transient spectroscopy (PICTS) was proven to be a powerful tool for investigation of the electronic parameters of deep bulk levels in the CIGS absorbers. In our previous publications we were able to distinguish deep levels appearing in both epitaxial and polycrystalline layers of various Ga content. Some of them, and these are of particular interest, have been found in all CIGS materials irrespective of their morphology and Ga/In ratio, and also observed also by capacitance methods in CIGS solar cells. In this report we would like to present a new approach for studying these levels: Excitation PICTS. First we measure the PICTS spectrum using LED diode and box-car averaging of the transient photocurrent. Then the excitation spectra for levels differentiated by PICTS are measured using chopped illumination in the range 400-1800 nm and phase-sensitive detection. The frequencies and temperatures of measurements corresponding to the PICTS maxima are chosen in order to determine excitation energy for a given defect level. We will present the results both for the epitaxial and polycrystalline thin films. Special attention will be paid to the cases of the disagreement between the sum of the thermal activation and excitation energies with the bandgap. The failure to observe such agreement and its possible sources such as negative correlation energy or barrier for carriers capture will be discussed.

V.VII.4
09:45
Authors : N. Nicoara (1), T. Lepetit (2), L. Arzel (2), S. Harel (2), N. Barreau (2), S. Sadewasser (1)
Affiliations : (1) International Iberian Nanotechnology Laboratory (INL), Av. Mestre José Veiga s/n, 4715-330 Braga, Portugal; (2) Institut des Materiaux Jean Rouxel (IMN) - UMR6502, Universite de Nantes, CNRS, 2 rue de la Houssiniere, BP 32229, 44322 Nantes Cedex 3, France

Resume : Recent efficiency improvements in Cu(In,Ga)Se2 (CIGS) thin-film solar cells were achieved by the application of a potassium post-deposition treatment (K-PDT), applied after the deposition of the CIGS absorber layer by a co-evaporation process. We use Kelvin probe force microscopy (KPFM) to study the effect of the K-PDT on the CIGS surface by spatially resolved imaging of the surface potential. We investigated the CIGS sample surface, and also the initial growth of the CdS buffer layer, after deposition of a thin CdS layer for 1 minute by chemical bath deposition. We observe an increase in the overall contact potential difference (CPD) for samples with K-PDT as compared with samples without K-PDT, while the variations of the overall CPD are comparable for all samples. The thin CdS layer reduces the CPD by 80 - 130 mV. A clear difference is observed in electronic properties of grain boundaries (GBs) observed by KPFM: the K-PDT increases the band bending at GBs by about 70% and results in a narrower distribution of CPD values at the GBs. This effect of the K-PDT on GBs electronic properties could additionally contribute to the improved efficiency values observed for CIGS thin-film solar cells with K-PDT. This work was supported by cooperation program Portugal-France FCT-Pessoa 2015/2016.

V.VII.5
10:00 Coffee break

CIGS growth : M. Igalson, A. Kanevce
10:30
Authors : Shogo Ishizuka
Affiliations : National Institute of Advanced Industrial Science and Technology (AIST)

Resume : The highest efficiency of Cu(In,Ga)Se2 (CIGS) solar cells has currently been demonstrated using CIGS thin films with a band-gap energy (Eg) of about 1.1 eV, corresponding to the [Ga]/([Ga]+[In]) (GGI) composition ratio of about 0.3, though the ideal Eg value is speculated to be about 1.4 eV (GGI ~ 0.6) for the case of single junction cells. To enhance CIGS cell efficiencies, therefore, material and device properties of highly Ga-containing CIGS or ternary CuGaSe2 (CGS) have long been studied and many efforts have been made to improve wide-gap CIGS solar cell performance thus far. In our recent work, we have for the first time demonstrated double digit efficiency (>10%) for elementally In-free ternary CGS thin film solar cells. The Se to metal flux ratio used during co-evaporation growth of CGS films was found to be an important parameter and affected alkaline Na and K diffusions in CGS films and led to the formation of a Cu-deficient layer (so-called ordered vacancy defect: OVC) on the CGS film surface, resulting in the formation of n-OVC/p-CGS junction. We have also found that the interface properties of ternary CGS solar cells are different from quaternary CIGS cells and thus post-growth processes for CdS buffer and ZnO window layer depositions on CGS films require specialized conditions different from the case for CIGS to demonstrate good device performance. These understandings are expected to contribute to explore highly efficient wide-gap CIGS solar cells as well.

V.VIII.1
11:00
Authors : Conrad Spindler, David Regesch, Susanne Siebentritt
Affiliations : Physics and Materials Science Research Unit, University of Luxembourg

Resume : It has been argued based on defect calculations, that CuGaSe2 solar cells are limited by GaCu defects, which form a deep state in the band gap. We aim at studying deep defects by photoluminescence. The studies on epitaxial CuGaSe2-films revealed two deep donor-acceptor-pair transitions. Cu-rich samples were used for a detailed analysis due to higher crystal quality, exciton luminescence and the absence of potential fluctuations. Gaussian-shaped luminescence peaks at 1.23 eV (DDA1) and 1.10 eV (DDA2) were characterized by temperature- and intensity-dependent measurements. From this it is suggested that both transitions occur from two deep donor levels into the same shallow acceptor around 100 meV. For T=10K, both transitions show a power law intensity dependence with changes from linear at low intensities to square root like at high intensities. Based on rate-equation-models it can be shown that the acceptor becomes saturated rather than the deep levels. From this it is concluded that at high excitations the electron-quasi-fermi level is pinned by the deep levels. Furthermore, it can be shown that these two pair transitions differ in Cu-poor samples. The luminescence peak around 1.10 eV (involving the deepest donor-like level) is significantly reduced. While the exact energy position of the deep donors remains unclear, the observed transitions seem to play a major role as electron recombination centers in Cu-rich CuGaSe2.

V.VIII.2
11:15
Authors : Thomas Lepetit(a), Sylvie Harel(a), Ludovic Arzel(a), Eric Gautron(a), Guy Ouvrard(a), Thierry Douillard(b),Thierry Epicier(b) and Nicolas Barreau(a)
Affiliations : (a) Institut des Matériaux Jean Rouxel (IMN) UMR 6502 CNRS-Université de Nantes, 2 rue de la Houssinière BP 32229, 44322 Nantes Cedex3, France (b) Matéis, UMR 5510, INSA de Lyon, F-69621 Villeurbanne Cedex, France

Resume : Recently developed potassium fluoride post-deposition treatment (KF-PDT) of Cu(In,Ga)Se2 absorber has allowed the achievement of 22.3% devices. Such a treatment improves both the open circuit voltage (Voc) and the fill factor of the solar cells. Moreover, it allows the reduction of the CdS buffer layer deposition duration by chemical bath deposition (CBD), leading to thinner CdS layers thus increased short circuit current. In the present work, we have investigated the heterojunction formation in 20 % energy conversion efficiency device treated with KF. We have analyzed by X-ray photoelectron spectroscopy and scanning electron microscopy the surface of KF-treated absorbers right after the KF-PDT and after different dipping durations in the CBD. KF-PDT treatment yields the formation of a thin KInSe2 phase at the CIGS surface. We show that (i) the KInSe2 induces a much more homogeneous growth of the buffer layer than onto the CIGS and (ii) the KInSe2 is turned into CdIn2(S,Se)4 in the CBD by substitution of K by Cd and Se by S. Transmission electron microscopy has revealed that a 5-nm thick CdIn2(S,Se)4 interface layer is present in complete device between the CIGS and the CdS. This material has been reported in literature to have n-type conductivity. Finally, KF-PDT and (CBD)CdS lead to an asymmetric junction between CIGS and CdIn2(S,Se)4, that could explain the increase of the Voc and why it is possible to thin the CdS layer.

V.VIII.3
11:30
Authors : Torben Klinkert1, Frederique Donsanti2+1, Marie Jubault2+1, Negar Naghavi3+1
Affiliations : 1 Institut Photovoltaïque d’Ile de France, 8 rue de la renaissance, 92160 Antony, France; 2 EDF R&D, Institute of Research and Development on Photovoltaic Energy (IRDEP), Chatou, France; 3 CNRS, IRDEP, UMR 7174, 78401 Chatou, France

Resume : Flexible and lightweight Cu(In,Ga)Se2 solar modules have a drastically increased potential for building-integration and allow for an industrial roll-to-roll process with increased throughput. Polyimide foils are a promising candidate to replace the standard glass substrate. The incorporation of alkaline dopants into the CIGS is a major challenge for alkaline-free substrates. Post-deposition treatments (PDT) with NaF and KF led to cell efficiencies up to 20.4 % but the influence of the PDT conditions (temperature, duration) on the alkaline concentration-profile and the morphology of the absorber layer and solar cell is not clear yet. This work aims to close this gap. Using a 3-stage co-evaporation process yielding a cell efficiency of 9.7 % (alkaline-free), KF and NaF PDT under various conditions were first studied separately and then combined. A pure KF PDT increased the efficiency to 11.8 % and a NaF PDT to 14.1 %. Bare and H2O rinsed absorber layers as well as complete solar cells were investigated by GD-OES and SEM. The rinsing washed off nanometric agglomerates from the CIGS surface and the influence of the PDT conditions on the Na profile (duration increased Na concentration, temperature increased penetration) was found to disappear. In certain cases a slight nano-structuration of the surface was observed. Finally as the alkaline treatments influence the p-n junction quality, solar cells with CdS and alternative Zn(O,S) buffer layers will be compared.

V.VIII.4
11:45
Authors : E. Avancini, B. Bissig, P. Reinhard, R. Carron, S. Nishiwaki, T. Feurer, S. Buecheler and A. N. Tiwari
Affiliations : Laboratory for Thin Films and Photovoltaics, Empa-Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstr. 129, 8600 Duebendorf, Switzerland

Resume : Highly efficient co-evaporated Cu(In,Ga)Se2 (CIGS) absorbers are typically grown with a [Ga]/([Ga]+[In]) (GGI) gradient across the thickness and a Cu-poor composition. Upon increasing the Cu content towards the CIGS stoichiometry, lower defect density is expected, which should lead to increased diffusion length and carrier collection. Further, optimization of the GGI grading is expected to increase the near infra-red (NIR) response. In this contribution [Cu]/([In]+[Ga]) (CGI) values are increased by shortening the deposition stage after the first stoichiometry point. In order to obtain comparable Ga contents at the interface for proper band alignment, the GGI gradings were modified. With a relative CGI increase of 7%, we observe an increased photocurrent, originating from an improved NIR external quantum efficiency response. Adequate tuning of front GGI allows maintaining Voc and FF values, yielding an overall increase of efficiency as compared to a reference baseline. Further reductions in the final stage duration do not lead to additional improvements. The net majority carrier concentrations, measured by capacitance-voltage profiling, are found to be similar up to a relative CGI increase of 15%. We further characterize the modified absorber properties by reflection-transmission spectroscopy and time-resolved photoluminescence. We suggest that optical absorption and carrier collection can be improved by composition and grading modifications for state-of-the-art devices.

V.VIII.5
12:00 Lunch break

Surfaces and interfaces : S. Levcenko, B. Bissig
13:30
Authors : Bart Vermang [1,2,3], Marika Edoff [3]
Affiliations : [1] Imec – partner in Solliance, Kapeldreef 75, 3001 Leuven, Belgium, [2] University of Leuven, Kasteelpark Arenberg 10, 3001 Leuven, Belgium, [3] University of Uppsala, P.O. Box 534, 75121 Uppsala, Sweden

Resume : In CIGS(e) solar cell research, a novel area of attention is the Mo/CIGS(e) rear interface, where recombination of charge carriers typically is rather high. A rear surface passivation layer with nano-sized contacts has been suggested and developed as innovative approach to reduce recombination of charge carriers at the rear CIGS(e) semiconductor interface. This design stems from the Si PV industry, but employing the concept in a CIGS(e) solar cell requires a scale down of all dimensions. It is needed to shrink the Si rear passivation design about 100 times and, instead of a contact hole size of several micrometres, aim for a hole size of 20-200 nm with a pitch of a few micron. Another area of attention where recombination of charge carriers is too high is the CIGS(e)/CdS front interface. Very recently, several techniques that could generate a front surface passivation layer with nano-sized point openings have been proposed, e.g. the spray-ILGAR® (ion layer gas reaction) and the SALT (self-assembled alkali-templates) approaches. Initial calculations indicate that in this case the design is even more demanding: A hole size of 10-100 nm with a maximal pitch of a few hundreds of nm is aimed for. This presentation will discuss recent developments in electrical passivation of CIGS(e) surfaces: From its fundamentals to solar cell applications, and their perspective.

V.IX.1
14:00
Authors : Marie Buffière1,2,3, Abdel-Aziz El Mel4, Nick Lenaers2,5, Thomas Lepetit4, Guy Brammertz7,8, Armin E. Zaghi2,5, Marc Meuris7,8 and Jef Poortmans2,3,8
Affiliations : 1 Qatar Environment and Energy Research Institute (QEERI), HBKU, Qatar Foundation, Doha, Qatar 2 imec – partner in Solliance, Kapeldreef 75, 3001 Leuven, Belgium 3 Department of Electrical Engineering (ESAT), KU Leuven, Kasteelpark Arenberg 10, 3001 Heverlee, Belgium 4 Institut des Matériaux Jean Rouxel, Université de Nantes, CNRS, 2 rue de la Houssinière B.P. 32229, 44322 Nantes cedex 3, France 5 Department of Metallurgy and Materials Engineering (MTM), KU Leuven, Kasteelpark Arenberg 44, 3001 Heverlee, Belgium 6 Electronics and Information Systems department (ELIS), University of Gent, Sint-Pietersnieuwstraat 41, 9000 Gent, Belgium 7 imec division IMOMEC – partner in Solliance, Wetenschapspark 1, 3590 Diepenbeek, Belgium 8 Institute for Material Research (IMO) Hasselt University, Wetenschapspark 1, 3590 Diepenbeek, Belgium

Resume : Chalcogenide thin films (i.e., CdTe, Cu(In,Ga)Se2, Cu2ZnSnSe4) have attracted intensive research over the past two decades to produce low cost and high efficiency thin film solar cells. As recently demonstrated [1], one of the major challenges to improve the performance of such devices is the control of the surface properties of the absorber. In the present contribution, we report on alternative chemical approaches that can be applied at room temperature to modify the surface of Se-based chalcogenide thin films, using ammonium sulfide (AS) as a treating agent. A first chemical treatment process has been developed based on the immersion of Cu(In,Ga)Se2 (CIGSe) absorber into an AS solution [2]. This treatment results in the removal of the undesirable CuxSe secondary phase from the absorber surface and in the incorporation of sulfur into the surface region of the material. Both of these effects lead to the improvement of the open circuit voltage and the minority carrier lifetime of the treated devices. A second chemical treatment has been developed based on the use of AS vapor as a sulfur source. When applied to CuInSe2 (CISe) absorbers, the exposure to AS vapor leads to the progressive formation of CuIn(S,Se)2 at the surface of CISe thin films. The open circuit voltage of the CISe/CdS/ZnO devices is found to be reproducibly improved by about 30 mV after 10 min of treatment compared to a reference device. The impact of the AS treatments duration on the physical and electrical properties of chalcogenide solar cells was also evaluated for Cu2ZnSnSe4 photovoltaic devices. [1] Chirila A. et al., Nature Materials 2013, 12, 1107–1111. [2] Buffière M. et al., Adv. Energy Mater. 2015, 5: doi: 10.1002/aenm.201401689

V.IX.2
14:15
Authors : D. Hauschild (1), E. Handick (1), S. Göhl-Gusenleitner (1)‚ F. Meyer (1), H. Schwab (1), A. Benkert (1,2), J. Palm (3), S. Tougaard (4), C. Heske (2,5,6), L. Weinhardt (2,5,6), F. Reinert (1)
Affiliations : (1) Experimental Physics VII, University of Würzburg; (2) Institute for Photon Science and Synchrotron Radiation (IPS), Karlsruhe Institute of Technology (KIT); (3) AVANCIS GmbH; (4) Department of Physics, Chemistry and Pharmacy, University of Southern Denmark; (5) Department of Chemistry and Biochemistry, University of Nevada, Las Vegas (UNLV); (6) Institute for Chemical Technology and Polymer Chemistry (ITCP), Karlsruhe Institute of Technology (KIT);

Resume : It has been a long-standing discussion in a variety of semiconductor communities [in particular for CuInGaSe2 (CIGS) thin film solar cells] to determine the band gap of a specific material. Variations between bulk and surface, but also between optically and electronically determined band gaps have been controversially debated. For CIGS, pioneering photoelectron spectroscopy (PES) measurements [Schmid et al., JAP 73, 2902-2909 (1993)] pointed towards a band gap widening at the surface of the chalcopyrite absorber, which was subsequently directly confirmed and quantified by a combination of PES and inverse PES (IPES) [Morkel et al., APL 79, 4482-4484 (2001)]. In this contribution, we use reflective electron energy loss spectroscopy (REELS) as a complementary method to study surfaces and interfaces in such systems. By analyzing the characteristic inelastic scattering cross-section λK(E), we have determined the surface dielectric function and thus the optical properties of a Cu(In,Ga)(S,Se)2 (CIGSSe) absorber, an as-grown indium sulfide (InxSy) buffer, and an annealed InxSy buffer. A comparison of the optical values at the surface of the InxSy film with bulk ellipsometry measurements indicates a good agreement between bulk- and surface-related optical properties. In contrast, the CIGSSe absorber shows a larger electronic surface band gap than for bulk-sensitive measurements, providing a complementary and independent confirmation of the earlier results.

V.IX.3
14:30
Authors : Sebastian Bröker, Dennis Kück, Alexander Timmer, Iver Lauermann, Bünyamin Ümsür, Dieter Greiner, Christian A. Kaufmann, Harry Mönig
Affiliations : Physikalisches Institut Universität Münster; Physikalisches Institut Universität Münster; Physikalisches Institut Universität Münster; Helmholtz-Zentrum Berlin für Materialien und Energie; Helmholtz-Zentrum Berlin für Materialien und Energie; Helmholtz-Zentrum Berlin für Materialien und Energie; Helmholtz-Zentrum Berlin für Materialien und Energie; Physikalisches Institut Universität Münster

Resume : The unusual defect chemistry of polycrystalline Cu(In,Ga)Se2 (CIGSe) thin films is a main issue for a profound understanding of recombination losses in chalcopyrite thin film solar cells. Especially impurity driven passivation of electronic levels due to point defects segregating at the surface and at grain boundaries is extensively debated. By combining current imaging tunneling spectroscopy with photoelectron spectroscopy, the local defect level density and unusual optoelectronic grain boundary properties of this material are correlated with the macroscopic energy levels and surface composition. Vacuum annealing of different CIGSe materials provide evidence that sodium diffusion from the glass substrate does not affect the surface defect passivation or grain boundary properties of standard Cu-poor materials. Furthermore, we find no major impact on the observed thermally activated dipole compensation or the accompanying change in surface band bending (up to 0.6eV) due to sodium. In contrast, Cu-rich CIGSe shows an opposing surface defect chemistry with only minor heat induced band bending. Our results lead to a comprehensive picture, where the highly desirable type inversion at the p/n-interface in standard chalcopyrite thin film solar cells is dominated by band bending within the CIGSe absorber, rather than the result of Na impurities or a n-type defect phase segregating at the interface. This is in accordance with recent studies suggesting a surface reconstruction as origin for the Cu-depletion and band gap widening at the surface of chalcopyrite thin films.

V.IX.4
14:45
Authors : Debora Keller [1,2], Stephan Buecheler [1], Patrick Reinhard [1], Fabian Pianezzi [1], Benjamin Bissig [1], Fredrik Hage [3], Quentin Ramasse [3], Rolf Erni [2], Ayodhya N. Tiwari [1]
Affiliations : [1] Laboratory for Thin Films and Photovoltaics, Empa - Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstrasse 129, CH-8600 Duebendorf, Switzerland; [2] Electron Microscopy Center, Empa - Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstrasse 129, CH-8600 Duebendorf, Switzerland; [3] SuperSTEM Laboratory, STFC Daresbury Campus, Keckwick Lane, Daresbury WA4 4AD, United Kingdom

Resume : The efficiency of Cu(In,Ga)Se2 (CIGS) solar cells is strongly affected by structural and compositional inhomogeneities in the absorber layer, which locally influence its electronic properties and also the charge carrier transport. However, a deeper understanding on how such nanoscale inhomogeneities influence electronic loss mechanisms in CIGS is still needed to further improve the solar cell performance. Therefore, the local characterization of electronic properties such as the band gap energy (Eg) is of high interest. Valence electron energy loss spectroscopy (VEELS) provides information about the Eg in the nanometer scale. However, the high energy resolution, which is required to access the small Eg of CIGS, is pushing towards the achievable limits of state-of-the-art electron sources. In this work we use a 2nd generation monochromator that provides a very high energy resolution to study the electronic properties at selected sites in CIGS by VEELS. First results of local Eg measurements within the bulk, at grain boundaries (GBs) and across the surface of CIGS are presented. E.g. we observe a variation in electronic properties that is correlated with the nanopatterned surface structure of CIGS. Further, the Eg varies as a function of compositional inhomogeneities in the bulk, but no distinct Eg fluctuations are observed at GBs. The possible effects of the observed nanoscale fluctuations in electronic properties are finally discussed in view of the solar cell performance.

V.IX.5
15:00
Authors : Negar Naghavi
Affiliations : CNRS, IRDEP, IPVF, 6 quai Watier, 78401, Chatou, France

Resume : The benefit of reducing the thickness of the Cu(In,Ga)Se2 absorber (CIGSe) is beyond the reduced material costs and production time. It also lowers the minimum quality requirements for the CIGSe layer, since shorter pathways for electron extraction allow shorter electron diffusion lengths. However, the design of ultrathin solar cells raises specific issues in terms of absorber quality, light management and electronic transport and in terms of the requirements on the interface quality due to the increased charge carrier density at the contacts. The aim of this presentation is to give an overview of the state of the art of ultrathin CIGS solar cells and to present some results and perspectives for improvement of the opto-electronic properties of ultra-thin solar cells. The impact of the deposition techniques for CIGS such as coevaporation, reactive sputtering and electrodeposition on the properties of ultrathin absorbers will be discussed.

V.IX.6
15:30 Coffee break
16:00
Authors : Youssef Arba (a), Bouchaib Hartiti(a), Abderraouf Ridah(a), Philippe Thevenin(b)
Affiliations : (a)Department of Physics FST, Hassan II Mohammedia University Mohammedia, Morocco; (b)Department of Physics Supelec, University of Lorraine Metz, France

Resume : Thin films of Cadmium sulfide CdS is one of the promising semiconductor materials which can be used as a window or tampon layer in thin film solar cells thanks to its tunable direct band gap energy, large transmission coefficient and cost effective. The role of the CdS layer is still debate within the scientific community, but the devices are still very high efficiency obtained with this fine n-type semiconductor layer. It could protect the damage associated with the following spraying deposits passivated defects in the surface of the absorber or adapt the width of the energy band gap between the absorber (~1.2eV) and the window layer (~3,3eV). The aim of this present study is to investigate the influence of parameters deposition of CdS, thin films using the L27 orthogonal array of the Taguchi?s design of experiments elaborated by spray pyrolysis method on ordinary glass substrate. The Taguchi design was used to evaluate the effects of eight deposition parameters, called factors, on optical and electrical properties of elaborated films. Those factors are the ratios Metal/S, [In3+]/[Cd2+], [Fe2+]/[Cd2+], [Sn3+]/[Cd2+], solution rate, air-compression, time of deposition and substrate temperature. The identification of the most influent factor of the deposition process on the band gap energy and the conductance of elaborated films is also done by employing the analysis of variance (ANOVA). The Taguchi analysis employed in the present investigation led to optimize process parameters for the most optimal deposition conditions.

V.P4.1
16:00
Authors : Choubrac Léo, Samira Khelifi, Sylvie Harel, Ludovic Arzel, Johan Lauwaert, Nicolas Barreau
Affiliations : CNRS-IMN, Université de Nantes, Gent University

Resume : Low temperature annealing of completed cells is reported by several authors as beneficial to CZTX/CdS based solar cells. [Neuschitzer, 2015 / Hironiwa, 2015] Cations diffusion at homo and hetero interfaces (grain boundaries and CZTX/CdS) plays a major role in this feature: Cu migration into the CdS, Cd into the CZTX, copper/zinc ratio changes at grain boundaries were observed by different authors. Similarly, In-supply to CdS and CZTS can boost the efficiencies, providing a good control of In-diffusion. [Kim, 2014] The present study consists in comparing the impact of annealing of CZTSe based solar cells with different buffer layers, in order to better understand the role of the different elements. CBD deposed CdS and Zn(O,S) and evaporated In2S3 and CdIn2S4 have been used. IV and EQE measurements are used to determine trends on the solar cell parameters evolution with annealing at different temperature/time, and check what features are reversible with time. Samples leading to the most remarkable parameters evolution are selected for advanced electrical measurements. The outputs of this study are: _A better understanding of the role of the different elements migration during annealing on CZTX-based solar cells, leading to a boost of cells efficiencies thanks to fine tuning of the annealing conditions (from 2 to 8% with CdS buffer without ARC) _Developpement of a new buffer layer material (CdIn2S4) for CZTSe based solar cells (efficiencies of 6.5% without ARC)

V.P4.2
16:00
Authors : Yong-Duck Chung1, 2*, Woo-Jung Lee1, Dae-Hyung Cho1, Jae-Hyung Wi1, Won Seok Han1, Boo-Kyoung Kim3, Sang Dae Choi3, Ju-Yeoul Baek3
Affiliations : 1Electronics and Telecommunications Research Institute, 218, Gajeong-ro, Yuseong-gu, Daejeon 34129, Republic of Korea; 2Korea University of Science and Technology, 217 Gajeong-ro, Yuseong-gu, Daejeon 34113, Republic of Korea; 3SNTEK Co., Ltd. 1433-100, Seobu-ro, Gwonseon-gu, Suwon-si, Gyeonggi-do, 16643 Republic of Korea

Resume : Chemical-bath-deposited (CBD) ZnS buffer layer is being steadily studied in Cu(In,Ga)Se2 (CIGS) thin-film solar cell because of their beneficial properties, for examples, good transparency with large direct bandgap, less toxicity and cost effectiveness. CBD-ZnS buffer layer, however, is easily affected during subsequent sputtering process for TCO layer and the conversion efficiency decreases with sputtering power. The efficiency decrease of the CBD-ZnS/CIGS thin-film solar cells is known to be related to plasma damage originated from high energy negative oxygen ions or neutral particles at the interface. It is important to develop a process for a high-quality interface between CBD-ZnS and CIGS. In this study, we developed the CBD-ZnS film by changing the process condition and applied the dual-facing targets sputtering process to TCO layer for reducing the plasma damage. The effects of plasma damage were investigated and the properties of TCO layer deposited by low damage process were characterized. Finally, the effects of sputtering process on the conversion efficiency of CBS-ZnS/CIGS thin-film solar cell were analyzed.

V.P4.3
16:00
Authors : Moises Espindola-Rodriguez1, Ignacio Becerril1, Yudania Sanchez1, Florian Oliva1, Simón Lopez-Marino1, Markus Neuschitzer1, Sergio Giraldo1, Victor Izquierdo-Roca1, Alejandro Pérez-Rodríguez12, Edgardo Saucedo1, Marcel Placidi1
Affiliations : 1Catalonia Institute for Energy Research (IREC), Sant Adrià del Besòs-Barcelona, Jardins de les Dones de Negre 1 2pl., 08930, Spain. 2IN2UB, Departament d’Electrònica, Universitat de Barcelona, Martí i Franquès 1, 08028 Barcelona, Spain

Resume : Several works studying the effect of the intrinsic ZnO (i-ZnO) layer on the performance of CIGSe solar cells have been reported nevertheless, many questions concerning its beneficial role still remains under debate. This oxide layer is of particular importance not only for CIGS but for most of thin film based technologies including CZTSe. In those technologies the same window strategy is used: i-ZnO followed by a transparent conducting oxide (TCO) as front contact. We report on the impact of incorporating 0%, 5%, 10% and 15% oxygen during i-ZnO sputtering correlated with the optoelectronic properties of CZTSe solar cells. The optical properties of the window layers (i-ZnO/TCO) were first investigated using normal incident transmittance by UV-VIS-NIR spectrometer, before and after performing hot plate air annealing at 200ºC (commonly used after cell fabrication to improve heterojunction quality). The annealed films showed improved transmittance over all visible electromagnetic spectrum and enhanced crystallinity as revealed by Raman scattering. The CZTSe solar cells fabricated with these window layers have improved optoelectronic properties following the oxygen incorporation by increasing the open circuit voltage, fill factor and hence efficiency, from 6.5% (0% oxygen) to 7.7% (15% oxygen). The results on the J-V characteristics under different light conditions indicate that the oxygen addition during the i-ZnO deposition has a strong effect on the commonly observed red-kink and cross-over that increases with oxygen.

V.P4.4
16:00
Authors : Cheul Ho Ha, Mingyang Zhu, Si Ok Ryu*
Affiliations : School of Chemical Engineering, Yeungnam University, 280 Daehak-ro, Gyeongsan 712-749, South Korea

Resume : Zn(O,S) used as an active layer of thin film transistors has been considered as an attracted material because of its wide energy band gap and high transparency for various optoelectronic devices. In addition, it is a prominent candidate for a Cd-free buffer layer in thin film solar cells due to its no environmental issues. There are lots of researches on Zn(O,S) are performed by using the solution-based processes because of their low cost, high throughput, inexpensive, and continuous roll-to-roll advantages. In this study, Zn(O,S) thin films was synthesized by a new solution-based method designed by utilizing printing technique. In the preparation of precursor inks, ZnSO4 and thiourea were used with continuous flow reactor and ratio of O/S was controlled by the concentration of thiourea. Then, Zn(O,S) thin films was deposited with the precursor inks by the printing process. The prepared Zn(O,S) films were characterized with X-ray diffraction spectrometer (XRD), scanning electron microscopy (SEM), energy dispersive X-ray spectroscopy (EDX), UV-visible spectrophotometer, and X-ray photoelectron spectroscope (XPS). Based on the physicochemical analyses, it was found that the good quality of Zn(O,S) thin films were successfully deposited by the printing process and a very short period time was taken to deposit an enough thickness for the TFT devices. We believe that this is the first experimental research work on the deposition of Zn(O,S) thin films using the printing process.

V.P4.5
16:00
Authors : M.A. Jafarov, E.F. Nasirov, S.A.Jahangirova
Affiliations : Baku State University, Baku, Azerbaijan, maarif.jafarov@mail.ru

Resume : Zinc sulfide (ZnS) thin film is a promising material for its use in various application devices due its high refractive index and high transmittance in the visible wavelength range. ZnS thin films were prepared on the glass substrates by CBD method using aqueous solutions of zinc acetate and thiourea at pH 10 and temperature was maintained at 950C. The non-toxic complexing agent tri-sodium citrate (Na3-citrate) was used to control the unwanted release of Zn2+ ions. The solutions were prepared in deionized water and films were deposited on İTO glass substrates. The reaction bath solution was prepared using 40 mL of a 0.2M zinc acetate dihydrate (Zn(CH3COO)2.2H2O) and 40 mL of a 0.4M thiourea (SC(NH2)2). The concentration of the complexing agent Na3-citrate was 0.2 M and the pH was adjusted to 10 by adding 25% ammonia (NH4OH) solution. Finally, a sufficient amount of deionizedwater was added so as to make the total volume of the deposition bath 100 mL. Before deposition, the substrates were ultrasonically cleaned with acetone followed by rinsing in methanol, isopropyl alcohol, and deionized water for 10 min, respectively. The prepared solution was stirred vigorously before dipping the glass substrates. The substrates were mounted on the substrate holder and kept vertically in the reaction bath. The temperature of the reaction bath was then maintained at 950 C. The films were sequentially removed in an interval of 15 min. It is well known that the atomic force microscopy (AFM) is one of the effective ways for the surface analysis due to its high resolution and powerful analysis software The ZnS and ZnS:Ag thin films were morphologically characterized using Atomic Force Microscopy (AFM) technique. Also the surface structure of a coating gains more and more importance. In the extreme case of vthin films the surface roughness may be in the order of the film thickness and can influence all film properties such as mechanical, electrical, magnetical or optical properties. Also film morphology, inner structure, texture and crystallinity are strongly connected to roughness evolution. Generally, the reason for the development of roughness during the deposition process is the finite extension of the film forming particles and their random, temporally and spatially uncorrelated impingement at he growth front. The "building blocks" of the film do not necessarily have to be single atoms as it is the case for PVD coatings. They can also be complex molecules (e. g. for organic coatings) multi-particle aggregates as e. g. for cluster deposition or macroscopic aggregates like the ceramic or metallic droplets in the case of thermal spraying. It can be seen that films are uniform, densely packed and pinhole free, and it shows that the morphology of these films has larger number of grain size and are homogeneously distributed, which indicates the crystalline nature of the film. Initial visual investigations of the deposited film have shown that they are compact and have good adherence to the substrate. No evidence of cracking observed The grains are made of different sizes varying from 74.0-76.0 nm. Based on AFM image, the grain density reduced indicating the smaller grains agglomerate together to form larger grains of ZnS and ZnS:Ag. On the other hand, the surface roughness and Root Mean Square (RMS) of the films were measured using AFM technique. The surface roughness defined as the standard deviation of the surface height profile from the average height is the most commonly reported measurement of surface roughness. The surface roughness is unavoidable since the grains are grown with different sizes.

V.P4.6
16:00
Authors : N. Khemiri, M. Kanzari
Affiliations : Université Tunis ElManar, Ecole National d’Ingénieurs de Tunis, Laboratoire de Photovoltaïque et Matériaux Semi-conducteurs 1002, Tunis, Tunisie.

Resume : Zinc oxysulfide is emerging as one of the most promising materials to replace toxic CdS in the buffer layer of chalcopyrite based thin-film solar cells. Zn(S, O) thin films were grown by three step process: (1) The deposition of Zn layer on glass substrates by vacuum thermal evaporation, (2) The oxidation of the as-deposited Zn layer in air atmosphere and (3) The sulfurization of the oxidised samples in N2 atmosphere. The samples were characterized for their structural, morphological, optical and electrical properties by using X-ray diffraction (XRD), atomic force microscopy (AFM), UV-Vis spectroscopy and hot probe method, respectively. XRD analysis revealed that the films were polycrystalline in nature. The optical constants (band gap energy, absorption coefficient) of the films were determined, in the spectral range 300 - 1800 nm, from the analysis of the transmission and reflection data. The surface morphological studies revealed that the films had an average roughness between 2 and 5 nm. All films exhibited n-type conductivity.

V.P4.7
16:00
Authors : Fredrik Larsson, Jan Keller, Marika Edoff, Tobias Törndahl
Affiliations : Ångström Solar Center, Solid State Electronics, Engineering Sciences, Uppsala University, Box 534, 75121 Uppsala, Sweden

Resume : Understanding how the solar cell device performance is influenced by changing material properties of different layers in the window layer structure of Cu(In,Ga)Se2 (CIGS) solar cells is important when developing new processes or materials. In this work, we study the interaction of intrinsic ZnO layers grown by chemical vapor deposition (CVD) and by magnetron sputtering (PVD), together with two different transparent conducting oxide (TCO) materials, ZnO:Al grown by PVD and atomic layer deposition (ALD) of In2O3. The solar cell device structure in the study is SLG/Mo/CIGS/CdS/i-ZnO/TCO/metal grid. It is found that the thickness of the intrinsic CVD ZnO layer affects the open circuit voltage (Voc) significantly when using the ALD In2O3 TCO. The average Voc drops by 28 mV when the intrinsic ZnO thickness is increased from 20 to 160 nm. This detrimental effect on Voc could not be seen when using a ZnO:Al TCO. In addition, the Voc drop for the CVD i-ZnO/ALD In2O3 structure could not be reproduced by using a PVD grown intrinsic ZnO layer. It has yet to be shown how and when the intrinsic ZnO thickness affects the Voc. However, due to the observed thickness trend, the Voc decrease cannot simply be explained by an i-ZnO/In2O3 interface property. A bulk property of ZnO is therefore likely one part of the explanation.

V.P4.8
16:00
Authors : Johannes Löckinger, Peter Fuchs, Shiro Nishiwaki, Stephan Buecheler, Yaroslav E. Romanyuk, Ayodhya N. Tiwari
Affiliations : Laboratory for Thin Films and Photovoltaics, Empa-Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstr. 129, 8600 Duebendorf, Switzerland

Resume : The development of a novel chemistry for the chemical bath deposition (CBD) of Zn(O,S) buffer layers for Cu(In,Ga)Se2 (CIGS) solar cells aims at a higher growth rate, hence reduced deposition time, while reducing simultaneously the required concentration of reactants. State-of-the-art recipes are based on thiourea as “S2-“ precursor requiring a high molarity of reactants and relatively long deposition times due to the slow decomposition rate of thiourea. In this contribution new sulphide precursors were in-vestigated for their decomposition and growth behaviour. A co-solvent approach in an aqueous am-monia medium was evaluated omitting the need for additional complexants. Homogeneous dense Zn(O,S) layers of around 30 nm were grown with a greatly decreased deposition time of 8 minutes compared to 25 minutes for thiourea. Likewise the concentration of the sulphide precursor was 40-fold reduced. X-ray photoelectron spectroscopy characterization was carried out to investigate the [S]/([S]+[O]) composition showing a more sulphur rich surface as compared to the thiourea process. The photovoltaic performance was characterized by EQE and IV measurements and showed compara-ble efficiencies to the thiourea based process of 15% cells.

V.P4.9
16:00
Authors : S. Ullah, M. Mollar, B. Marí
Affiliations : Institut de Disseny i Fabricació, Universitat Politècnica de València, Camí de Vera s/n 46022-Valencia, Spain

Resume : This paper reports on the synthesis of Cd1-xZnxS thin film buffer layers prepared by chemical bath deposition (CBD) onto indium thin oxide coated glass substrates using aqueous solutions for solar cell photovoltaic application due. Cadmium sulfide, zinc sulfide and thiourea were used as sources of Cd+2, Zn+2, and of S-2, respectively. Triethenolamine was used as complexing agent to control the Cd+2 and Zn+2 ions concentrations and ammonia to adjust the pH 9.8±5 of the solution. The temperature of the bath was kept at 70 °C. The as deposited films are well adherent, homogeneous and free from pinholes. The structure of the films as observed by X-ray diffraction was polycrystalline with hexagonal structure and (100), (101), (102) and (110) as main peaks. Energy dispersive spectroscopy (EDS) shows non-stoichiometric films due to a deficit of sulfur by increasing Zn content. The strong absorption edge shifts towards the lower wavelength region and hence the band gap of the films increases as the Zn content increases. The values of the absorption edge are found to shift towards the shorter wavelengths with Zn content and hence the direct bandgap energy varies from 2.42 eV for the CdS film and 3.50 eV for the ZnS film. Cd1-xZnxS thin films can be useful as buffer and window layers in Cu(In,Ga)Se2 thin films solar cells due to ability to tune the band gap through the Zn/Cd ratio present in the chemical bath.

V.P4.10

Poster 4: Windows, buffers, and other aspects : N. Naghavi, R. Scheer
16:00
Authors : Natalia Maticiuc, Jaan Hiie, Malle Krunks
Affiliations : Laboratory of Thin Film Chemical Technologies, Department of Materials Science, Tallinn University of Technology, Ehitajate tee 5, 19086 Tallinn, Estonia

Resume : CdS is used as a buffer layer in thin film solar cells and it is subjected to thermal treatments during deposition of ZnO window or during CdTe vapor deposition and CdCl2 activation, influencing the performance of the devices. An unambiguous understanding of physico-chemical processes taking place during annealing and resulting in changes of CdS properties is still missing. This paper aims to study systematically the changes in the properties of CBD CdS films during annealing and to describe the physico-chemical mechanism of these changes. Based on IR spectroscopy, energy dispersive X-ray spectroscopy, X-ray diffraction, Hall, Van der Pauw and optical band gap studies, the analysis is given in terms of defect chemistry involving OH groups substituting the sulfur in CdS lattice. Incorporation of cadmium hydroxide in the deposition process causes formation of cadmium hydroxysulfide alloy as a compensated semiconductor with a stressed crystalline lattice. Thermal treatments of CBD CdS films from 200 °C to 450 °C generate destruction of incorporated hydroxide group, creation and out diffusion of excess Cd, and modification of the film electron concentration in the range of 10E16-10E19 cm-3. We have found that during the sputtering of ZnO layers the sheet resistance of underlying CBD CdS film was decreased by three orders corresponding to the electron density of 10E19 cm-3, indicating to the importance of these results for further development of substrate type thin film solar cells.

V.P4.11
16:00
Authors : Richard Menner, Marco Cemernjak, Stefan Paetel, Wiltraud Wischmann
Affiliations : Zentrum für Sonnenenergie- und Wasserstoff-Forschung Baden-Württemberg (ZSW), Industriestrasse 6, D-70565, Germany Phone: +49 711 7870 212, Fax +49 711 7870 230

Resume : Recently, indium-based transparent conductive oxides have become more interesting for application in Cu(In,Ga)Se2 (CIGS) solar cells. Although the fabrication costs may be higher as compared to standard ZnO:Al (ZAO), amorphous indium zinc oxide (InZnO, IZO) films are very attractive due to their high charge carrier mobilities leading to high conductivity. In addition, no need for heating during sputter coating and superior stability against humidity is of advantage. We investigate the deposition of IZO films by RF and DC magnetron sputtering in dependence of sputtering power, total pressure, oxygen admixture, and substrate temperature. The IZO films on glass are analyzed by means of conductivity, spectral transmission, and Hall measurements as well as X-ray diffraction and scanning electron microscopy. Specific resistivity below 350 µOhmcm is obtained for 0.4 µm films, half that of ZAO. Best mobilities of about 50 cm²/Vsec are achieved for highly transparent films (average absorption (400 to 1100 nm) < 4 %). The suitability of IZO as a window layer for CIGS solar cells is demonstrated with efficiencies as high as 18.5 % (with anti-reflective coating) comparable to the ZAO reference. Results for stability tests of IZO-coated CIGS modules in damp heat will be discussed.

V.P4.12
16:00
Authors : Ho Young Jun, Si Ok Ryu*
Affiliations : School of Chemical Engineering, Yeungnam University, 280 Daehak-ro, Gyeongsan 712-749, South Korea

Resume : CdS thin films are used as a buffer layer in the hetero-junction structured CIGS thin film solar cells. However, because Cd is a toxic material, the needs for its alternative materials have been discussed to avoid the environmental issues. ZnS is considered as a prominent substitute material to replace Cd. It was reported that some amount of ZnO and Zn(OH)2 as the impurities, which are denoted as Zn(O,S), are required to be present in ZnS for fabricating the efficient CIGS solar cells. In this study, Zn(O,S) films were synthesized by a solution-based deposition method designed by a combination of a continuous flow reactor (CFR) with another method. Their structural and physicochemical properties were characterized by XRD, SEM and UV-vis spectroscopy. It was confirmed that the CFR process was very effective method to deposit Zn(O,S) thin films. Based on our result, Zn(O,S) thin films were successfully deposited in a very short period of time using the combined CFR process. Cd-free B:ZnO/Zn(O,S)/CIGS solar cells were also fabricated on Mo coated glass substrates in order to investigate the influences of the experimental parameters such as deposition time and deposition method on the performance of Zn(O,S) buffer layer in the devices. Photovoltaic performance was measured under AM. 1.5G illumination. The fabricated CIGS solar cell yielded an efficiency of 9.64%. It is expected that a higher efficiency can be obtained when our experimental conditions are optimized.

V.P4.13
16:00
Authors : P.M.P Salomé1, J.P. Teixeira2 J. Keller3, T. Törndahl3, N. Nicoara1, R-Ribeiro Andrade1,4, D. G. Stroppa1 J. C. Gonzalez4, M. Edoff3, J.P. Leitão2, S. Sadewasser1
Affiliations : 1 International Iberian Nanotechnology Laboratory, 4715-330 Braga, Portugal 2 Departamento de Física and I3N, Universidade de Aveiro, Aveiro, Portugal 3 Ångström Laboratory, Solid State Electronics, Ångström Solar Center, Uppsala University, SE-751 21 Uppsala, Sweden 4 Departamento de Física, Instituto de Ciências Exatas, Universidade Federal de Minas Gerais, Caixa Postal 702, 30123-970 Belo Horizonte, MG, Brasil

Resume : Thin film solar cells based on Cu(In,Ga)Se2 (CIGS), where just the buffer layer is changed, were fabricated and studied. The effects of two buffer layers are compared, CdS and ZnxSn1-xOy (ZnSnO), using several characterization techniques. The general trend from the literature where CdS-based solar cells show higher values of open circuit voltage (Voc) and fill factor (FF) compared with Cd-free buffer layers is confirmed in this work. Kelvin probe force microscopy (KPFM) results indicate that CdS provides junctions with slightly higher surface photovoltage (SPV) than ZnSnO. The higher SPV value of CdS is reflected in the higher Voc values of resulting devices when compared with ZnSnO. Contrasting the higher SPV and Voc values of the CIGS/CdS devices, the CIGS/CdS interface exhibits more defects as concluded by photoluminescence (PL) results and in accordance with C-V measurements. Our results indicate that the CIGS/CdS interface still has a vast potential to be improved and that future studies of ZnSnO buffer layers should focus on understanding its limitations in SPV and Voc.

V.P4.14
16:00
Authors : Y. Sanchez (1), M. Espíndola-Rodríguez (1), H. Xie (1) , S. Giraldo (1), S. López-Marino (1), I. Becerril-Romeo (1), V. Izquierdo-Roca (1), O. Vigil-Galán (2), E. Saucedo (1)
Affiliations : (1) IREC, Catalonia Institute for Energy Research, Jardins de les Dones de Negre 1, 2ª, 08930 Sant Adrià del Besòs, Spain; (2) Escuela Superior de Física y Matemáticas-Instituto Politécnico Nacional (IPN), México DF, México

Resume : The development of non-toxic and sustainable materials and devices is of paramount importance for the future deployment of solar energy. In this frame, kesterites are at the forefront of sustainable photovoltaic technologies due to the abundance of its constituent elements and the relatively low environmental impact of the associated processes. Nevertheless, kesterite devices (and almost all the thin film photovoltaic technologies), rely in the use of CdS as “universal” buffer layer, requiring for a medium-long-term Cd-free substitute in order to ensure the sustainability of the technology. In this work we present a comparative study of chemical bath deposited ZnS and In2S3 as buffer layers for Cu2ZnSnSe4 (CZTSe) based solar cells. A complete analysis of the impact of bath composition (mainly [M]/Tiourea, being [M] the concentration of Zn or In), bath temperature (60-80 ºC) and growth time will be presented. The Cd-free buffer layers were characterized regarding their optical (transmittance and photoluminescence), structural (Raman spectroscopy and XRD) and morphological (SEM and AFM) properties, as well as implemented in CZTSe based devices. We will show the high potential of these buffer layers reporting a CZTSe/In2S3 device with 4.5% efficiency (VOC = 460 mV, JSC = 23.9 mA/cm2), FF = 41%) and CZTSe/ZnS with 5.2% efficiency (VOC = 366 mV, JSC = 27 mA/cm2), FF = 53%), and we will discuss the challenges of these buffer layers to become a real alternative to CdS.

V.P4.15
16:00
Authors : Johannes Schoneberg, Jörg Ohland, Michael Richter, Patrick Eraerds, Thomas Dalibor, Jürgen Parisi
Affiliations : Laboratory for Chalcogenide Photovoltaics, Energy and Semiconductor Research Laboratory, Department of Physics, University of Oldenburg, 26111 Oldenburg, Germany; Laboratory for Chalcogenide Photovoltaics, Energy and Semiconductor Research Laboratory, Department of Physics, University of Oldenburg, 26111 Oldenburg, Germany; Laboratory for Chalcogenide Photovoltaics, Energy and Semiconductor Research Laboratory, Department of Physics, University of Oldenburg, 26111 Oldenburg, Germany; AVANCIS GmbH, Otto-Hahn-Ring 6, 81739 Munich, Germany; AVANCIS GmbH, Otto-Hahn-Ring 6, 81739 Munich, Germany; AVANCIS GmbH, Otto-Hahn-Ring 6, 81739 Munich, Germany; Laboratory for Chalcogenide Photovoltaics, Energy and Semiconductor Research Laboratory, Department of Physics, University of Oldenburg, 26111 Oldenburg, Germany;

Resume : Replacing the toxic CdS buffer material in thin-film solar cells based on Cu(In,Ga)(Se,S)2 (CIGSSe) has been a crucial issue for a long time. A promising alternative buffer material is InxSy which stands out due to its tuneable characteristics, e.g., the band-gap or the electron-affinity by adding third elements. The specific influence of additional elements has been subject of many publications, however, with inconsistent results e.g. concerning the nature of the band-gap or the conductivity. The experimental access to the optical and electrical parameters of InxSy thin-films is a necessity to fully understand the formation of the solar-cells hetero-junction. For this work, CIGSSe solar-cells with a varied sodium-concentration in the InxSy:Na-buffer-layer and comparable single InxSy:Na-layers on sodium-free glass substrates were investigated. The solar-cells were characterized by means of current-voltage-measurements (IV), whereas spectroscopic-ellipsometry (SE) and conductivity-measurements were performed on bare InxSy:Na- layers. The IV-measurements indicate a formation of a transport-barrier with increasing sodium content which is in agreement with a decrease in electron affinity reported in the literature. The SE analysis shows band-gap values of Eg=2.1 eV for sodium-free thin-film InxSy and Eg=2.33 eV for the layers with the highest sodium content. The absorption coefficient shows a clear indirect nature of the band-gap transition. The conductivity under illumination is in the range of σ=10^(-6)(1/Ωm) and shows a strong decrease in the dark. The conductivity shows no significant trend with increasing sodium-concentration.

V.P4.16
16:00
Authors : S. Ouédraogo1234, M.B. Kébré1, D. Oubda2, F. Zougmoré1, Z. Koalaga1, J.M. Ndjaka2 and M. Maaza4
Affiliations : 1 Laboratoire des Matériaux et Environnement (LA.M.E), UFR-SEA, Université de Ouagadougou, 03 B.P. 7021 Ouaga 03, Ouagadougou, Burkina Faso. 2 Département de Physique, Faculté des Sciences, Université de Yaoundé I, B.P. 812, Yaoundé, Cameroon. 3 UNESCO-UNISA Africa Chair in Nanosciences/Nanotechnology, College of Graduate Studies, University of South Africa (UNISA), Muckleneuk ridge, PO Box 392, Pretoria, South Africa. 4 Nanosciences African Network (NANOAFNET), iThemba LABS-National Research Foundation, Old Faure road, 7129 Somerset West, South Africa.

Resume : In this paper, device modeling and simulation were conducted to investigate the effect of Magnesium and Gallium content on Zn1-yMgyO/CuIn1-xGaxSe2 heterojunction solar cells. The performance of the solar cells by varying the Magnesium and Gallium content, are studied and the correlation between these parameters and the way they affect the metastable behavior of the solar cells cell is proposed. The resulting performance parameters of open-circuit voltage (Voc), short-circuit density (Jsc), fill factor (FF) and efficiency (ƞ) are determined using current density-voltage (J-V) characteristics. The obtained results show that the best solar cells with the Zn(Mg,O) buffer layer can be achieved when Mg content in the buffer layer is approximately 0.15-0.2. In comparison to the conventional CdS buffer layer, the best solar cells with the Zn(Mg,O) buffer layer has lower Voc, FF but higher Jsc which result in slightly lower conversion efficiency. The simulation results suggest that the high defect density in the Zn(Mg,O) buffer layer may be the cause of poor performances of Zn(Mg,O)/CIGS solar cells. A comparison of the simulation re-sults with published data for the CIGS cells with the Zn(Mg,O) buffer layer shows an excellent agreement.

V.P4.17
16:00
Authors : Lan Wang, Alexander Steigert, Iver Lauermann, and Reiner Klenk
Affiliations : Helmholtz-Zentrum Berlin für Materialien und Energie, D-14109 Berlin, Germany

Resume : We designed a precursor ink based process for the fabrication of indium sulfide (In2S3) thin films, as a buffer layer in CIGSe thin film solar cells. Inkjet printing has been successfully utilized to deposit the ink. A working In2S3 buffer was obtained after drying the film in air and annealing it in flowing Ar or Ar/H2S. Solar cells with the buffer produced by our process demonstrated performance comparable to that of standard CdS-buffered cells. As a drop-on-demand technique, inkjet printing has advantages in terms of material usage and generation of waste. The whole process is also vacuum-free and the combination of these specific properties promises low cost in industrial production. In addition, inkjet printing enables highly localized deposition of materials, which is attractive for implementing advanced device concepts, such as micro-concentrator solar cells. X-ray photoelectron spectroscopy (XPS) has been used for a first assessment of substrate coverage, interdiffusion, contaminations, and reaction mechanisms. The spectra indicate the presence of In, S, Se, Cu, O, N, and C. The transformation of the film during the annealing step is deduced from a strong decline in the O and N concentrations. The origin of the remaining N contamination (In salt or S source) has been studied by comparing films prepared from inks with different thiourea concentrations. Cu and Se signals indicate incomplete coverage and/or interdiffusion between absorber and buffer. Both are crucial for optimum performance of In2S3 buffer layers and could be assessed separately by taking into account the Cu/Se ratio.

V.P4.18
16:00
Authors : Himeka Tominag1, Masamito Imai1, Marin Watanabe1, Akiko Mochihara1, Akiko Ide1, Kenji Yoshino1, Shigeru Ikeda2, Takashi Minemoto2
Affiliations : 1Department of Applied Physics and Electronic Engineering, University of Miyazaki, 1-1 Gakuen Kibanadai-nishi, 889-2192 Miyazaki, Japan 2Research Center for Solar Energy Chemistry, Osaka University, 1-1 Yamadaoka Suita Osaka, 565-0871, Japan 3Department of Electrical and Electronic Engineering, Ritsumeikan University, 1-1-1 Nojihigashi Kusatsu Shiga 525-8577, Japan

Resume : Low cost processes are very important problem for solar cell devices. The spray method is one of non-vacuum processes and is respected as low cost method. In our previous works, high quality transparency ZnO films were successfully grown at 100 °C by a conventional atmospheric spray pyrolysis using diethylzinc (DEZ) based solution [1]. The DEZ was diluted with diisopropyl ether to control its reactivity to air and water (supplied by Tosoh Finechem Corporation, JAPAN). Moreover, the growth of Ga-doped ZnO (GZO) /glass films was carried out by spray pyrolysis at 150 °C [2]. The samples had an average optical transmittance of more than 80% and were strongly a-axis orientated. The sheet resistivity of 30 /sq. could be obtained. In this work, the GZO films were successfully grown on ZnO/CdS/CIGS/Mo/glass by spray pyrolysis using DEZ based solution. After covering clean SLG substrates with back electrodes of Mo films by sputtering, CIGS films were deposited using physical vapor deposition. Buffer layers of CdS films were prepared by chemical vapor deposition. Buffer layers of ZnO films (≈ 20 nm) were also prepared by RF sputtering method [3]. The efficiency of the obtained device was 10.3%. The short-circuit current density (Jsc) of 34.3 mA/cm2, open circuit voltage (Voc) of 0.50 V and fill factor (FF) of 0.60 are obtained. [1] K. Yoshino, Y. Takemoto, M. Oshima, K. Toyota, K. Inaba, K. Haga, and K. Tokudome, Jpn. J. Appl. Phys. 50, 040207 (2011). [2] Y. Takemoto, M. Oshima, K. Yoshino, K. Toyota, K. Inaba, K. Haga, and K. Tokudome, 50, 08801 (2011). [3] T. Minemoto, Y. Hashimoto, W. S.-Kolahi, T. Satoh, T. Negami, H. Takakura, Y. Hamakawa Solar Energy and Solar Cell Materials, 75, 121 (2003).

V.P4.19
16:00
Authors : Corentin Berthier1,2,6, Alexandre Jaffré3,6, Arouna Darga4,6, José Alvarez3,6, Romain Bodeux1,2,6, Alain Lafond5,6.
Affiliations : 1EDF, 6 quai Watier, 78400 CHATOU, France; 2IRDEP, UMR 7174 (EDF, CNRS, Chimie Paris Tech) 6, quai Watier – BP 49 78401 CHATOU Cedex, France; 3GeePs, CNRS UMR 8507,CentraleSupélec, Univ Paris-Sud ; Sorbonne Universités-UPMC Univ Paris 06, 11 rue Joliot-Curie, Plateau de Moulon, F-91192 Gif-sur-Yvette Cedex, France; 4Sorbonne Universités, UPMC Univ Paris 06, UMR 8507, Laboratoire Génie Electrique et Electronique de Paris, F-91190 Gif sur Yvette, France; 5Institut des matériaux Jean Rouxel, 2, rue de la Houssinière 44322 NANTES Cedex 3, France; 6Institut Photovoltaïque Ile de France (IPVF), 8 rue de la Renaissance 92160 Antony, France;

Resume : The main characteristic of Cu2ZnSnS4 (CZTS) base solar cells is the presence of secondary phases which may introduce a local compositional and structural inhomogeneity. Among of the various secondary phases generally observed in CZTS material, one of the most limiting is the ZnS phase. In this work, in order to probe ZnS phase and quantify inhomogeneity in CZTS thin film material, we use, on one hand, spatially resolved Raman and PL spectroscopy measurements at different wavelength, and on other hand, three kinds of samples: CZTS crystal with controlled phase purity, CZTS crystal with controlled phase purity and intentional localized ZnS phases inclusions, and thin film CZTS fabricated by sputtering method. By comparing the spatially resolved micro-Raman spectra of thin film CZTS to that of controlled phase purity CZTS crystal, we are able to identify the main Raman pics of thin film CZTS and to quantify its distribution within an area of 50x50 um. Additionally, micro-PL cartography at multiple wavelength gives information on layer quality and secondary phases localization. Hence, the effects of ZnS phases in the structure of CZTS thin film are also successfully identify by comparing different excitations wavelengths (325, 532, 640, 784nm) Raman spectra of CZTS crystals with localized ZnS inclusions to that of thin film CZTS. These results, will be compared to those determined by others groups, as a lot of work has been done on CZTS secondary phases identification, and we will discuss the possible correlation with photovoltaic cells response parameters.

V.P4.20
16:00
Authors : Sofia Gaiaschi, Anaïs Loubat, Simon Richard, Muriel Bouttemy, David Alamarguy, Patrick Chapon, Arnaud Etcheberry
Affiliations : Horiba Scientific, 16-18 rue du canal 91165 Longjumeau France; Lavoisier Institute of Versailles (ILV), UMR 8180 CNRS-UVSQ, IPVF, 45 avenue des Etats Unis, 78035 Versailles, France; Horiba Scientific, 16-18 rue du canal 91165 Longjumeau France; Lavoisier Institute of Versailles (ILV), UMR 8180 CNRS-UVSQ, IPVF, 45 avenue des Etats Unis, 78035 Versailles, France; GeePs | Group of electrical engineering – Paris UMR CNRS 8507, CentraleSupelec, Univ Paris-Sud, Sorbonne Universités, UPMC Univ Paris 06 11 rue Joliot Curie, Plateau de Moulon F91192 Gif sur Yvette CEDEX; Horiba Scientific, 16-18 rue du canal 91165 Longjumeau France; Lavoisier Institute of Versailles (ILV), UMR 8180 CNRS-UVSQ, IPVF, 45 avenue des Etats Unis, 78035 Versailles, France;

Resume : The growth of the photovoltaic technology relies on the improvement of existing materials and manufacturing technologies, as well as on the development of new ones. In the case of CIGS solar cells the chemical engineering of the absorber layer remains a permanent challenge. The variation of composition, the diffusion of impurities and the nature of the interfaces are three critical points that influence the performance of these devices. Multiple characterization techniques are applied. Among them, Radio Frequency Glow Discharge Optical Emission Spectrometry (GDOES) is used for fast elemental depth profile. The technique relies on the very fast sputtering (typically µm/min) of a representative area of the sample by a high density and low energy RF plasma. An excellent depth resolution can be obtained, depending on the surface roughness. The most recent advance in GDOES is the real time measurement of the depth of the sputtered crater thanks to the addition of a Differential Interferometry Profiling (DiP) module within the GD source. It gives a direct access to layers thickness and erosion rates. In this work the characterization by GDOES and DiP of chemically etched CIGS samples was performed for the first time. These materials are challenging for DIP as they are possibly rough and partially transparent. Different surface roughness levels were investigated, corresponding to different etching times, and their impact on the layer thickness determination with DiP was evaluated.

V.P4.21
16:00
Authors : Tzu-Ying Lin Chia-Hsiang Chen Chih-Huang Lai
Affiliations : Department of Materials Science and Engineering, National Tsing Hua University, Hsinchu 30013, Taiwan

Resume : To further characterize the composition distribution, a promising nondestructive analysis of field-emission electron probe microanalysis (FE-EPMA) was proposed to probe the compositional distribution within Cu(InxGa1-x)Se2 absorbers. FE-EPMA obtained the high S/N ratio and collaborated with high detector resolution (10 eV) resulting in 10 ppm in detection limit; additionally, advanced field emission gun achieved much tinier probe size about 10 nm, and by well controlling the accelerating voltage of electron beam, the escape depth could be lower to sub-micron meter level. FE-EPMA shows the excellent ability for detecting the fine distinction of Se, trace elements, and provides the direct evidence for uniformity issue. Using field-emission electron probe microanalysis (FE-EPMA), electrometry (IV, EQE, C-AFM), and photometry (PL) we investigate the relationship between the Se concentration environment and the corresponding spatial distribution of films. We show that the deficient Se environment gives rise to its non-uniform spatial distribution, resulting in poorer grain boundary quality and enhancing deep defects recombination. By improving the uniformity of Se, the efficiency is leading to the increase about 5%. Our results suggest that not only the Se quantity but also the spatial distribution limits the CIGS cell performance.

V.P4.22
16:00
Authors : Charlène Crevant1,4, Anne-Laure Joudrier2,4, Myriam Paire1,4, Jean-François Guillemoles3,4, Thomas Fix5, Abdelilah Slaoui5, Anatolie Gavriluta4,5
Affiliations : 1 EDF R&D, Institute of research and development for photovoltaic energy, 6 quai Watier, 78401 Chatou, France; 2 Chimie ParisTech, Institute of research and development for photovoltaic energy, 6 quai Watier, 78401 Chatou, France; 3 NextPV, LIA CNRS-RCAST/U, 4-6-1 Komaba, Meguro-ku, Tokyo 153-8904, Japan; 4 IPVF, Institut Photovoltaïque d’Ile-de-France, 8 rue de la Renaissance 92160 Antony, France; 5 ICube, CNRS - Université de Strasbourg, 23 rue du Loess 67037 Strasbourg, France.

Resume : Luminescent downshifting layer (LDL) has a real interest to improve the performances of a solar cell. LDL allows to convert photons from UV to visible range, increasing the photon fraction absorbed by the solar cell. The LDL is constituted of a polymeric matrix doped with fluorophores. We propose a review of different categories of fluorophores (organic dyes, inorganic dyes, quantum dots, etc…). Figures of merit such as Absorption range, emission range, photoluminescence quantum yield (PLQY), the emission overlap, and the emission spectral matching integral were calculated for each fluorophores. The final aim is to find the good combination between fluorophores, matrix and solar cell. Starting from figures of merit we identify, for example, the following materials: Lumogens (BASF) with the Lumogen red305 as reference, quantum dots CdSe/ZnS with different absorption/emission ranges and homemade rare-earth complex. The Lumogen family has a high PLQY (>90%), more precisely our reference Lumogen red 305 has a PLQY of 96%. For the quantum dots family, we retained CdSe/ZnS for two reasons: the large absorption (max at 376nm) and emission (max at 623nm) range and the large Stokes shift. Optical properties of the matrix (transmission, reflexion) w/o fluorescent materials (absorption and emission range, photoluminescent quantum yield) were studied. Experimental work of CIGS cell and LDL, to quantify the downshifting efficiency will be presented.

V.P4.23
16:00
Authors : Anatolie Gavriluta;1,2,3 Thomas Fix,2 Aline Nonat;3 Myriam Paire;4,1 Abdelilah Slaoui;2 Loïc J. Charbonnière;3 Jean-François Guillemoles 5,1
Affiliations : 1 Institut Photovoltaïque d'Ile de France (IPVF), 8 rue de la Renaissance, 92160 Antony, France 2 ICube Laboratory, Université de Strasbourg and CNRS, 23 rue du Loess BP 20 CR, 67037 Strasbourg Cedex 2, France 3 LIMAA, IPHC, UMR 7178 CNRS, Université de Strasbourg, ECPM, 25 rue Becquerel, 67087 Strasbourg Cedex, France 4 EDF R&D, IRDEP, Institute of R&D on Photovoltaic Energy, UMR 7174, CNRS-EDF-Chimie ParisTech, 6 Quai Watier-BP 49, 78401 Chatou Cedex, France 5 NextPV, The University of Tokyo, Komaba campus, LIA CNRS-RCAST-U. Bordeaux, Tokyo Japan

Resume : Today, the world solar photovoltaic modules market is dominated by PV cells based on silicon and thin films, including CdTe and CIGS cells. Yet, their conversion performances are limited by the so-called spectral mismatch between solar cells and the solar spectrum. For instance, the spectral response of CIGS cells has maximum external quantum efficiency (EQE) in the region 550-900 nm and its efficiency is dramatically decreased between 500 and 300 nm, where the total sun illumination power is around 19 %. One solution to this issue is to use downshifting materials based on Eu(III) complexes to convert UV light into red light. Their major advantages are very limited reabsorption and large Stokes? shifts. The goal of this work is to increase the photon conversion efficiency of CIGS cells in the region 280-500 nm by implementing encapsulating polymers containing highly luminescent europium complexes. Herein, we will present a complete study on the influence of the [Eu(TTA)3(TTPO)2] complex concentration and thickness of the ethylene-vinyl acetate (EVA) copolymer to increase the conversion efficiency of CIGS cells. We have demonstrated an improvement of the EQE at 350 nm by 30 % absolute. We pointed out that the highest concentration of [Eu(TTA)3(TTPO)2] in EVA obtained from spectral response does not automatically result in the best conversion efficiency. Finally, the best cells exhibit an increase of the conversion efficiency of CIGS cells by 0.8% absolute.

V.P4.24
16:00
Authors : Shafi Ullah, Miguel Mollar, Bernabé Marí
Affiliations : Department de Física Aplicada-IDF, Universitat Politècnica de València, Camí de Vera s/n, 46022-València, Spain.

Resume : CuGaSe2 and CuGaS2 polycrystalline thin films absorbers have been prepared by one-step electrodeposition from an aqueous electrolyte containing CuCl2, GaCl3, and H2SeO3. The pH of the solution was adjusted to 2.3 by adding HCl and LiCl. Annealing improves crystallinity of CuGaSe2 and further annealing in sulphur atmosphere is required to obtain CuGaS2 layers. The morphology, topography, chemical composition and crystal structure of the deposited thin films were analysed by Scanning Electron Microscopy, Atomic Force Microscopy, Energy Dispersive X-Ray spectroscopy and X-Ray Diffraction, respectively. The X-Ray diffraction shows that the as-deposited CuGaSe2 film exhibits poor crystallinity, but it improves dramatically when the layers are annealed in forming gas atmosphere for 40 min. Subsequent sulfurization of CuGaSe2 films was performed at 400 °C for 10 min in presence of molecular sulphur and under forming gas atmosphere. The effect of sulfurization is the conversion of CuGaSe2 into CuGaS2. The formation of CuGaS2 thin films is evidenced by the shift observed in X-Ray diffraction pattern and by the blue shift of the optical band gap. The bandgap of CuGaSe2 was found to be 1.66 eV while for CuGaS2 it raises up to 2.2 eV. A broad intermediate absorption band associated to Cr and centred at 1.63 eV was observed in Cr-doped CuGaS2 films.

V.P4.25
16:00
Authors : Julien Marquardt, Alexandra Franz, Christiane Stephan, Susan Schorr
Affiliations : Helmholtz-Zentrum Berlin für Materialien und Energie, Freie Universität Berlin Institut für Geologische Wissenschaften; Helmholtz-Zentrum Berlin für Materialien und Energie; Freie Universität Berlin Institut für Geologische Wissenschaften, Bundesanstalt für Materialforschung und -prüfung (BAM); Helmholtz-Zentrum Berlin für Materialien und Energie, Freie Universität Berlin Institut für Geologische Wissenschaften;

Resume : By now, the progress in CIGSSe based thin film solar cells led to conversion efficiencies of more than 22% [1]. By establishing an intermediate band within the energy gap of a wide gap semiconductor, theoretical predictions state the possibility to increase the utilization of solar energy [2]. With such an intermediate band gap it is proposed, that the efficiency can be raised up to 63.3% [3]. In the presented study CuGaS2, which has the widest band gap in the solid solution series of CIGSSe, is used as basis to establish an intermediate band by the incorporation of transition metals. Martì et al. [4] proposed different transition elements, such as Ti4+/3+ and Fe3+/2+. In this study we focused on incorporating Cr instead of Ti into the crystal structure of CuGaS2, because of better solubility proposed from thermodynamic calculations as well as Mn as analogue [5]. Aiming in a systematic study to determine the solubility limits of these cations in CuGaS2, powder samples have been prepared by solid state reaction of the elements (900°C) in evacuated silica tubes. The synthesized materials were analyzed in terms of chemical composition and phase content using WDX spectroscopy as well as in terms of crystal structure by X-ray and neutron diffraction. The presentation will summarize structural trends of lattice parameters, tetragonal distortion and tetragonal deformation in dependence on the Mn/Cr content. Moreover the solubility limits of Mn/Cr in CuGaS2 are discussed.

V.P4.26
16:00
Authors : E. Simsek Sanli1, H. Stange2, W. Sigle1, Q.M. Ramasse3, D. Abou-Ras4, R. Mainz4, H.-J. Kleebe5, P.A. van Aken1
Affiliations : 1 Max Planck Institute for Solid State Research, Stuttgart Center for Electron Microscopy, Heisenbergstr. 1, 70569 Stuttgart, Germany; 2 Institut für Werkstoffwissenschaften, Technische Universität Berlin, Ernst-Reuter-Platz 1, 10587 Berlin, Germany; 3 SuperSTEM Laboratory, SciTech Daresbury Campus, Keckwick Lane, Daresbury, WA4 4AD, United Kingdom; 4 Helmholtz Zentrum Berlin für Materialien und Energie GmbH, Hahn-Meitner-Platz 1, 14109 Berlin, Germany; 5 Technische Universität Darmstadt, Institut für Angewandte Geowissenschaften, Germany

Resume : Na incorporation in Cu(In,Ga)Se2 thin film solar cells improves photovoltaic properties. However, it remains an open question why –especially at low growth temperatures– the beneficial effect is stronger when Na is added after the layer growth. To examine a possible influence of Na, CuInSe2 thin-films deposited at low substrate temperatures (below 400°C) by multi-stage coevaporation were analyzed in this study. A 12 nm NaF precursor layer on the molybdenum back contact acted as alkali metal source during the growth of the samples. The effect of Na on the structural defects in the absorber layer is characterized via high-resolution scanning transmission electron microscopy (HR-STEM) in combination with electron energy-loss spectroscopy (EELS) for two samples from processes interrupted during Cu-Se deposition at Cu-poor and Cu-rich compositions. The defect concentration in the samples was analyzed via STEM low-angle annular dark-field imaging. Although most of the defects were expected to have been annihilated for the sample with Cu-rich composition, both samples showed high concentrations of planar defects. We observed stoichiometric elemental distribution at twin boundaries and at stacking faults, however, elemental redistribution was found at lower-symmetry grain boundaries (GB). We also found evidence of CuPt ordered CIS phase within the grains and around GBs.

V.P4.27
16:00
Authors : P. Tsoulka, I. Braems, N. Barreau, S. Harel, L. Arzel
Affiliations : IMN, UMR 6502, Université de Nantes, 2 rue de la Houssinière, 44322 Nantes Cedex 3, France

Resume : Polycrystalline CuIn1-xGaxSe2 thin films solar cells present a high conversion efficiency (h≈22 %) for x*≈0.4 while theoretical predictions indicate better performance for larger x. Recent results obtained by Atom Probe Tomography [1] on CIGSe layers on soda-lime substrate strongly suggest that below x*, Grain Boundaries (GBs) are In-enriched compared to the bulk while Cu-enriched GBs are more frequent for larger x. The chemical difference of GB-segregating species below and above x* may explain the unexpected limited performance described hereabove. Hence to understand this two-regime segregation a part of the puzzle is to carefully analyze the coupling between the structure and the chemistry of the GBs. On one hand, our study aims at assessing the role of Na onto the GB structure by alternative techniques (EBSD, XRD). On the other hand, we perform atomic-scale computations to refine the state-of-the-art knowledge of CIGSe bulk phase diagram [2]. This may give insights on the segregation driving forces at GBs in CIGSe. [1] M. Raghuwanshi, E. Cadel, P. Pareige, S. Duguay, F. Couzinie-Devy, L. Arzel, N. Barreau, Applied Physics Letters 105, 013902 (2014) [2] H. T. Xue, W. J. Lu, F. L. Tang, X. K. Li, Y. Zhang, Y. D. Feng, Journal of Applied Physics 116, 053512 (2014)

V.P4.28
16:00
Authors : Jean-Charles Jacob, Edouard Léonard, Ludovic Arzel, Linda Cattin, Nicolas Barreau
Affiliations : Institut des Matériaux Jean Rouxel (IMN) - UMR 6502, Université de Nantes, CNRS, 2 rue de la Houssinière, BP32229, 44322 Nantes cedex 3, France

Resume : The fabrication of semitransparent thin film solar cell based on Cu(In,Ga)Se2 needs a substitution of molybdenum as back contact. The structure is the stack Glass/ZnO:Al/CIGSe/CdS/ZnO/ZnO:Al. The work involves optimizing the optical and electrical properties of the back contact made of ZnO:Al, deposited by RF-sputtering. Moreover, the thin film of CIGSe needs to have a high gallium rate at the CIGSe/ZnO:Al interface, so an unusual deposition process is used, referenced to as CURO process. This structure permits to obtain cells with a 12% power conversion efficiency with a 700 nm thin absorber and a 50% transmission beyond the semiconductor band gap. First results are promising and show the suitability of the choice of ZnO:Al as an alternative to molybdenum as back contact. Then, some alternative back contact will be investigated and tandem solar cell with CIGSe and crystalline silicon will be realized. Key word: semitransparent solar cell, tandem solar cell, thin film, Cu(In,Ga)Se2, ZnO:Al, CURO process, alternative back contact.

V.P4.29
16:00
Authors : E. Jarzembowski, B. Fuhrmann, R. Scheer
Affiliations : Institute of Physics, Martin-Luther-Universität Halle-Wittenberg, Von-Danckelmann-Platz 3, 06120 Halle, Germany, roland.scheer@physik.uni-halle.de

Resume : Thickness reduction of CIGSe films is a subject of economic importance. The problems so far are non-sufficient light absorption by single or double light pass, pin holes, and carrier recombination. From silicon technology, the concept of point contact solar cells is known which, in combination with a back contact reflector, allows collecting long wavelength photons. Using a model system of 190 nm thick CIGSe films, we follow this approach and prepare a SiO2 back side film with periodic openings to the molybdenum layer being the electrical contact. The openings are plasma etched through a mask prepared by laser interference lithography. We find a maximum increase of the short circuit current density of 25% for a SiO2 thickness of 60 nm and structure length of 1.1 µm. This gain is mainly due to (1) a roughness increase of the CIGSe layer due to the back contact height profile which enhances the quantum efficiency at all wavelengths and (2) an anticipated wave guide effect which boosts the quantum efficiency particularly at long wavelength. Interestingly, due to the absorber growth process not all structure lengths lead to a roughness increase: The CIGSe film tends to smooth out the back contact height profile for too small structure length. The best efficient solar cells with 190 nm thick CIGSe has a conversion efficiency of 9% (FF=70%) without anti-reflection coating. These experimental results can largely be represented by simulation. The success of ongoing optimisation will be reported in the paper.

V.P4.30
16:00
Authors : J. Posada - 1, M. Jubault - 2, N. Naghavi - 1
Affiliations : 1 - CNRS, Institut of Research and Development on Photovoltaic Energy (IRDEP) - 6 Quai Watier, 78401 Chatou, France ; 2 - EDF - R&D, Institut of Research and Development on Photovoltaic Energy (IRDEP) - 6 Quai Watier, 78401 Chatou, France

Resume : Thin film solar cells based on chalcopyrite Cu(In,Ga)Se2 (CIGS) exhibit efficiencies up to 22 % with an absorber layer thickness of 2-3 µm. In order to overcome the bottleneck of the limited primary resources such as indium and gallium, one of the solution is to synthesize the CIGS absorber with a thickness lower than 500 nm. In this work, we have developed a hybrid one-step co-sputtering/evaporation ultra-thin CIGS deposition process, where Cu, In and Ga are sputtered simultaneously with the thermal evaporation of selenium, thus avoiding H2Se use. To meet this goal, studies have been conducted to ensure control of the multiple deposition parameters. Ultra-thin CIGS absorbers down to 500 nm were synthesized with a stabilized hybrid process. These absorbers were deposited in one and three stages to analyze the influence of composition gradients on their morphological, structural and optoelectronic properties. The film composition and thickness of the samples were measured by XRF, EDX and GD-OES. The different phases formed during the process were identified by Raman spectroscopy and XRD. The impact of the deposition conditions on nucleation step and morphology of the absorbers were studied by SEM. The optoelectronic properties analysis of each sample was also performed by I(V) measurement under illumination and dark conditions and by spectral response. CIGS solar cells with conversion efficiencies up to 5 % were fabricated with an absorber layer thickness of 300 nm.

V.P4.31
Start atSubject View AllNum.Add

Buffers and windows : A. Loubat, C. Schnohr
08:30
Authors : Homare Hiroi(*1,2, Yasuaki Iwata(1, Hiroki Sugimoto(1 and Akira Yamada(2
Affiliations : 1) Technology Development Division, Atsugi Research Center, Solar Frontier K.K. 2) Department of Physical Electronics, Tokyo Institute of Technology

Resume : A conversion efficiency of 15.5% on a pure-sulfide Cu(In,Ga)S2 solar cell with a Cd-free buffer layer was achieved. This is a big progress of pure-sulfide Cu(In,Ga)S2 cells whose conversion efficiency have not been improved since 2009. Our pure-sulfide Cu(In,Ga)S2 cells were fabricated by combing Cu-poor absorbers and Zn-based buffer layers. Current breakthrough to exceed the limit of 15% efficiency was brought by optimizing the Zn-based buffer layer. In this paper, we will review our recent progresses of our pure-sulfide Cu(In,Ga)S2 cells, especially in the impact of buffer layers for the pure-sulfide Cu(In,Ga)S2 cells. We keep exploring the potential of pure-sulfide Cu(In,Ga)S2 cells, and the latest results will be shown at the conference.

V.X.1
09:00
Authors : (1) N. Barreau, A. Frelon, T. Lepetit, C. Latouche, S. Harel, L. Arzel, L. Choubrac, C. Laurencic, S. Jobic (2) M. Moret, O. Briot
Affiliations : (1) Institut des Matériaux Jean Rouxel (IMN), UMR6502, CNRS-Université de Nantes, 2 chemin de la Houssinière, BP 32229, 44322 Nantes cedex 3, France. (2) Laboratoire Charles Coulomb (L2C), UMR 5221 CNRS-Univ. Montpellier 2, Montpellier, France.

Resume : The recent efficiency breakthrough of Cu(In,Ga)Se2/CdS heterojunction-based solar cells results from KF post-deposition treatment (KF-PDT) of the completed absorber layer. KF-PDT implies the formation of a very thin CdIn2S4-like layer at the surface of the CIGSe during the chemical bath deposition (CBD) of CdS, yielding CIGSe/CdIn2S4/CdS junction. With the aim of better understanding the electro-optical characteristics of such a junction, thin films of CdIn2S4 have been co-evaporated on different types of substrates, namely soda-lime glass (SLG), SLG/Mo and regular SLG/Mo/CIGSe structures for cells preparation. In the present contribution, physico-chemical, optical and electrical properties of the layers will be presented as well as performances of cells based on p-CIGSe/n-CdIn2S4 junctions. The efficiencies reached by the latter devices appear strongly dependent on the amount of sulfur supplied during CdIn2S4 deposition. The first results of theoretical calculations, supporting the hypothesis that S-vacancies are at the origin of the n-type conductivity of CdIn2S4, do provide fundamental bricks to interpret cells performance.

V.X.2
09:15
Authors : J.Keller1, A.Aijaz1, T.Kubart1, L.Stolt1;2, M.Edoff1, T.Törndahl1
Affiliations : 1 Solid State Electronics, The Ångström Laboratory, Uppsala University, SE-75121 Uppsala, Sweden 2 Solibro Research AB, Vallvägen 5, SE-75151 Uppsala, Sweden

Resume : In this study thin films of In2O3 were fabricated by physical vapor deposition (PVD), namely magnetron sputtering, with and without a post-annealing step, and by atomic layer deposition (ALD). The electro-optical properties on glass as well as the performance as a transparent conductive oxide (TCO) layer in CuIn1-xGaxSe2 (CIGSe)-based solar cells are compared and related to a ZnO:Al (AZO) baseline TCO. Corresponding TCO film thicknesses were adjusted to a resulting sheet resistance of about Rsh = 20 Ohm/sq for all samples. Structural investigations were conducted by X-ray diffraction and scanning electron microscopy, while Hall and optical absorption measurements were performed to analyze the electrical and optical quality of the window layers. It is shown that the fully crystallized In2O3 layers processed by ALD and PVD plus post-annealing show similar microstructural and electro-optical properties, which are superior to the AZO baseline. The finalized solar cells were characterized by current-voltage and reflectance-corrected quantum efficiency measurements. While there is no significant gain in short circuit current density for as-deposited PVD In2O3 layers, the application of crystalline In2O3 TCOs leads to an improvement of more than 1 mA/cm2 due to an increase in ”optical” band gap energy and less free charge carrier absorption. The open circuit voltage (Voc) of the best cells is 10-15 mV higher compared to the AZO reference, independent on the crystallinity of the In2O3 films. Since very comparable absorber and buffer layers were used (stemming from the same run) the differences in Voc are reliable and the detected slight gain is most likely caused by material properties (lower electron affinity or reduced interface defect density by a more coherent interface to the buffer layer) rather than by differences in the deposition processes.

V.X.3
09:30
Authors : J. P. Teixeira (1), P. M. P. Salomé (2), J. Keller (3), T. Törndahl (3), N. Nicoara (2), M. Edoff (3), S. Sadewasser (2) and J. P. Leitão (1)
Affiliations : (1) Departamento de Física and I3N, Universidade de Aveiro, 3810-193 Aveiro, Portugal; (2) INL - International Iberian Nanotechnology Laboratory, 4715-330 Braga, Portugal; (3) Angström Laboratory, Solid State Electronics, Angström Solar Center, Uppsala University, SE-751 21 Uppsala,Sweden

Resume : We study the effect of post-growth annealing on the Cu(In,Ga)Se2 (CIGS) thin film and its interface with CdS, as well as the effect of the delay between the annealing and the photoluminescence (PL) measurements. A CIGS/CdS sample was annealed in air at 185oC for 30 mins and PL was measured before (15 min) and after annealing (1, 16 and 64 h). Before the annealing, a broad and asymmetric band is observed, suggesting the influence of fluctuating potentials in the radiative transitions. After the annealing, a redshift of the PL (~23 meV) and a decrease of the asymmetry of the band are observed. For a time interval of 16 and 64 h, a blueshift and an increase of the asymmetry is observed. We used the dependence on the excitation power of the peak energy to investigate the influence of the annealing on the fluctuating potentials at the CIGS layer. With the increase of the excitation power, the observed peak energy shifts were 7.0(0.5), 5.8(0.4), 6.2(0.8) and 6(2) meV for before annealing and 1, 16 and 64 h after the post-growth annealing, respectively. The results suggest that a post-growth annealing step is beneficial for the reduction of fluctuating potentials. Nevertheless, a partial “recovery” of the absorber layer and/or the absorber/buffer interface compared to their properties prior to the annealing is observed.

V.X.4
09:45
Authors : M. Algasinger, T. Niesen, T. Dalibor, A. Steigert, R. Klenk, I. Lauermann, M.C. Lux-Steiner, J. Palm
Affiliations : AVANCIS, Otto Hahn Ring 6, 81739 München; Helmholtz-Zentrum Berlin für Materialien und Energie, Hahn-Meitner-Platz 1, 14109 Berlin

Resume : CIGS modules with an aperture area of 667cm2 and efficiencies up to 15.6% were prepared using a sputtered Zn(O,S)-buffer layer. The AVANCIS Cd-free buffer layer is based on InxSy, deposited with a soft but more complex thermal evaporation process. Here we demonstrate that a simple and low-cost industrial sputter process can be used to substitute the conventional buffer and i-layer with a single film of Zn(O,S). We evaluate the influence of an additional i-ZnO film between the Zn(O,S)-buffer and the ZnO:Al front electrode layer. In comparison with our state-of-the-art InxSy:Na reference, the CIGS modules with a Zn(O,S)-buffer show a superior short-circuit current, which is slightly overcompensated by a loss in the open-circuit voltage. Quantum efficiency measurements reveal that the gain in the short-circuit current can be attributed to a higher transparency in the UV-region due to a larger band gap of the Zn(O,S). Electroluminescence images demonstrate a low and uniform recombination across the active module area. The quality of the Zn(O,S)/CIGS interface, as judged from saturation current and ideality factor, is close to that of the InxSy:Na reference. Hence, by further optimizing the deposition parameters and interface properties, the sputtered Zn(O,S)-buffer is a promising candidate in order to increase the efficiency and reduce the costs of CIGS modules.

V.X.5
10:00 Coffee break

Modules & structural characterization : N. Barreau, M. Algasinger
10:30
Authors : Martin Ehrhardt1, Klaus Zimmer1, Pierre Lorenz1, Lukas Bayer1, Emilio Sánchez Cortezon2
Affiliations : 1 Leibniz-Institut für Oberflächenmodifizierung e. V., Permoserstraße 15, 04318 Leipzig, Germany; 2 Abengoa Solar – Madrid, Paseo de la Castellana 31,5º, 28046 Madrid, Spain

Resume : Selective removal of functional layers without affecting the functionality is still challenging for laser-assisted methods. In the present study laser pattering of copper indium gallium selenide (CIGS) thin films which are deposited on flexible metal substrates are presented. The pattering experiments were performed with a laser source having a wavelength of 1550 nm and pulse duration of 6 ns. The 1550 nm wavelength was selected due to the high transparency of the CIGS material in this wavelength range. It was found that due to the high transparency of the CIGS material two different material removal processes can be activate. By using a fixed laser repetition rate with a high pulse overlap a material ablation process starting front the sample was observed. By decreasing the pulse overlap the material removal process induced by laser ablation changes to a stress assisted delamination process. The material modification of the processed sample material in dependence on the laser parameters used was analyzed in detail for both processes. Therefore the composition of the sample material after the laser treatment was analyzed by energy dispersive X-ray spectroscopy (EDX) and micro Raman spectroscopy.

V.XI.1
10:45
Authors : I. Becerril-Romero, S. Giraldo, M. Placidi, Y. Sánchez, D. Sylla, V. Izquierdo-Roca, E. Saucedo, P. Pistor
Affiliations : IREC, Catalonia Institute for Energy Research, Jardins de les Dones de Negre 1, 2ª, 08930 Sant Adrià del Besòs, Spain.

Resume : The range of applications of kesterite photovoltaic devices can be widely broadened by the use of alternative substrates to soda-lime glass. This work explores the use of commercial ceramic tiles as ecological substrates for CZTSe thin film solar cells in view of an application in building integrated photovoltaics (BIPV). As a novel approach to control the Na-incorporation into the absorber, the substrates are coated with enamels containing different concentrations of Na2O. This way, the enamel acts not only as barrier, but also a source of Na during the absorber growth. Cu2ZnSnSe4 (CZTSE) absorbers were produced on Mo coated substrates by sequential process including sputtering deposition of the metallic precursors followed by a reactive annealing. The analysis of the samples processed with different Na2O contents shows an optimum region before degradation of the back contact morphology. Resonant Raman scattering measurements have revealed the formation of SnSe2 as main secondary phase in the layers, being the content of this phase strongly related to the thermal annealing conditions. Correlation of these measurements with the optoelectronic properties of test cells fabricated with these layers shows that this phase deteriorates the device performance mainly by limiting the short circuit current. Optimisation of these processes has allowed the synthesis of SnSe2 free layers with good crystallinity that lead to a promising device efficiency of 7.5%.

V.XI.2
11:00
Authors : Claudia S. Schnohr (1), Stefanie Eckner (1), Philipp Schöppe (1), Erik Haubold (1), Christian A. Kaufmann (2), Dieter Greiner (2), Francesco d’Acapito (3)
Affiliations : (1) Institut für Festkörperphysik, Friedrich-Schiller-Universität Jena, Max-Wien-Platz 1, 07743 Jena, Germany; (2) PVcomB, Helmholtz-Zentrum Berlin für Materialien und Energie, Schwarzschildstr. 3, 12489 Berlin, Germany; (3) CNR-IOM-OGG c/o ESRF LISA CRG, 71 Avenue des Martyrs, 38043 Grenoble, France

Resume : High efficiency Cu(In,Ga)Se2 solar cells are typically Cu-poor but have passed through a Cu-rich intermediate stage during the three-stage co-evaporation process. This strongly increases the solar cell performance, however, the mechanisms behind this improvement are not yet fully understood [1]. Similarly, the presence of alkali elements such as Na and K is known to increase the conversion efficiency, but again, the underlying mechanisms are not yet clear. We have therefore used X-ray absorption spectroscopy (XAS) to study the local atomic structure of Cu(In,Ga)Se2 absorber layers prepared by the three-stage co-evaporation process. The films are characterized by different final Cu contents and have or have not passed through the Cu-rich intermediate stage. Additionally, samples were prepared with and without the presence of alkali elements. The XAS analysis yields local structural parameters such as element-specific bond lengths and bond length variations [2]. Comparing these parameters for the different Cu(In,Ga)Se2 samples provides unique insight into the correlation between preparation conditions and subnanoscale structure and thus contributes to a better understanding of the improved device performance of absorber layers that have passed through a Cu-rich intermediate stage and were subjected to alkali treatment. [1] Caballero et al., Prog. Photovolt. 21, 30 (2013). [2] Schnohr et al., Thin Solid Films 582, 356 (2015).

V.XI.3
11:15
Authors : Helena Stange 1, Stephan Brunken 2, Dieter Greiner 2, Marc-Daniel Heinemann 2, Christian Alexander Kaufmann 2, Sebastian Simon Schmidt 2, Jan-Peter Bäcker 2, Manuela Klaus 2, Christoph Genzel 2, Roland Mainz 2
Affiliations : 1 Technische Universität Berlin, Institut für Werkstoffwissenschaften, 10587, Berlin, Germany; 2 Helmholtz-Zentrum Berlin für Energy und Materialien GmbH, Hahn-Meitner Platz 1, 14109, Berlin, Germany

Resume : A Cu-poor/Cu-rich compositional transition is essential in multi-stage co-evaporation of high-efficiency Cu(In,Ga)Se2 thin film solar cell absorbers. For manufacturing purposes a precise understanding of the influence of Cu is necessary to simplify the complex deposition process. The recrystallisation occurring around the point of stoichiometry has been attributed to an increased mobility of grain boundaries. Less attention has been paid to the effect of Cu on the microstructure at Cu-poor compositions. In samples from interrupted processes the typically constant Cu evaporation rate makes it difficult to differentiate between the influence of exposure to high substrate temperature and Cu concentration increase. We overcome this obstacle by using in-situ energy-dispersive X-ray diffraction to study the microstructural evolution of CuInSe2 thin films during Cu-Se deposition with repeatedly interrupted Cu evaporation at low substrate temperatures (420°C). We show that at Cu-poor compositions domain size growth, stacking fault annihilation and stress relaxation are driven by Cu deposition. We deduce an additional driving force for grain growth induced by Cu diffusion and propose diffusion induced grain boundary migration (DIGM) as grain growth mechanism in Cu-poor CuInSe2. DIGM has hitherto not been considered in CuInSe2 thin film growth and differs from the explanations based on grain boundary mobility for grain growth during the Cu-poor/Cu-rich transition. Our results complement the picture of the role of Cu in the microstructural evolution during multi-stage co-evaporation of CuInSe2.

V.XI.4
11:30
Authors : A. Loubat, F. Mollica, M. Bouttemy, D. Aureau, J. Vigneron, S. Gaiaschi, N. Naghavi, M. Jubault, F. Donsanti, P. Chapon, D. Lincot, A. Etcheberry
Affiliations : Lavoisier Institute of Versailles (ILV), UMR 8180 CNRS-UVSQ, IPVF, 45 avenue des Etats Unis, 78035 Versailles, France; Institute of Research and Development on Photovoltaic Energy (IRDEP) EDF –UMR 7174 CNRS-Chimie ParisTech, IPVF, 6 quai Watier, 78400 Chatou, FRANCE; Lavoisier Institute of Versailles (ILV), UMR 8180 CNRS-UVSQ, IPVF, 45 avenue des Etats Unis, 78035 Versailles, France; Lavoisier Institute of Versailles (ILV), UMR 8180 CNRS-UVSQ, IPVF, 45 avenue des Etats Unis, 78035 Versailles, France; Lavoisier Institute of Versailles (ILV), UMR 8180 CNRS-UVSQ, IPVF, 45 avenue des Etats Unis, 78035 Versailles, France; HORIBA Jobin Yvon, IPVF, 16 rue du Canal, 91160 Longjumeau, France; Institute of Research and Development on Photovoltaic Energy (IRDEP) EDF –UMR 7174 CNRS-Chimie ParisTech, IPVF, 6 quai Watier, 78400 Chatou, France; Institute of Research and Development on Photovoltaic Energy (IRDEP) EDF –UMR 7174 CNRS-Chimie ParisTech, IPVF, 6 quai Watier, 78400 Chatou, France; Institute of Research and Development on Photovoltaic Energy (IRDEP) EDF –UMR 7174 CNRS-Chimie ParisTech, IPVF, 6 quai Watier, 78400 Chatou, France; HORIBA Jobin Yvon, IPVF, 16 rue du Canal, 91160 Longjumeau, France; Institute of Research and Development on Photovoltaic Energy (IRDEP) EDF –UMR 7174 CNRS-Chimie ParisTech, IPVF, 6 quai Watier, 78400 Chatou, France; Lavoisier Institute of Versailles (ILV), UMR 8180 CNRS-UVSQ, IPVF, 45 avenue des Etats Unis, 78035 Versailles, France

Resume : CIGS (Cu(In,Ga)Se2) thin film absorbers are performing for high yield photovoltaic cells. It’s well known that photovoltaic cells’ performances mainly rely on absorber properties. In this context, the fine optimization of absorber requires an accurate characterization of the surface, the volume of each layer and their interfaces. Especially for CIGS absorbers, determination of gallium gradient (through GGI=Ga/[Ga+In] ratio) is a key parameter. We have developed a strategy of cross physico-chemical characterization methods. First, the chemical composition (major elements, impurities) is investigated combining EDS, ICP-OES, GD-OES and XPS. Then, the surface morphology is studied by SEM and AFM imaging (roughness). All analyzes were carried out on a batch of ungraded CIGS samples prepared by coevaporation with GGI ratio ranging from 0.15 to 0.61. Both thickness and depth composition were set constant to evaluate the sensitivity of each technique. Cross-checking of results will be discussed in terms of calibration and accuracy of composition depth profile linearity. An original XPS approach, to directly access the GGI ratio, based on Ga3dIn4d region study, will be presented as a better way to determine the actual surface composition before buffer layer deposition. Complementary work will be also shown and dedicated to the determination of local scale composition using nanoAuger technique (spot size 12nm). This method allows the investigation of grain boundaries particularities.

V.XI.5
11:45
Authors : Norbert Schäfer (1), Angus J. Wilkinson (2), Thomas Schmid (3), Aimo Winkelmann (4), Gilbert A. Chahine (5), Tobias U. Schülli (5), Sergiu Levcenko (1), Thorsten Rissom (1), Julien Marquardt (1,6), Susan Schorr (1,6) , Daniel Abou-Ras (1)
Affiliations : 1. Helmholtz-Zentrum Berlin für Materialien und Energie GmbH, Hahn-Meitner-Platz 1,14109 Berlin, Germany; 2. Department of Materials, University of Oxford, Parks Road, Oxford OX1 3PH, U.K.; 3. Federal Institute for Materials Research and Testing, Richard-Willstätter-Str. 11, 12489 Berlin, Germany; 4. Bruker Nano GmbH, D-12489 Berlin, Germany; 5. European Synchrotron Radiation Facility, BP 220, Grenoble Cedex, France; 6. Freie Universitaet Berlin, Institute of Geological Sciences, Malteserstr. 74-100, 12249 Berlin, Germany

Resume : The enhanced understanding of the microstructural influence of the polycrystalline Cu(In,Ga)Se2 absorber layers is crucial for the further improvement of the power-conversion efficiency of the complete device. As a part of this work, various line and planar defects need to be detected and characterized. Since these defects introduce local changes in interplanar distances within individual grains, their presence are expected to be visible in microstrain distribution maps, which may be acquired by various diffraction and spectroscopy techniques. In the present contribution, we show a comparative study of microstrain distributions within individual grains, by means of electron backscatter diffraction, high-resolution X-ray diffraction, and Raman microspectroscopy, using a coevaporated, polycrystalline CuInSe2 thin film as a model system. Most of the measured microstrain values were in the order of 0.0001, and the microstrain maps from the three techniques appear qualitatively similar to one another. However, the sensitivities of the analysis methods with respect to reliable, quantitative microstrain distributions differ substantially. The possibility of applying these techniques for microstrain mapping on thin films with average grain sizes of less than 2 µm, particularly addressing possible sample geometries, for the characterization of structure-property relationships is discussed.

V.XI.6

Symposium organizers
Daniel ABOU-RASHelmholz Zentrum Berlin für Materialien und Energie GmbH

Hahn-Meitner Platz 1 14109 Berlin Germany

+49 30 8062 43218
daniel.abou-ras@helmholtz-berlin.de
Hugh W. HILLHOUSEUniversity of Washington

Box 351750 Seattle, WA 98195 USA

+1 206 685 5257
h2@uw.edu
Marika EDOFFUppsala University

Department of Engineering Sciences Box 534 751 21 Uppsala Sweden

+ 46 18 471 72 49
marika.edoff@angstrom.uu.se
Stephan BUECHELER (Main Organizer)Empa

Laboratory for Thin Films and Photovoltaics, Überlandstrasse 129, 8600 Dübendorf, Switzerland

+ 41 58 765 6107
Stephan.Buecheler@empa.ch
Takeaki SAKURAIUniversity of Tsukuba

Faculty of Pure and Applied Sciences Tennodai 1-1-1 Tsukuba 305-8573 Japan

+81 29 853 6150
sakurai@bk.tsukuba.ac.jp
